353320-5 datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > The connector> The connector> 353320-5

353320-5: DescriptionMINI CT; CategoryThe connector The connector; File Size125KB，1 Pages; ManufacturerTE Connectivity; Websitehttp://www.te.com

Download Datasheet Parametric View All

353320-5 Overview

MINI CT

353320-5 Parametric

Parameter Name	Attribute value
Brand Name	AMP
Is it lead-free?	Contains lead
Is it Rohs certified?	incompatible
Maker	TE Connectivity
Reach Compliance Code	compliant
ECCN code	EAR99
Other features	PANEL MOUNTABLE
Body/casing type	RECEPTACLE
Connector type	BOARD CONNECTOR
Contact to complete cooperation	NOT SPECIFIED
Contact point gender	MALE
Contact material	NOT SPECIFIED
contact mode	RECTANGULAR
Contact resistance	20 mΩ
Contact style	SQ PIN-SKT
DIN compliance	NO
Dielectric withstand voltage	500VAC V
Durability	30 Cycles
Filter function	NO
IEC compliance	NO
Minimum insulation diameter	0.031 inch
Insulation resistance	100000000 Ω
Insulator color	WHITE
insulator material	NYLON
MIL compliance	NO
Plug contact pitch	0.059 inch
Mixed contacts	NO
Installation option 1	LATCH
Installation type	CABLE
Number of rows loaded	1
Maximum operating temperature	105 °C
Minimum operating temperature	-30 °C
Options	GENERAL PURPOSE
polarization key	POLARIZED HOUSING
Rated current (signal)	2 A
Guideline	UL
reliability	COMMERCIAL
Terminal pitch	1.5 mm
Termination type	CRIMP
Total number of contacts	5
UL Flammability Code	94V-0
Maximum wire diameter	26 AWG
Minimum wire diameter	28 AWG
Base Number Matches	1

Preview

Download Datasheet

View All

My Account

Tyco Electronics

(C hange)

Se a rch by Ke yword or Pa rt #

Products

Documentation

Resources

My Account

Customer Support

Home

Products

By Type

Product Feature Selector

> Product Details

353320-5 Product Details

Live Product Chat

1.5mm AMP Mini CT Connectors

Not EU R oHS or ELV C om plia nt

(

Find R oHS C om plia nt Alte rna te s

)

Quick Links

C heck Pricing & Availability

Search for Tooling

Product Feature Selector

C ontact Us About This Product

353320-5

T E I nternal N umber: 3 5 3 3 2 0 - 5

Product Highlights:

Post Header

C onnector Type = Intermediary

5 Positions

With Panel Attachment

Number of Rows = 1

View all Features

Active

View 3D PDF

A dd to M y P art L is t

Reques t Sample

Find Similar P roduc ts

Buy P roduc t

Documentation & Additional Information

Product Drawings:

None Available

Catalog Pages/Data Sheets:

PERSONAL SYSTEMS PRODUC TS

(PDF, English)

Product Specifications:

None Available

Application Specifications:

None Available

Instruction Sheets:

None Available

CAD Files:

AD Format & C ompression Information)

2D Drawing

(DXF, Version A)

3D Model

(IGES, Version A)

3D Model

(STEP, Version A)

List all Documents

Product Features

(Please use the Product Drawing for all design activity)

Product Type Features:

Product Type

= Post Header

C onnector Type

= Intermediary

Number of Positions

= 5

C olor

= White

Post Size (mm [in]) = 0.50 [.020]

Panel Thickness (mm [in]) = 0.80 – 1.60 [0.031 – 0.063]

Mechanical Attachment:

Panel Attachment

= With

Body Related Features:

Number of Rows

= 1

C enterline (mm [in]) = 1.50 [0.059]

Contact Related Features:

C ontact Base Material = Brass

C ontact Plating, Mating Area, Material = Tin-Lead

C ontact Shape = Square

Housing Related Features:

Housing Material = Nylon 66

Housing Flammability Rating = UL 94V-0

Industry Standards:

RoHS/ELV C ompliance

= Not ELV/RoHS compliant

Lead Free Solder Processes

= Not relevant for lead free process

Packaging Related Features:

Packaging Method

= Loose Piece

Other:

Brand = AMP

Additional Information:

Product Line Information
