REVISION Q
DO NOT
SCALE FROM
THIS PRINT
.397 10.08
02
(No OF POS x .100[2.54])
+ .694[17.63] REF
(No OF POS -1)
x .100[2.54] REF
.150 3.81 (TYP)
REF
No OF POSITIONS
-05 THRU -25
EJH-1XX-XX-XX-D-XX-XX-XX
OPTION
-LC: LOCKING CLIP (FOR -SM ONLY)
-P: PICK & PLACE PAD (FOR -SM ONLY)
(USE PPP-50, SEE FIGURE 6, SHEET 3)
-K: POLYAMIDE FILM (SEE FIG. 3, SHEET 3)
(USE K-850-650)
-TR: TAPE & REEL PACKAGING
(SEE FIG. 7, SHEET 3))
(FOR -SM-P, & -SM-K ONLY)
(NOT AVAILABLE ON -SM-LC)
(NOT AVAILABLE ON -25 POSITION)
"A"
.100 2.54
.020 0.51 REF
.390 9.91 REF
01
2 MAX SWAY
(TYP)
(No OF POS x .100[2.54])
+ .104[2.64] REF
.225 5.72 REF
.025 0.64 SQ REF
EJH-XX-D
"A"
.250 6.35 REF
-01: STANDARD
(USE EJH-XX-D)
-02: EXTENDED
(SEE FIG. 11, SHEET 4)
(USE EJH-XX-D-EXT &
EHA-03-EXT)
LEAD STYLE
PLATING SPECIFICATION
-S: SELECTIVE GOLD
(USE T-1S6X-XX-S-X)
-F: FLASH SELECTIVE GOLD
(USE T-1S6X-XX-F-X)
-SM: SELECTIVE HEAVY GOLD
(USE T-1S6X-XX-S-X)
-FM: FLASH SELECTIVE GOLD,
MATTE TIN TAIL
(USE T-1S6X-XX-F-X)
POLARIZED OPTION
-XX = PIN OMITED
TAIL OPTION
-SM: SURFACE MOUNT (SEE FIG. 1)
-TH: THROUGH HOLE (SEE FIG. 8, SHEET 2)
-RA: RIGHT ANGLE (SEE FIG. 9, SHEET 2)
ROW SPECIFICATION
-D: DOUBLE
.500 12.70 REF
90°
.505 12.83
.004[.10]
.467±.010 11.87±0.25
SECTION "A"-"A"
PIN A (SEE TABLE 1)
(No OF POS x .100[2.54])
+ .400[10.16] REF
.060 1.52
LC-09-TM
.060 1.52 REF
90°
.130 3.31
.467±.010 11.87±0.25
.280 7.11
POSITION 1 INDICATOR
EJH-110-01-X-D-SM-LC SHOWN
FIG. 1
-SM IN-PROCESS 1
UNLESS OTHERWISE SPECIFIED,
DIMENSIONS ARE IN INCHES.
TOLERANCES ARE:
DECIMALS
-SM IN-PROCESS 2
PROPRIETARY NOTE
NOTES:
1.
C
REPRESENTS A CRITICAL DIMENSION.
2. COPLANARITY TO BE: .004 MAX FOR POSITIONS -05 THRU -10
.006 MAX FOR POSITIONS -15 THRU -25
3. BURR ALLOWANCE: .0015 MAX.
4. MINIMUM PUSHOUT FORCE: 1 LB MIN.
5. MAXIMUM ALLOWABLE BOW: .002 INCH/INCH AFTER ASSEMBLY.
6. PARTS TO BE TUBED WITH EJECTOR ARMS IN THE UP POSITION
AS SHOWN.
7. REPRESS TO DIMENSION SHOWN.
8. NOTE DELETED.
9. MEASURE FROM THE TIPS OF THE TERMINALS.
.XX: .01 [.3]
2
.XXX: .005 [.13]
.XXXX: .0020 [.051]
ANGLES
THIS DOCUMENT CONTAINS INFORMATION
CONFIDENTIAL AND PROPRIETARY TO
SAMTEC, INC. AND SHALL NOT BE REPRODUCED
OR TRANSFERRED TO OTHER DOCUMENTS OR
DISCLOSED TO OTHERS OR USED FOR ANY
PURPOSE OTHER THAN THAT WHICH IT WAS
OBTAINED WITHOUT THE EXPRESSED WRITTEN
CONSENT OF SAMTEC, INC.
520 PARK EAST BLVD, NEW ALBANY, IN 47150
PHONE: 812-944-6733
FAX: 812-948-5047
e-Mail: info@SAMTEC.com
code: 55322
MATERIAL:
DO NOT SCALE DRAWING
-01 INSULATOR: VECTRA E130i, COLOR: BLACK
-02 INSULATOR COLOR: NATURAL
TERMINAL: PHOS BRONZE 510 3/4 HARD
F:\DWG\MISC\MKTG\EJH-1XX-XX-XX-D-XX-XX-XX-MKT.SLDDRW
SHEET SCALE: 1:0.666667
DESCRIPTION:
.100 x .100 EJECTOR HEADER ASSEMBLY
DWG. NO.
BY:
ERIC M.
EJH-1XX-XX-XX-D-XX-XX-XX
09/19/01
SHEET
1
OF
4
REVISION Q
EJH-110-01-X-D-TH SHOWN
[DIFFERENT AS SHOWN, OTHERWISE SAME AS FIG. 1]
"C"
PIN A (SEE TABLE 1)
FIG. 8
PIN A (SEE TABLE 1)
.125 3.18 REF
.120 3.05
C1
.125 3.18 REF
90°
.650 16.51
REF
C2
2 MAX SWAY
(TYP)
.100 2.54 (TYP)
"C"
C4
2 MAX SWAY
(TYP)
C3
C5
.375 9.53
.09 2.3
REF
.16 4.1
(SEE NOTE 9)
((No OF POS -1) x
.100[2.54]) .008[.20]
.100 2.54 (TYP)
SECTION "C"-"C"
-RA IN-PROCESS 1
-RA IN-PROCESS 2
FIG. 9
EJH-110-01-X-D-RA SHOWN
[DIFFERENT AS SHOWN, OTHERWISE SAME AS FIG. 1]
2 MAX SWAY
(TYP)
02
PIN B (SEE TABLE 1)
90°
.225 5.72
REF
.850 21.59
REF
01
.475 12.07
PIN B (SEE TABLE 1)
"F"
90°
PIN A (SEE TABLE 1)
.06 1.5
(SEE NOTES 7 & 9)
.09 2.3 REF
-RA IN-PROCESS 3
.225 5.72
REF
PROPRIETARY NOTE
THIS DOCUMENT CONTAINS INFORMATION
CONFIDENTIAL AND PROPRIETARY TO
SAMTEC, INC. AND SHALL NOT BE REPRODUCED
OR TRANSFERRED TO OTHER DOCUMENTS OR
DISCLOSED TO OTHERS OR USED FOR ANY
PURPOSE OTHER THAN THAT WHICH IT WAS
OBTAINED WITHOUT THE EXPRESSED WRITTEN
CONSENT OF SAMTEC, INC.
"F"
.09 2.3
REF
.06 1.5
(SEE NOTE 9)
.100 2.54
(SEE NOTE 9)
520 PARK EAST BLVD, NEW ALBANY, IN 47150
PHONE: 812-944-6733
FAX: 812-948-5047
e-Mail: info@SAMTEC.com
code: 55322
DESCRIPTION:
DWG. NO.
DO NOT SCALE DRAWING
SHEET SCALE: 1.5:1
.100 x .100 EJECTOR HEADER ASSEMBLY
SECTION "F"-"F"
F:\DWG\MISC\MKTG\EJH-1XX-XX-XX-D-XX-XX-XX-MKT.SLDDRW
BY:
ERIC M.
EJH-1XX-XX-XX-D-XX-XX-XX
09/19/01
SHEET
2
OF
4
REVISION Q
FIG. 2
ARM ASSEMBLY & ROTATION
PPP-50
.390 9.91
-P: PICK & PLACE PAD
FIG. 6
.425 10.80
EHA-03
.665 16.88 REF
.455 11.56
.945 24.00
-K: POLYAMIDE FILM
01
"B"
.385 9.78 REF
01
"B"
"A"
FIG. 3
.475 12.07 REF
C
L
PACKAGING TUBE VIEWS
FIG. 4
SURFACE MOUNT
(SEE NOTE 6)
TUBE: PT-1-24-01-121
PLUG: TP-13
USER DIRECTION OF UN-REELING
POCKET NOT DETAILED
THROUGH HOLE
(SEE NOTE 6)
TUBE: PT-1-24-02-74
PLUG: TP-26
FIG. 5
SECTION "B"-"B"
SCALE 0.75 : 1
FIG. 7
-TR TAPE & REEL PACKAGING
PROPRIETARY NOTE
THIS DOCUMENT CONTAINS INFORMATION
CONFIDENTIAL AND PROPRIETARY TO
SAMTEC, INC. AND SHALL NOT BE REPRODUCED
OR TRANSFERRED TO OTHER DOCUMENTS OR
DISCLOSED TO OTHERS OR USED FOR ANY
PURPOSE OTHER THAN THAT WHICH IT WAS
OBTAINED WITHOUT THE EXPRESSED WRITTEN
CONSENT OF SAMTEC, INC.
TOTAL PARTS PER REEL: 125
RIGHT ANGLE
(SEE NOTE 6)
TUBE: PT-1-24-01-131
PLUG: TP-26
FIG. 10
520 PARK EAST BLVD, NEW ALBANY, IN 47150
PHONE: 812-944-6733
FAX: 812-948-5047
e-Mail: info@SAMTEC.com
code: 55322
DESCRIPTION:
DWG. NO.
DO NOT SCALE DRAWING
SHEET SCALE: 1:0.666667
.100 x .100 EJECTOR HEADER ASSEMBLY
BY:
ERIC M.
EJH-1XX-XX-XX-D-XX-XX-XX
09/19/01
SHEET
3
OF
4
REVISION Q
D
FIG. 11
-02 LEAD STYLE
(SAME AS FIG. 1, UNLESS OTHERWISE STATED)
(EJH-125-02-X-D-SM-LC SHOWN)
(No OF POS X .100) + .815 REF
.458 11.62
EHA-03-EXT
(No OF POS X .100) + .225 REF
EJH-XX-D-EXT
.685 17.39
REF
PROPRIETARY NOTE
THIS DOCUMENT CONTAINS INFORMATION
CONFIDENTIAL AND PROPRIETARY TO
SAMTEC, INC. AND SHALL NOT BE REPRODUCED
OR TRANSFERRED TO OTHER DOCUMENTS OR
DISCLOSED TO OTHERS OR USED FOR ANY
PURPOSE OTHER THAN THAT WHICH IT WAS
OBTAINED WITHOUT THE EXPRESSED WRITTEN
CONSENT OF SAMTEC, INC.
520 PARK EAST BLVD, NEW ALBANY, IN 47150
PHONE: 812-944-6733
FAX: 812-948-5047
e-Mail: info@SAMTEC.com
code: 55322
DESCRIPTION:
DWG. NO.
DO NOT SCALE DRAWING
SHEET SCALE: 2:1
.100 x .100 EJECTOR HEADER ASSEMBLY
F:\DWG\MISC\MKTG\EJH-1XX-XX-XX-D-XX-XX-XX-MKT.SLDDRW
BY:
ERIC M.
EJH-1XX-XX-XX-D-XX-XX-XX
09/19/01
SHEET
4
OF
4
