C8D30PF29013 Product Details
Live Product Chat
High Density and Press-Fit Connectors
Always EU R oHS com plia nt but not ELV C om plia nt
(
Sta te m e nt of
C om plia nce
)
Quick Links
C heck Pricing & Availability
Search for Tooling
Product Feature Selector
C ontact Us About This Product
C8D30PF29013
(5-1437260-6)
T E I nternal N umber: 5 - 1 4 3 7 2 6 0 - 6
Product Highlights:
l
C onnector
l
C onnector Type = Standard
l
2.54 mm C enterline
l
Row-to-Row Spacing = 5.08 mm
l
30 Dual Positions
View all Features
A dd to M y P art L is t
Reques t Sample
Find Similar P roduc ts
Active
Buy P roduc t
Documentation & Additional Information
Product Drawings:
l
None Available
Catalog Pages/Data Sheets:
l
card edge connectors
(PDF, English)
Product Specifications:
l
None Available
Application Specifications:
l
None Available
Instruction Sheets:
l
None Available
CAD Files:
l
None Available
List all Documents
Product Features
(Please use the Product Drawing for all design activity)
Product Type Features:
l
Product Type = C onnector
l
C onnector Type
= Standard
l
Number of Dual Positions
= 30
l
Post Type = Press-Fit
Termination Related Features:
l
Termination Post Length (mm [in])
= 4.57 [0.180]
Body Related Features:
l
C enterline (mm [in])
= 2.54 [0.100]
l
Row-to-Row Spacing (mm [in])
= 5.08 [0.200]
l
C ard Slot Depth (mm [in])
= 7.62 [0.300]
Contact Related Features:
l
C ontact Base Material
= High Strength C opper Alloy
l
C ontact Plating, Mating Area, Material
= Gold (30)
Housing Related Features:
l
Housing Material = Thermoplastic - GF
l
Housing C olor = Black
l
Housing Flammability Rating = UL 94V-0
Configuration Related Features:
l
Standoffs
= With
Industry Standards:
l
RoHS/ELV C ompliance
= RoHS/Not ELV C ompliant
l
Lead Free Solder Processes
= Not relevant for lead free process
l
RoHS/ELV C ompliance History = Always was RoHS not ELV
compliant
Other:
l
Daughter Board Thickness (mm [in])
= 1.37 – 1.78 [0.054 – 0.070]
l
Brand = Tyco Electronics
Additional Information:
l
Product Line Information
