Part Number

Search

352115-4

Description
55 CONTACT(S), FEMALE, RIGHT ANGLE TWO PART BOARD CONNECTOR, PRESS FIT, RECEPTACLE
CategoryThe connector    The connector
File Size75KB,1 Pages
ManufacturerTE Connectivity
Websitehttp://www.te.com
Download Datasheet Parametric Compare View All

352115-4 Overview

55 CONTACT(S), FEMALE, RIGHT ANGLE TWO PART BOARD CONNECTOR, PRESS FIT, RECEPTACLE

352115-4 Parametric

Parameter NameAttribute value
Is it lead-free?Contains lead
Is it Rohs certified?incompatible
Objectid1504390069
Reach Compliance Codeunknown
Other featuresACTION PIN
body width0.482 inch
subject depth0.826 inch
body length0.982 inch
Body/casing typeRECEPTACLE
Connector typeBOARD CONNECTOR
Contact to complete cooperationMATTE TIN
Contact completed and terminatedMATTE TIN
Contact point genderFEMALE
Contact materialCOPPER ALLOY
contact modeRECTANGULAR
Contact resistance20 mΩ
Contact styleSQ PIN-SKT
DIN complianceNO
Durability250 Cycles
Filter functionNO
IEC complianceNO
maximum insertion force.7506 N
Insulation resistance10000000000 Ω
Insulator colorGRAY
insulator materialGLASS FILLED POLYESTER
JESD-609 codee3
MIL complianceNO
Manufacturer's serial number352115
Plug contact pitch0.079 inch
Match contact row spacing0.079 inch
Mixed contactsNO
Installation option 1LOCKING
Installation methodRIGHT ANGLE
Installation typeBOARD
Number of connectorsONE
Number of rows loaded5
Maximum operating temperature125 °C
Minimum operating temperature-55 °C
OptionsGENERAL PURPOSE
PCB contact patternRECTANGULAR
PCB contact row spacing2.0066 mm
Plating thickness30u inch
polarization keyPOLARIZED HOUSING
Rated current (signal)1.5 A
reliabilityCOMMERCIAL
Terminal length0.13 inch
Terminal pitch2 mm
Termination typePRESS FIT
Total number of contacts55
Evacuation force-minimum value.15012 N

352115-4 Related Products

352115-4 352115-9
Description 55 CONTACT(S), FEMALE, RIGHT ANGLE TWO PART BOARD CONNECTOR, PRESS FIT, RECEPTACLE 55 CONTACT(S), FEMALE, RIGHT ANGLE TWO PART BOARD CONNECTOR, PRESS FIT, RECEPTACLE
Is it Rohs certified? incompatible incompatible
Objectid 1504390069 1504390072
Reach Compliance Code unknown compliant
Other features ACTION PIN ACTION PIN
body width 0.482 inch 0.482 inch
subject depth 0.826 inch 0.827 inch
body length 0.982 inch 0.984 inch
Body/casing type RECEPTACLE RECEPTACLE
Connector type BOARD CONNECTOR BOARD CONNECTOR
Contact to complete cooperation MATTE TIN MATTE TIN
Contact completed and terminated MATTE TIN MATTE TIN
Contact point gender FEMALE FEMALE
Contact material COPPER ALLOY COPPER ALLOY
contact mode RECTANGULAR RECTANGULAR
Contact resistance 20 mΩ 20 mΩ
Contact style SQ PIN-SKT BELLOWED TYPE
DIN compliance NO NO
Filter function NO NO
IEC compliance NO NO
Insulator color GRAY GRAY
insulator material GLASS FILLED POLYESTER GLASS FILLED POLYESTER
JESD-609 code e3 e3
MIL compliance NO NO
Manufacturer's serial number 352115 352115
Plug contact pitch 0.079 inch 0.079 inch
Match contact row spacing 0.079 inch 0.079 inch
Mixed contacts NO NO
Installation method RIGHT ANGLE RIGHT ANGLE
Installation type BOARD BOARD
Number of connectors ONE ONE
Number of rows loaded 5 5
Options GENERAL PURPOSE GENERAL PURPOSE
PCB contact pattern RECTANGULAR RECTANGULAR
PCB contact row spacing 2.0066 mm 2.0066 mm
Plating thickness 30u inch 30u inch
polarization key POLARIZED HOUSING POLARIZED HOUSING
Rated current (signal) 1.5 A 1.5 A
reliability COMMERCIAL COMMERCIAL
Terminal length 0.13 inch 0.13 inch
Terminal pitch 2 mm 2 mm
Termination type PRESS FIT PRESS FIT
Total number of contacts 55 55
