BUK78150-55T/R: DescriptionTRANSISTOR 5.5 A, 55 V, 0.15 ohm, N-CHANNEL, Si, POWER, MOSFET, FET General Purpose Power; CategoryDiscrete semiconductor The transistor; File Size55KB，9 Pages; ManufacturerNXP; Websitehttps://www.nxp.com

Download Datasheet Parametric Compare View All

BUK78150-55T/R Overview

TRANSISTOR 5.5 A, 55 V, 0.15 ohm, N-CHANNEL, Si, POWER, MOSFET, FET General Purpose Power

BUK78150-55T/R Parametric

Parameter Name	Attribute value
package instruction	SMALL OUTLINE, R-PDSO-G4
Reach Compliance Code	unknown
ECCN code	EAR99
Other features	LOGIC LEVEL COMPATIBLE
Avalanche Energy Efficiency Rating (Eas)	15 mJ
Shell connection	DRAIN
Configuration	SINGLE WITH BUILT-IN DIODE
Minimum drain-source breakdown voltage	55 V
Maximum drain current (ID)	5.5 A
Maximum drain-source on-resistance	0.15 Ω
FET technology	METAL-OXIDE SEMICONDUCTOR
JESD-30 code	R-PDSO-G4
Number of components	1
Number of terminals	4
Operating mode	ENHANCEMENT MODE
Package body material	PLASTIC/EPOXY
Package shape	RECTANGULAR
Package form	SMALL OUTLINE
Polarity/channel type	N-CHANNEL
Maximum pulsed drain current (IDM)	30 A
Certification status	Not Qualified
surface mount	YES
Terminal form	GULL WING
Terminal location	DUAL
transistor applications	SWITCHING
Transistor component materials	SILICON
Base Number Matches	1

Preview

Download Datasheet

View All

Philips Semiconductors

Product specification

TrenchMOS™ transistor

Standard level FET

GENERAL DESCRIPTION

N-channel enhancement mode logic

level field-effect power transistor in a

plastic envelope suitable for surface

mounting. Using

’trench’

technology

the device features very low on-state

resistance and has integral zener

diodes giving ESD protection. It is

intended for use in automotive and

general

purpose

switching

applications.

BUK78150-55

QUICK REFERENCE DATA

SYMBOL

tot

DS(ON)

PARAMETER

Drain-source voltage

Drain current

Total power dissipation

Junction temperature

Drain-source on-state

resistance

= 10 V

MAX.

5.5

1.8

150

UNIT

˚C

mΩ

PINNING - SOT223

gate

drain

source

drain (tab)

DESCRIPTION

PIN CONFIGURATION

SYMBOL

LIMITING VALUES

Limiting values in accordance with the Absolute Maximum System (IEC 134)

SYMBOL

DGR

±V

tot

stg

, T

PARAMETER

Drain-source voltage

Drain-gate voltage

Gate-source voltage

Drain current (DC)

Drain current (pulse peak value)

Total power dissipation

Storage & operating temperature

CONDITIONS

= 20 kΩ

= 25 ˚C

On PCB in Fig.19

amb

= 25 ˚C

On PCB in Fig.19

amb

= 100 ˚C

= 25 ˚C

On PCB in Fig.19

amb

= 25 ˚C

MIN.

- 55

MAX.

5.5

2.6

1.6

8.3

1.8

150

UNIT

˚C

ESD LIMITING VALUE

SYMBOL

PARAMETER

Electrostatic discharge capacitor

voltage

CONDITIONS

Human body model

(100 pF, 1.5 kΩ)

MIN.

MAX.

UNIT

January 1998

Rev 1.000
