Bussmann
®
Class G Fuseblocks
For Bussmann SC Fuses
600 Volt AC, 0 - 20 Amp
480 Volt AC, 25 - 60 Amp
Dimensional Data
1 to 30A
BG Series
and
G Series
All other dimensions (±0.015)
1.53"
1.22"
0.36"
0.425"
0.425"
.360"
3"
(±0.031)
1.5"
.200"
±.003
0.86"
.765"
1.63"
2.38"
.169
≈
.210
TYP. 2"
Catalog Symbol:
BG Series and G Series
Class G Fuseblocks
Ampere Rating:
0-20 Amperes, 600VAC OR LESS
25-60 Amperes, 480 VAC OR LESS
Withstand Rating:
100,000 Amps RMS Sym.
Agency Approvals:
1-30A: U.L. Recognized, U.L. 512, Guide IZLT2, File E14853
35-60A: U.L. Listed, U.L. 512, Guide IZLT, File E14853
CSA Certified, C22.2 No. 39, Class 6225-01; File 47235
For use with Class G Fuses (Bussmann SC)
Temperature Rating (RTI):
BG Series:
130°C
G Series:
150°C
Material:
(1-30) Thermoplastic
(35-60) Phenolic
Catalog Data
Terminal Type
Screw with
Quick-Connect*
BG3011SQ
BG3012SQ
BG3013SQ
BG3021SQ
BG3022SQ
BG3023SQ
BG3031S
Poles
Pressure Plate
w/Quick Connect*
BG3011PQ
BG3012PQ
BG3013PQ
BG3021PQ
BG3022PQ
BG3023PQ
BG3031P
BG3032P
BG3033P
—
—
—
Box
Lug
BG3011B
BG3012B
BG3013B
BG3021B
BG3022B
BG3023B
BG3031B
BG3032B
BG3033B
—
Box Lug
w/Clip
—
—
—
—
—
—
—
—
—
G30060-1CR
Fig.
No.
1
2
3
1
2
3
1
2
3
4
5
6
Figure 1.
Figure 2.
Figure 3.
35 to 60A
1.38"
0.22"
0.5"
0.47"
0.84"
0.29" DIAMETER
0.38" C'BORE
4.25"
2.125"
0.94"
Figure 4.
1.69"
1.78"
Figure 5.
Amps
1
1
to
2
15
3
1
20
2
3
25
1
to
30
35
to
60
1.41"
0.53"
0.22" DIAMETER
HOLE
3.56"
2 BG3032S
3 BG3033S
1
—
2
3
—
—
—
G30060-2CR
G30060-3C G30060-3CR
1.78"
* QUICK CONNECT ONLY RATED FOR 20A.
2.75"
CE logo denotes compliance with European Union Low Voltage Directive
(50-1000 Vac, 75-1500 Vdc). Refer to BIF document #8002 or contact
Bussmann Application Engineering at 636-527-1270 for more information.
Figure 6.
The only controlled copy of this BIF document is the electronic read-only version located on the Bussmann Network Drive. All other copies of this document are by definition uncontrolled. This bulletin
is intended to clearly present comprehensive product data and provide technical information that will help the end user with design applications. Bussmann reserves the right, without notice, to change
design or construction of any products and to discontinue or limit distribution of any products. Bussmann also reserves the right to change or update, without notice, any technical information con-
tained in this bulletin. Once a product has been selected, it should be tested by the user in all possible applications.
1-18-00
N99230
Rev. A
Form No. BG Series
Page 1 of 1
BIF Doc #1106
