STANDARD SPECIFICATIONS
Parameter
Center Frequency (MHz):
Frequency Range (MHz):
Tuning Voltage Range (Vdc):
Tuning Sensitivity (MHz/V):
Tuning Slope:
Supply Voltage (Vdc):
Input Current (mA):
Output Level (dBm):
Pushing (kHz):
Harmonics (dBc):
Phase Noise (dBc/Hz):
Output Load Impedance (Ohms):
Operating Temperature Range (°C):
Storage Temperature Range (°C):
Condition
-
Vcc=3.0Vdc, Vt=0.5Vdc
Vcc=3.0Vdc, Vt=2.5Vdc
-
Vt=0.5Vdc to 2.5Vdc
-
-
-
-
Vcc=3.0Vdc ±0.15Vdc
Vcc=3.0Vdc
at 10kHz Offset, Vcc=3.0Vdc, Vt=1.4Vdc
-
-
-
Minimum
-
-
739.0
0.5
10.0
-
2.835
-
-2.0
-1500.0
-
-
-
-30
-40
Typical
729.0
-
-
1.4
12.0
Positive
3.000
-
0.0
-
-
-
50.0
25
25
Maximum
-
719.0
-
2.5
-
-
3.165
20.0
2.0
1500.0
-15.0
-100.0
-
75
85
Comments:
Unless otherwise specified, all of the above specifications are under the following conditions:
Operating Temperature = -30°C to +75°C, Vcc = 3.00Vdc ±0.05Vdc, Vt = 1.4Vdc, Output Load = 50 Ohms
MECHANICAL DIMENSIONS
12.70
±0.25
15 14
2.80
±0.51
13
12
11
10
9
5
6
7
10.0
±0.1
8
1.90
MAX
0.99
MAX
1.05
±0.05
1.50
±0.05
(x4)
ALL DIMENSIONS
IN MILLIMETERS
16
1
12.70 10.0 2
±0.25 ±0.1
3
4
1.65
±0.05
2.56 ±0.08 (x12)
1.05
±0.05
3.60
±0.05
Pin
1
2
3-9
10
11-13
14
15-16
Function
Ground
Vt
Ground
RF Out
Ground
Vcc
Ground
MARKING GUIDE
(Line #1)
AVAR0046
(Line #2)
XX Y ZZ
Week of the Year
Last Digit of the Year
Amplitronix Manufacturing Code
Part Number:
AVAR0046
3545-B Cadillac Avenue Costa Mesa, CA 92626-1401 (714) 918-4752 Fax (714) 918-4760
