Agilent HDSP-S51E Series
27.4 mm (1.08 inch) General Purpose
5 x 7 Dot Matrix Alphanumeric Displays
Data Sheet
Features
• 5 x 7 Dot matrix font
• Stackable horizontally
• Industry standard pin-out
– 22.86 mm (0.9 in.) Dual-In-Line
(DIP) leads on 2.54 mm (0.1 in.)
centers
• Choice of colors
– Single color: GaP Red or
GaP Green
– Bi-color: GaP Red and
GaP Green
• Face paint color: black
• Design flexibility
– Common row anode or
common row cathode
• Categorized for luminous intensity
or luminance
• Green categorized for color
Applications
• Suitable for indoor use
• Not recommended for industrial
applications, i.e., operating
temperature requirements
exceeding 85°C or below -35°C
• Extreme temperature cycling not
recommended
[1]
Description
These displays have a 27.4 mm
(1.08 inch) character height and
use industry standard size and pin-
out. The devices are available in
either common row anode or
common row cathode configura-
tions. The displays come in only
black face paint and are available in
a choice of GaP Red (HER) or GaP
Green colors. The Bi-color
display consists of GaP Red and
Green colors.
These parts are subjected to Out-
going Quality Assurance (OQA)
inspection with an AQL of
0.065% for functional and visual/
cosmetic defects.
Devices
GaP Red Green
HDSP-
HDSP-
S51E
S51G
S56E
S56G
B51Z
B56Z
Description
27.4 mm Black Surface Common Row Anode
27.4 mm Black Surface Common Row Cathode
27.4 mm Black Surface Bi-Color Common Row Anode
27.4 mm Black Surface Bi-Color Common Row Cathode
Note:
1. For details, please contact your local Agilent components sales office or an authorized distributor.
