536428-5

Description
CONNECTOR,DIN-41612,PCB MNT,RECEPT,150 CONTACTS,PIN,0.1 PITCH,PC TAIL TERMINAL,HOLE .112-.124
CategoryThe connector    The connector
File Size114KB，1 Pages
ManufacturerTE Connectivity
Websitehttp://www.te.com
Download Datasheet Parametric View All

536428-5 Overview

CONNECTOR,DIN-41612,PCB MNT,RECEPT,150 CONTACTS,PIN,0.1 PITCH,PC TAIL TERMINAL,HOLE .112-.124

536428-5 Parametric

Parameter NameAttribute value
MakerTE Connectivity
Reach Compliance Codeunknown
body width0.433 inch
subject depth0.453 inch
body length5.535 inch
Body/casing typeRECEPTACLE
Connector typeBOARD EURO CONNECTOR
Contact point genderMALE
Contact materialBRASS
Contact resistance20 mΩ
Contact styleSQ PIN-SKT
DIN complianceYES
Dielectric withstand voltage1000VAC V
Insulation resistance1000000000000 Ω
Insulator colorGRAY
insulator materialPOLYESTER
Plug contact pitch0.1 inch
Match contact row spacing0.1 inch
Installation option 1HOLE .112-.124
Installation methodSTRAIGHT
Installation typeBOARD
Loaded row nameA,B,C
PCB row number3
Number of rows loaded3
Maximum operating temperature125 °C
Minimum operating temperature-55 °C
PCB contact patternRECTANGULAR
PCB contact row spacing2.54 mm
Rated current (signal)1.5 A
GuidelineUL, CSA
reliabilityCOMMERCIAL
Terminal length0.18 inch
Terminal pitch2.54 mm
Termination typeSOLDER
Total number of contacts150
Base Number Matches1

Preview

Download Datasheet
C orporate Hom e
|
Electronic Components
|
Se gm e nts
|
W ho W e Are
My Account
Searc h
Products
Documentation
Resources
My Account
Customer Support
Home
>
Products
>
By Type
>
Eurocard C onnectors
>
Product Feature Selector
> Product Details
536428-5 Product Details
Live Product Chat
Product Photo
Eurocard Type R
Not re vie we d for R oHS C om plia nce
Quick Links
C heck Pricing & Availability
Search for Tooling
Product Feature Selector
C ontact Us About This Product
536428-5
T E I nternal N umber: 5 3 6 4 2 8 - 5
Product Highlights:
l
Plug
l
Number of Positions = 150
l
PC B Mount Angle = Vertical
l
Yes PC B Retention Feature
l
Boardlock(s)
View all Features
Obsolete
Search for Replacement Parts
A dd to M y P art L is t
Reques t Sample
Find Similar P roduc ts
Buy P roduc t
Documentation & Additional Information
Documents are temporarily unavailable. We are working hard to correct the problem. Please try
again later.
Additional Information:
l
Product Line Information
Related Products:
l
Tooling
Product Features
(Please use the Product Drawing for all design activity)
Product Type Features:
l
Product Type
= Plug
l
Number of Positions
= 150
l
PC B Mount Angle
= Vertical
l
PC B Retention Feature
= Yes
l
Post Type
= Solder Post
l
Mating Polarization
= Without
l
Guides
= Without
l
Make First / Break Last
= No
l
DIN Level
= II
l
C olor = Gray
Termination Related Features:
l
Termination Post Length (mm [in])
= 4.57 [0.180]
Body Related Features:
l
PC B Retention Method
= Boardlock(s)
l
C ontact C ross Section (mm [in]) = 0.64 [.025] Sq.
l
Rows Loaded
= A, B, C
Contact Related Features:
l
C ontact Base Material = Brass
Housing Related Features:
l
Housing Material = Polyester
l
Housing Flammability Rating = UL 94V-0
Industry Standards:
l
RoHS/ELV C ompliance
= Not reviewed for ELV/RoHS compliance
l
Lead Free Solder Processes
= Not reviewed for lead free solder
process
l
Flux-Tight C oating
= Without
Other:
l
Brand = AMP
