MOTOROLA
SEMICONDUCTOR TECHNICAL DATA
Octal 3-State Noninverting
Bus Transceiver with
LSTTL Compatible Inputs
High–Performance Silicon–Gate CMOS
The MC54/74HCT245A is identical in pinout to the LS245. This device
may be used as a level converter for interfacing TTL or NMOS outputs to
High Speed CMOS inputs.
The MC54/74HCT245A is a 3–state noninverting transceiver that is
used for 2–way asynchronous communication between data buses. The
device has an active–low Output Enable pin, which is used to place the
I/O ports into high–impedance states. The Direction control determines
whether data flows from A to B or from B to A.
•
•
•
•
•
•
Output Drive Capability: 15 LSTTL Loads
TTL/NMOS Compatible Input Levels
Outputs Directly Interface to CMOS, NMOS and TTL
Operating Voltage Range: 4.5 to 5.5 V
Low Input Current: 1.0
µA
In Compliance with the Requirements Defined by JEDEC Standard
No. 7A
•
Chip Complexity: 304 FETs or 76 Equivalent Gates
LOGIC DIAGRAM
A1
A2
A3
A
DATA
PORT
A4
A5
A6
A7
A8
DIRECTION
OUTPUT ENABLE
2
3
4
5
6
7
8
9
1
19
18
17
16
15
14
13
12
11
B1
B2
B3
B4
B5
B6
B7
B8
B
DATA
PORT
MC54/74HCT245A
J SUFFIX
CERAMIC PACKAGE
CASE 732–03
1
20
20
1
20
1
N SUFFIX
PLASTIC PACKAGE
CASE 738–03
DW SUFFIX
SOIC PACKAGE
CASE 751D–04
SD SUFFIX
SSOP PACKAGE
CASE 940C–03
DT SUFFIX
TSSOP PACKAGE
CASE 948E–02
20
1
20
1
ORDERING INFORMATION
Ceramic
MC54HCTXXXAJ
Plastic
MC74HCTXXXAN
SOIC
MC74HCTXXXADW
SSOP
MC74HCTXXXASD
TSSOP
MC74HCTXXXADT
PIN ASSIGNMENT
DIRECTION
A1
A2
A3
A4
1
2
3
4
5
6
7
8
9
10
20
19
18
17
16
15
14
13
12
11
VCC
OUTPUT ENABLE
B1
B2
B3
B4
B5
B6
B7
B8
PIN 20 = VCC
PIN 10 = GND
A5
A6
A7
A8
GND
ÎÎÎÎÎÎÎÎÎÎÎÎÎ
Î Î
Î Î
Î
ÎÎÎÎÎÎÎÎÎÎÎÎÎ
Î Î Î
Î Î
ÎÎÎÎÎÎÎÎÎÎÎÎÎ
ÎÎÎÎÎÎÎÎÎÎÎÎÎ
Î Î
ÎÎÎÎÎÎÎÎÎÎÎÎÎ
Î Î
ÎÎÎÎÎÎÎÎÎÎÎÎÎ
Î Î
ÎÎÎÎÎÎÎÎÎÎÎÎÎ
ÎÎ Î
Î Î
Î Î
Î
Î
ÎÎÎÎÎÎÎÎÎÎÎÎÎ
ÎÎÎÎÎÎÎÎÎÎÎÎÎ
ÎÎÎÎÎÎÎÎÎÎÎÎ
Î Î
Î
ÎÎÎÎÎÎÎÎÎÎÎÎÎ
ÎÎÎÎÎÎÎÎÎÎ
Design Criteria
Value
76
Units
ea
ns
Internal Gate Count*
Internal Gate Propagation Delay
Internal Gate Power Dissipation
Speed Power Product
1.0
5.0
µW
pJ
0.005
* Equivalent to a two–input NAND gate.
2/97
FUNCTION TABLE
Control Inputs
Output
Enable
L
L
H
X = Don’t Care
Direction
L
H
X
Operation
O
i
Data Transmitted from Bus B to Bus A
Data Transmitted from Bus A to Bus B
Buses Isolated (High–Impedance State)
©
Motorola, Inc. 1997
3–1
REV 7
MC54/74HCT245A
