PWR-82341-360 Overview

Brushless DC Motor Controller, 10A, Hybrid, 1.8 X 1.4 INCH, 0.25 INCH HEIGHT, PACKAGE-34

PWR-82341-360 Parametric

Parameter Name	Attribute value
Is it lead-free?	Contains lead
Is it Rohs certified?	incompatible
Maker	Data Device Corporation
Parts packaging code	DIP
package instruction	1.8 X 1.4 INCH, 0.25 INCH HEIGHT, PACKAGE-34
Contacts	34
Reach Compliance Code	compliant
ECCN code	EAR99
Other features	DRIVE BRUSH OR BRUSHLESS DC MOTORS
Analog Integrated Circuits - Other Types	BRUSHLESS DC MOTOR CONTROLLER
JESD-30 code	R-XDIP-P34
JESD-609 code	e0
length	45.72 mm
Number of functions	1
Number of terminals	34
Maximum operating temperature	70 °C
Minimum operating temperature
Maximum output current	10 A
Package body material	UNSPECIFIED
encapsulated code	DIP
Package shape	RECTANGULAR
Package form	IN-LINE
Peak Reflow Temperature (Celsius)	NOT SPECIFIED
Certification status	Not Qualified
Filter level	MIL-STD-883
Maximum seat height	6.35 mm
Maximum supply voltage (Vsup)	100 V
Nominal supply voltage (Vsup)	28 V
surface mount	NO
technology	HYBRID
Temperature level	COMMERCIAL
Terminal surface	TIN LEAD
Terminal form	PIN/PEG
Terminal pitch	2.54 mm
Terminal location	DUAL
Maximum time at peak reflow temperature	NOT SPECIFIED
width	30.48 mm
Base Number Matches	1

Preview

Download Datasheet

View All

PWR-82341

SMART POWER H-BRIDGE MOTOR

DRIVE

FEATURES

Make sure the next

Card you purchase

has...

•Small size (1.8" x 1.4" x 0.25")

•100 Vdc Rating

•5 A Continuous, 10 A peak

Capability

•High-Efficiency MOSFET Drive

Stage

•Direct Drive from PWM

•Drive Brush or Brushless DC

Motors

•Four Quadrant Operation

DESCRIPTION

The PWR-82341 is a smart Power H-Bridge Motor Drive hybrid. The PWR-

82341 uses a MOSFET output stage with a 100Vdc rating, and can deliver

5 A continuous, 10 A peak current to the load.

This Smart Power Motor Drive has CMOS Schmitt Trigger inputs for high

noise immunity. High and low-side input logic signals are XOR’d in each

phase to prevent simultaneous turn on of in-line transistors, thus eliminating

a shoot through condition.

The internal logic controls the high and low-side gate drivers for each phase

and can operate from +5 to +15 V logic levels. An internal charge pump cir-

cuit provides the required voltage to the high-side gate drives. This ensures

constant output performance for switching frequencies from DC to 50 kHz.

APPLICATIONS

Packaged in a small case, these hybrids are an excellent choice for high per-

formance, high-reliability motor drives for Military and Aerospace servo-amps

and speed controls.

Among the many applications are robotics; electro-mechanical valve assem-

blies; actuator systems; antenna and radar positioning; fan and blower

motors for environmental conditioning; position control of mini-subs, drones,

and RPV’s; and compressor motors for cryogenic coolers.

The PWR-82341 hybrid is ideal for harsh military environments where shock,

vibration, and temperature extremes are evident, such as missile applications

including fin actuators and I. seeker head movement. The PWR-82341 oper-

ates over the -55°C to +125°C temperature range.

FOR MORE INFORMATION CONTACT:

Data Device Corporation

105 Wilbur Place

Bohemia, New York 11716

631-567-5600 Fax: 631-567-7358

www.ddc-web.com

Technical Support:

1-800-DDC-5757 ext. 7771
