MC74HC157A
Quad 2-Input Data
Selectors / Multiplexers
High–Performance Silicon–Gate CMOS
The MC74HC157A is identical in pinout to the LS157. The device
inputs are compatible with standard CMOS outputs; with pullup
resistors, they are compatible with LSTTL outputs.
This device routes 2 nibbles (A or B) to a single port (Y) as
determined by the Select input. The data is presented at the outputs in
noninverted form. A high level on the Output Enable input sets all four
Y outputs to a low level.
http://onsemi.com
MARKING
DIAGRAMS
16
16
1
•
•
•
•
•
•
Output Drive Capability: 10 LSTTL Loads
Outputs Directly Interface to CMOS, NMOS, and TTL
Operating Voltage Range: 2.0 to 6.0 V
Low Input Current: 1.0
µA
High Noise Immunity Characteristic of CMOS Devices
In Compliance with the Requirements Defined by JEDEC Standard
No. 7A
•
Chip Complexity: 82 FETs or 20.5 Equivalent Gates
LOGIC DIAGRAM
A0
NIBBLE
A INPUTS
A1
A2
A3
B0
NIBBLE
B INPUTS
B1
B2
B3
2
5
11
14
3
6
10
13
1
15
PIN 16 = VCC
PIN 8 = GND
4
7
9
12
Y0
Y1
Y2
Y3
DATA
OUTPUTS
PDIP–16
N SUFFIX
CASE 648
MC74HC157AN
AWLYYWW
1
16
16
1
SO–16
D SUFFIX
CASE 751B
1
HC157A
AWLYWW
16
TSSOP–16
DT SUFFIX
CASE 948F
1
A
WL
YY
WW
= Assembly Location
= Wafer Lot
= Year
= Work Week
HC
157A
ALYW
16
1
PIN ASSIGNMENT
SELECT
A0
B0
Y0
A1
B1
1
2
3
4
5
6
7
8
16
15
14
13
12
11
10
9
VCC
OUTPUT
ENABLE
A3
B3
Y3
A2
B2
Y2
SELECT
OUTPUT
ENABLE
FUNCTION TABLE
Inputs
Output
Enable
H
L
L
Select
X
L
H
Outputs
Y0 – Y3
L
A0 – A3
B0 – B3
Y1
GND
ORDERING INFORMATION
Device
MC74HC157AN
MC74HC157AD
MC74HC157ADR2
MC74HC157ADT
MC74HC157ADTR2
Package
PDIP–16
SOIC–16
SOIC–16
TSSOP–16
TSSOP–16
Shipping
2000 / Box
48 / Rail
2500 / Reel
96 / Rail
2500 / Reel
X = don’t care
A0 – A3, B0 – B3 = the levels of the
respective Data–Word Inputs.
©
Semiconductor Components Industries, LLC, 2000
1
March, 2000 – Rev. 8
Publication Order Number:
MC74HC157A/D
MC74HC157A
Î Î Î Î Î Î
Î
Î
Î
Î
Î
ÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎ
Î
Î
ÎÎÎ Î Î Î Î
Î Î Î Î Î
Î Î Î Î Î
Î
Î
Î Î
Î
ÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎ
ÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎ
ÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎ
ÎÎÎ Î Î Î Î
Î Î Î Î Î
Î
Î
Î
Î Î
Î
ÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎ
ÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎ
Î Î Î Î
Î
Î Î
ÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎ
Î Î Î Î Î
Î
Î
ÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎ
Î
ÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎ
Î Î Î Î Î
Î Î Î Î Î
Î
Î
Î Î
Î
ÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎ
ÎÎÎÎÎÎÎÎÎÎÎÎ
ÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎ
Î Î Î Î Î
ÎÎÎ Î Î Î Î
Î Î Î Î Î
Î
Î
Î
Î Î
Î
ÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎ
ÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎ
Î Î Î Î
Î
Î Î
ÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎ
Î Î Î Î Î
Î
Î
ÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎ
Î
Î
ÎÎÎ Î Î Î Î
Î Î Î Î Î
Î Î Î Î Î
Î
Î
Î Î
Î
ÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎ
ÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎ
ÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎ
Î
Î
ÎÎÎ Î Î Î Î
Î Î Î Î Î
Î
Î
Î
Î
Î Î
Î
ÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎ
ÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎ
ÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎ
Î Î Î Î Î
Î
Î Î
ÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎ
Î Î Î Î Î
ÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎ
Î Î Î Î Î
Î
Î
ÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎ
ÎÎÎÎÎÎÎÎÎ Î
Î
Î
Î
ÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎ
ÎÎÎ Î
ÎÎ
Î
Î
ÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎ
Î Î
ÎÎÎÎ
Î Î
ÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎ
Î
ÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎ
ÎÎ Î
ÎÎÎÎ Î
ÎÎ Î
Î
ÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎ
ÎÎ Î
Î
ÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎ
ÎÎ Î
Î
ÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎ
ÎÎ Î
Î
ÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎ
ÎÎ Î
Î
ÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎ
ÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎ
Î
ÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎ
ÎÎ Î
Î Î
Î
ÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎ
ÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎ
Î Î
Î
ÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎ
Î Î
Î
ÎÎÎÎ
Î Î
Î
Î
ÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎ
Î Î Î
Î
ÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎ
ÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎ
Î Î
Î Î
Î
Î
Î
ÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎ
ÎÎÎÎ
ÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎ
ÎÎ Î
Î Î
Î
ÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎ
Î Î
ÎÎÎ
Î Î
Î
ÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎ
Î Î
Î
ÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎ
Î Î
Î
ÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎ
Î Î
Î
ÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎ
Î Î
Î
ÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎ
Î Î
Î
ÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎ
Î Î
Î
ÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎ
Î Î
Î
ÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎ
Î Î
Î
ÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎ
Î Î
Î
ÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎ
Î Î
Î
ÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎ
ÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎ
Î
ÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎ
Î Î
Î
Î
ÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎ
ÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎ
ÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎ
Î
Î
ÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎ
MAXIMUM RATINGS*
Symbol
VCC
Vin
Parameter
Value
Unit
V
V
V
DC Supply Voltage (Referenced to GND)
DC Input Voltage (Referenced to GND)
– 0.5 to + 7.0
– 0.5 to VCC + 0.5
– 0.5 to VCC + 0.5
±
20
±
25
±
50
750
500
450
Vout
Iin
DC Output Voltage (Referenced to GND)
DC Input Current, per Pin
mA
mA
mA
Iout
DC Output Current, per Pin
ICC
PD
DC Supply Current, VCC and GND Pins
Power Dissipation in Still Air,
Plastic DIP†
SOIC Package†
TSSOP Package†
mW
Tstg
TL
Storage Temperature
– 65 to + 150
260
This device contains protection
circuitry to guard against damage
due to high static voltages or electric
fields. However, precautions must
be taken to avoid applications of any
voltage higher than maximum rated
voltages to this high–impedance cir-
cuit. For proper operation, Vin and
Vout should be constrained to the
range GND (Vin or Vout) VCC.
Unused inputs must always be
tied to an appropriate logic voltage
level (e.g., either GND or VCC).
Unused outputs must be left open.
v
v
_
C
_
C
Lead Temperature, 1 mm from Case for 10 Seconds
(Plastic DIP, SOIC or TSSOP Package)
*Maximum Ratings are those values beyond which damage to the device may occur.
Functional operation should be restricted to the Recommended Operating Conditions.
†Derating — Plastic DIP: – 10 mW/
_
C from 65
_
to 125
_
C
SOIC Package: – 7 mW/
_
C from 65
_
to 125
_
C
TSSOP Package: – 6.1 mW/
_
C from 65
_
to 125
_
C
For high frequency or heavy load considerations, see Chapter 2 of the ON Semiconductor High–Speed CMOS Data Book (DL129/D).
RECOMMENDED OPERATING CONDITIONS
Symbol
VCC
Parameter
Min
2.0
0
Max
6.0
Unit
V
V
DC Supply Voltage (Referenced to GND)
DC Input Voltage, Output Voltage
(Referenced to GND)
Vin, Vout
TA
VCC
Operating Temperature, All Package Types
Input Rise and Fall Time
(Figure 1)
– 55
0
0
0
+ 125
1000
500
400
_
C
ns
tr, tf
VCC = 2.0 V
VCC = 4.5 V
VCC = 6.0 V
DC ELECTRICAL CHARACTERISTICS
(Voltages Referenced to GND)
Guaranteed Limit
Symbol
VIH
Parameter
Test Conditions
VCC
V
2.0
3.0
4.5
6.0
2.0
3.0
4.5
6.0
2.0
4.5
6.0
3.0
4.5
6.0
2.0
4.5
6.0
3.0
4.5
6.0
– 55 to
25
_
C
1.5
2.1
3.15
4.2
0.5
0.9
1.35
1.8
1.9
4.4
5.9
v
85
_
C
v
125
_
C
1.5
2.1
3.15
4.2
0.5
0.9
1.35
1.8
1.9
4.4
5.9
1.5
2.1
3.15
4.2
0.5
0.9
1.35
1.8
1.9
4.4
5.9
2.2
3.7
5.2
0.1
0.1
0.1
0.4
0.4
0.4
Unit
V
Minimum High–Level Input
Voltage
Vout = VCC – 0.1 V
|Iout|
20
µA
v
v
v
VIL
Maximum Low–Level Input
Voltage
Vout = 0.1 V
|Iout|
20
µA
V
VOH
Minimum High–Level Output
Voltage
Vin = VIH
|Iout|
20
µA
Vin = VIH
V
|Iout|
|Iout|
|Iout|
v
2.4 mA
v
6.0 mA
v
7.8 mA
v
2.4 mA
v
6.0 mA
v
7.8 mA
2.48
3.98
5.48
0.1
0.1
0.1
2.34
3.84
5.34
0.1
0.1
0.1
VOL
Maximum Low–Level Output
Voltage
Vin = VIL
|Iout|
20
µA
v
V
Vin = VIL
|Iout|
|Iout|
|Iout|
0.26
0.26
0.26
0.33
0.33
0.33
http://onsemi.com
2
MC74HC157A
DC ELECTRICAL CHARACTERISTICS
(Voltages Referenced to GND)
Î Î
Î
ÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎ
Î Î Î Î Î
Î
Î
Î
ÎÎÎ Î Î Î Î
ÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎ
Î Î Î Î
Î Î
ÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎ
Î Î Î Î Î
Î
ÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎ
ÎÎÎ Î Î Î Î
Î Î Î Î Î
Î
Î Î
Î
ÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎ
ÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎ
Î Î Î Î
Î Î
ÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎ
Î Î Î Î Î
Î
ÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎ
ÎÎÎ Î Î Î Î
Î Î Î Î Î
Î Î
Î Î
Î
ÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎ
ÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎ
Î Î Î Î
Î Î Î
Î Î
ÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎ
Î
ÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎ
ÎÎÎ Î Î Î Î
Î Î Î Î Î
Î
Î Î
Î
ÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎ
ÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎ
Î Î
ÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎ
ÎÎ Î Î Î Î
Î Î Î Î Î
Î
ÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎ
Î
Î
ÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎ
Î Î Î Î Î
ÎÎÎ Î Î Î Î
Î Î Î Î Î
Î
ÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎ
ÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎ
Î
ÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎ
Î Î Î Î Î
Î Î
Î
ÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎ
ÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎ
Î Î
Î
Î Î Î Î Î Î
Î
Î
Î
Î
Î
ÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎ
ÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎ Î
Î Î Î Î Î
Î Î Î Î Î
Î
Î
Î
Î
ÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎ
ÎÎÎÎ
ÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎ
Î Î Î Î Î
Î
Î
ÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎ
Î Î Î Î Î
Î Î Î Î Î
Î
Î
Î
Î
ÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎ
ÎÎÎÎÎÎÎÎÎÎÎÎ
ÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎ
ÎÎ Î Î Î Î
Î
Î
Î
ÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎ
Î Î Î Î Î
ÎÎÎ Î Î Î Î
Î Î Î Î Î
Î
Î
ÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎ
ÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎ
Î
Î
ÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎ
Î Î Î Î Î
Î Î
Î
Î
ÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎ
ÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎÎ
Î Î
Î
Î
Guaranteed Limit
Symbol
Iin
Parameter
Test Conditions
VCC
V
6.0
6.0
– 55 to
25
_
C
±
0.1
±
0.5
v
85
_
C
v
125
_
C
±
1.0
±
5.0
±
1.0
±
10
Unit
µA
µA
Maximum Input Leakage
Current
Maximum Three–State
Leakage Current
Vin = VCC or GND
IOZ
ICC
Maximum Quiescent Supply
Current (per Package)
Output in High–Impedance State
Vin = VIL or VIH
Vout = VCC or GND
Vin = VCC or GND
Iout = 0
µA
6.0
4.0
40
160
µA
NOTE: Information on typical parametric values can be found in Chapter 2 of the ON Semiconductor High–Speed CMOS Data Book
(DL129/D).
AC ELECTRICAL CHARACTERISTICS
(CL = 50 pF, Input tr = tf = 6.0 ns)
Guaranteed Limit
Symbol
tPLH,
tPHL
Parameter
VCC
V
2.0
3.0
4.5
6.0
2.0
3.0
4.5
6.0
2.0
3.0
4.5
6.0
2.0
3.0
4.5
6.0
—
– 55 to
25
_
C
105
65
21
18
110
70
22
19
v
85
_
C
v
125
_
C
130
85
26
22
140
90
28
24
125
80
25
21
95
32
19
16
10
160
115
32
27
165
115
33
28
150
110
30
26
110
36
22
19
10
Unit
ns
Maximum Propagation Delay, Input A or B to Output Y
(Figures 1 and 4)
tPLH,
tPHL
Maximum Propagation Delay, Select to Output Y
(Figures 2 and 4)
ns
tPLH,
tPHL
Maximum Propagation Delay, Output Enable to Output Y
(Figures 3 and 4)
100
60
20
17
75
27
15
13
10
ns
tTLH,
tTHL
Maximum Output Transition Time, Any Output
(Figures 1 and 4)
ns
Cin
Maximum Input Capacitance
pF
NOTE: For propagation delays with loads other than 50 pF, and information on typical parametric values, see Chapter 2 of the ON
Semiconductor High–Speed CMOS Data Book (DL129/D).
Typical @ 25°C, VCC = 5.0 V
33
CPD
Power Dissipation Capacitance (Per Package)*
pF
* Used to determine the no–load dynamic power consumption: P D = C PD V CC 2 f + I CC V CC . For load considerations, see Chapter 2 of the
ON Semiconductor High–Speed CMOS Data Book (DL129/D).
http://onsemi.com
3
MC74HC157A
PIN DESCRIPTIONS
INPUTS
A0, A1, A2, A3 (Pins 2, 5, 11, 14)
Nibble A inputs. The data present on these pins is
transferred to the outputs when the Select input is at a low
level and the Output Enable input is at a low level. The data
is presented to the outputs in noninverted form.
B0, B1, B2, B3 (Pins 3, 6, 10, 13)
The data present on these pins is in its noninverted form. For
the Output Enable input at a high level, the outputs are at a
low level.
CONTROL INPUTS
Select (Pin 1)
Nibble B inputs. The data present on these pins is
transferred to the outputs when the Select input is at a high
level and the Output Enable input is at a low level. The data
is presented to the outputs in noninverted form.
OUTPUTS
Y0, Y1, Y2, Y3 (Pins 4, 7, 9, 12)
Nibble select. This input determines the data word to be
transferred to the outputs. A low level on this input selects
the A inputs and a high level selects the B inputs.
Output Enable (Pin 15)
Output Enable input. A low level on this input allows the
selected input data to be presented at the outputs. A high
level on this input sets all outputs to a low level.
Data outputs. The selected input Nibble is presented at
these outputs when the Output Enable input is at a low level.
SWITCHING WAVEFORMS
tr
INPUT A OR B
tPLH
OUTPUT Y
tTLH
90%
50%
10%
tTHL
90%
50%
10%
tPHL
tf
tr
VCC
SELECT
GND
tPLH
OUTPUT Y
90%
50%
10%
tTLH
tTHL
90%
50%
10%
tPHL
tf
VCC
GND
Figure 1. HC157A
tr
OUTPUT
ENABLE
tPHL
OUTPUT Y
tTHL
90%
50%
10%
90%
50%
10%
tf
Figure 2. Y versus Select, Noninverted
VCC
GND
tPLH
tTLH
Figure 3. HC157A
TEST POINT
OUTPUT
DEVICE
UNDER
TEST
CL*
*Includes all probe and jig capacitance
Figure 4. Test Circuit
http://onsemi.com
4
MC74HC157A
EXPANDED LOGIC DIAGRAM
2
A0
B0
A1
B1
NIBBLE
OUTPUTS
A2
B2
A3
B3
OUTPUT ENABLE
SELECT
10
14
13
15
1
12 Y3
9
Y2
3
5
6
11
7
Y1
DATA
OUTPUTS
4
Y0
http://onsemi.com
5
