AP2008SA Overview

Switching Controller, 0.2A, 300kHz Switching Freq-Max, PDSO8, SOP-8

AP2008SA Parametric

Parameter Name	Attribute value
Maker	Integrated Circuit Systems（IDT ）
Parts packaging code	SOIC
package instruction	SOP,
Contacts	8
Reach Compliance Code	unknown
ECCN code	EAR99
Analog Integrated Circuits - Other Types	SWITCHING CONTROLLER
Control Technology	PULSE WIDTH MODULATION
Maximum input voltage	20 V
Minimum input voltage	3.6 V
Nominal input voltage	6 V
JESD-30 code	R-PDSO-G8
length	5.05 mm
Number of functions	1
Number of terminals	8
Maximum operating temperature	85 °C
Minimum operating temperature	-20 °C
Maximum output current	0.2 A
Package body material	PLASTIC/EPOXY
encapsulated code	SOP
Package shape	RECTANGULAR
Package form	SMALL OUTLINE
Certification status	Not Qualified
Maximum seat height	1.75 mm
surface mount	YES
Switch configuration	BUCK
Maximum switching frequency	300 kHz
Temperature level	OTHER
Terminal form	GULL WING
Terminal pitch	1.27 mm
Terminal location	DUAL
width	3.9 mm
Base Number Matches	1

Preview

Download Datasheet

View All

AP2008

PWM Buck Controller

Features

- PWM Buck Control Circuitry

- Operating voltage can be up to 20V

- Under voltage Lockout (UVLO) Protection

- Short Circuit Protection (SCP)

- Soft-start circuit

- Variable Oscillator Frequency -- 300KHz Max

- 0.77V voltage reference Output

- 8-pin PDIP and SOP packages

General Description

The AP2008 integrates Pulse-Width-Modulation

(PWM) control circuit into a single chip, mainly

designs for power-supply regulator. All the functions

included an on-chip 0.77V reference output, an

error amplifier, an adjusted oscillator, a soft-start,

UVLO, SCP circuitry, and a push-pull output circuit.

Switching frequency can be adjustable by trimming

CT. During low VCC situation, the UVLO makes

sure that the outputs are off until the internal circuit

is operational normally.

Applications

- Backlight inverter

- LCD Monitor

- XDROM, XDSL Product

- DC/DC converters in computers, etc.

Pin Assignment

( Top View )

OUT

VCC

COMP

Pin Descriptions

Name

GND

SCP

Description

Timing Capacitor

Voltage Feedback

Soft-Start.

Feedback Loop Compensation

PWM Output

Ground

Supply Voltage

Short Circuit Protection

COMP

OUT

GND

VCC

SCP

PDIP/SOP

Ordering Information

AP2008 X

Package

N: PDIP-8L

S: SOP-8L

Lead Free

Packing

Blank : Tube

Blank : Normal

L : Lead Free Package A : Taping

This datasheet contains new product information. Anachip Corp. reserves the rights to modify the product specification without notice. No liability is assumed as a result of the use of

this product. No rights under any patent accompany the sale of the product.

Rev. 1.0 Oct 11, 2004

1/8
