3079-1500 datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > The connector> Connector bracket> 3079-1500

3079-1500: DescriptionWire And Cable,; CategoryThe connector Connector bracket; File Size241KB，3 Pages; ManufacturerAlpha Wire; Websitehttp://www.alphawire.com/zh-CN/; Environmental Compliance

Download Datasheet Parametric Compare View All

3079-1500 Overview

Wire And Cable,

3079-1500 Parametric

Parameter Name	Attribute value
Is it Rohs certified?	conform to
Maker	Alpha Wire
Reach Compliance Code	compliant
Connector bracket type	WIRE AND CABLE
Base Number Matches	1

Preview

Download Datasheet

View All

Alpha Wire | 711 Lidgerwood Avenue, Elizabeth, NJ 07207

Tel: 1-800-52 ALPHA (25742), Web: www.alphawire.com

Customer Specification

PART NO. 3079

Construction

Diameters (In)

1) Component 1

a) Conductor

b) Insulation

1 X 1 HOOKUP

14 (41/30) AWG TC

0.032" Wall, Nom. PVC

0.074

0.138+/- 0.004

ALPHA WIRE E163872-* (UL) MTW OR TW 600V OR AWM

STYLE 1015/1230 105C 600V VW-1 14 AWG ---- LLXXXX

(1) Print

CSA AWM I A/B 105C 600V FT1 OR TEW 105C 600V FT1

CE ROHS

{0} * = Factory Code

[Note: Product may have c(UL) or CSA markings depending upon plant of manufacture.]

WHITE, BLACK, RED, GREEN, YELLOW, BLUE, BROWN

ORANGE, SLATE, VIOLET, GREEN/YELLOW, YELLOW/GREEN

(2) Color(s)

Applicable Specifications

1) UL

AWM/STYLE 1015

MTW

AWM/STYLE 1230

VW-1

2) CSA International

TEW-105

AWM I A/B

FT1

3) CE:

EU Low Voltage Directive 2006/95/EC

105°C / 600 VRMS

90°C Dry / 60°C Wet / 600 VRMS

105°C / 600 VRMS

60°C Dry / 60°C Wet / 600 VRMS

Environmental

1) EU Directive 2011/65/EU(RoHS2):

All materials used in the manufacture of this part are in compliance with European Directive

2011/65/EU regarding the restriction of use of certain hazardous substances in electrical and

electronic equipment. Consult Alpha Wire's web site for RoHS C of C.

2) REACH Regulation (EC 1907/2006):

This product does not contain Substances of Very High Concern (SVHC) listed on the European

Union's REACH candidate list in excess of 0.1% mass of the item. For up-to-date information,

please see Alpha's REACH SVHC Declaration.

3) California Proposition 65:

The outer surface materials used in the manufacture of this part meet the requirements of

California Proposition 65.

Properties

Physical & Mechanical Properties

1) Temperature Range

2) Bend Radius

3) Pull Tension

Electrical Properties

1) Voltage Rating

2) Inductance

3) Conductor DCR

-40 to 105°C

5X Cable Diameter

32 Lbs, Maximum

(For Engineering purposes only)

600 VRMS

0.05 µH/ft, Nominal

2.8 Ω/1000ft @20°C, Nominal

Other

Packaging

a) 1000 FT

b) 1000 FT UK

c) 500 FT

d) 100 FT UK

e) 100 FT

Flange x Traverse x Barrel (inches)

12 x 4.5 x 3.5 Continuous length

11 x 5.5 x 5 Continuous length

6.5 x 6 x 1.9 Continuous length

6.5 x 2 x 1.875 Continuous length

6.5 x 2 x 1.9 Continuous length

[Spool dimensions may vary slightly]

Notes:

a) Certain colors and put-ups are available as a special order only, minimums may apply.

www.alphawire.com

Alpha Wire | 711 Lidgerwood Avenue, Elizabeth, NJ 07207

Tel: 1-800-52 ALPHA (25742)

Although Alpha Wire (“Alpha”) makes every reasonable effort to ensure their accuracy at the time of publication, information and specifications

described herein are subject to errors or omissions and to changes without notice, and the listing of such information and specifications does not

ensure product availability.

Alpha provides the information and specifications herein on an “AS IS” basis, with no representations or warranties, whether express, statutory or

implied. In no event will Alpha be liable for any damages (including consequential, indirect, incidental, special, punitive, or exemplary) whatsoever,

even if Alpha had been advised of the possibility of such damages, whether in an action under contract, negligence or any other theory, arising out

of or in connection with the use, or inability to use, the information or specifications described herein.

ALPHA WIRE - CONFIDENTIAL AND PROPRIETARY

Notice to persons receiving this document and/or technical information. This document is confidential and is the exclusive property of ALPHA WIRE,

and is merely on loan and subject to recall by ALPHA WIRE at any time. By taking possession of this document, the recipient acknowledges and

agrees that this document cannot be used in any manner adverse to the interests of ALPHA WIRE, and that no portion of this document may be

copied or otherwise reproduced without the prior written consent of ALPHA WIRE. In the case of conflicting contractual provisions, this notice shall

EU/China ROHS CERTIFICATE OF COMPLIANCE

To Whom It May Concern:

Alpha Wire Part Number: 3079

3079 , RoHS-Compliant Commencing With 1/1/2005 Production

This document certifies that the Alpha part number cited above is manufactured in accordance with Directive 2011/65/EU of the European

Parliament, better known as the RoHS Directive, with regards to restrictions of the use of certain hazardous substances used in the manufacture of

electrical and electronic equipment. The reader is referred to this Directive for the specific definitions and extents of this Directive. No Exemptions

are required for RoHS Compliance on this item. It should be noted that this product does not fall within the scope of Directive 2011/65/EU, but this

Certificate is offered for cases where this product will be used within EEE that does fit within the Directive's scope. Additionally, Alpha certifies that

the listed part number is in compliance with China RoHS “Marking for Control of Pollution by Electronic Information Products” standard SJ/T 11364-

2006.

Substance

Lead

Mercury

Cadmium

Hexavalent Chromium

Polybrominated Biphenyls (PBB)

Polybrominated Diphenyl Ethers (PBDE) ,

Including Deca-BDE

0.1% by weight (1000 ppm)

The information provided in this document and disclosure is correct to the best of Alpha Wire's knowledge, information and belief at the date of its

release. The information provided is designed only as a general guide for the safe handling, storage, and any other operation of the product itself or

the one that it will become part of. The intent of this document is not to be considered a warranty or quality specification. Regulatory information is

for guidance purposes only. Product users are responsible for determining the applicability of legislation and regulations based on their individual

usage of the product.

Authorized Signatory for the Alpha Wire Company:

Maximum Control Value

0.1% by weight (1000 ppm)

0.01% by weight (100 ppm)

0.1% by weight (1000 ppm )

0.1% by weight (1000 ppm)

Dave Watson, Director of Engineering & QA

7/17/2013
