05067
SM20M05-18
Only One Name Means ProT
ek’Tion™
ST
ANDARD CAPACIT
ANCE TVS ARRA
Y
APPLICA
TIONS
✔
Multiple I/O Port Protection
✔
Board Level Interface Connection
✔
RS-232, RS-422 & RS-423 Data Lines
✔
Portable Electronics
IEC COMPA
TIBILITY
(EN61000-4)
✔
61000-4-2 (ESD): Air - 15kV, Contact - 8kV
✔
61000-4-4 (EFT): 40A - 5/50ns
✔
61000-4-5 (Surge): 24A, 8/20µs - Level 2(Line-Gnd) & Level 3(Line-Line)
FEA
TURES
✔
200 Watts Peak Pulse Power per Line (tp=8/20µs)
✔
ESD Protection > 25 kilovolts
✔
Unidirectional Configuration
✔
Monolithic Design
✔
Protection 18 I/O Lines
MECHANICAL CHARACTERISTICS
✔
Molded JEDEC SO-20WB (Wide Body) Package
✔
Weight 0.6 grams (Approximate)
✔
Flammability rating UL 94V-0
✔
24mm Tape and Reel Per EIA Standard 481
✔
Marking: Logo, Marking Code, Date Code & Pin One Defined By Dot on Top of Package
SO-20L
(WIDE BODY)
PIN CONFIGURA
TION
GND
20
19
18
17
16
15
14
13
12
11
1
2
3
4
5
6
GND
7
8
9
10
05067.R4 9/03
1
www.protekdevices.com
SM20M05-18
PACKAGE OUTLINE & DIMENSIONS
PACKAGE OUTLINE
-A-
SO-20WB
(Wide Body)
20
11
-B-
P
0.010” (0.25 MM)
M
B
M
10 PL
1
10
PACKAGE DIMENSIONS
DIM
A
B
C
J
F
MILLIMETERS
MIN
MAX
12.65
7.40
2.35
0.35
0.50
1.27 BSC
0.25
0.10
10.05
0.25
12.95
7.60
2.65
INCHES
MIN
MAX
0.499
0.292
0.093
0.014
0.020
0.510
0.299
0.104
0.019
0.035
G
C
0º - 7º
-T-
20 PL
0.010” (0.25 MM)
M
T B
S
R X 45º
D
A
S
K
D
F
G
J
K
P
R
NOTES
0.49
0.90
1.27 BSC 0.05 BSC 0.05 BSC
0.010
0.012
0.32
0.004
0.009
0.25
10.55
0.395
0.415
0.029
0.75
0.010
MOUNTING PAD
0.050” TYP
0.030”
±
0.005”
1. - T - = Seating Plane and Datum Surface.
2. Dimensions “A” and “B” are Datum.
3. Dimensions “A” and “B” do not include mold protrusions.
4. Maximum mold protrusion is 0.015” (0.380 mm) per side.
5. Dimensioning and tolerances per ANSI Y14.5M, 1982.
6. Dimensions are exclusive of mold flash and metal burrs.
TAPE & REEL/BULK ORDERING NOMENCLATURE
0.325”
±
0.005”
0.420” MIN
1. Surface mount product is taped and reeled in accordance
with EIA-481.
2. Suffix-T13 = 13 Inch Reel - 1,000 pieces per 24mm tape,
i.e.,
SM20M05-18-T13.
3. No Suffix = Product Shipped in Tubes of 37 pcs per Tube.
0.045”
±
0.005”
Outline & Dimensions: Rev 1 - 11/01, 06018
COPYRIGHT © ProTek Devices 2003
SPECIFICATIONS: ProTek reserves the right to change the electrical and or mechanical
characteristics described herein without notice (except JEDEC).
DESIGN CHANGES: ProTek reserves the right to discontinue product lines without notice, and that
the final judgement concerning selection and specifications is the buyer’s and that in furnishing
engineering and technical assistance, ProTek assumes no responsibility with respect to the
selection or specifications of such products.
ProTek Devices
2929 South Fair Lane, Tempe, AZ 85282
Tel: 602-431-8101 Fax: 602-431-2288
E-Mail:
sales@protekdevices.com
Web Site:
www.protekdevices.com
05067.R4 9/03
4
www.protekdevices.com
