AMEL5-277NZ
Preliminary
AC-DC Converter
Click to
AMEL5-277NZ
ORDER
samples
The new AMEL5-277NZ is an AC/DC converter that offers much greater cost
effectiveness due to increased production automation, leading to improved
reliability and performance. Offering a wide industrial input voltage range of 85-
305VAC and an output voltage range from 3.3-24V, this series will offer many
benefits to your new system design.
This new series offers great operating temperatures, from -40℃ to 70℃ and
isolation of 4000VAC for improved reliability and system safety. Furthermore, a high
MTBF of 300,000h, output short circuit protection (OSCP), output over-current
protection (OCP) and an output over-voltage protection (OVP) come standard with
the series.
The AMEL5-277NZ is perfect for street lighting controls, grid power,
instrumentation, industrial controls, telecom and civil applications.
Picture coming soon
Encapsulated
Features
•
•
•
•
•
•
Universal Input: 85 - 305VAC/100 - 430VDC
Operating Temp: -40 °C to +70 °C
High isolation voltage: 4000VAC
Low ripple & noise, 100mV(p-p), max.
Output short circuit, over-current, over-voltage
protection
Regulated Output
Summary
528
48
AMEL5-277NZ
60
4000
85
85
305
24
1000
3.3
5.5
4.2
1
70
85
85
0
-25
-40
-40
Input voltage Output voltage
(VAC)
(V)
Isolation
(VAC)
Power
(W)
Temp. range
(℃)
Derating
(℃)
Training
Applications
Press Release
Coming Soon!
Power Grid
Product Training Video
(click to open)
Application Notes
Industrial
Telecom
Instrumentation
F 052e R4
www.Aimtec.com
1
AMEL5-277NZ
Preliminary
General Specifications
Parameters
Over Current protection
Over voltage protection
Short circuit protection
Switching Frequency
Operating temperature
Storage temperature
Power derating
Conditions
Typical
Maximum
Units
AC-DC Converter
Soldering temperature
Temperature coefficient
Protection Class
Cooling
Storage Humidity
Case material
Weight
Dimensions (L x W x H)
MTBF
Self- recovery
≥
110
% of Iout
3.3V / 5V Output
≤ 7.5
9V Output
≤
15
Zener diode clamp
VDC
12V / 15V Output
≤ 20
24V Output
≤ 30
Hiccup, Continuous, Self-recovery
100
KHz
o
-40 to +70
C
o
-40 to +85
C
o
o
-40 C ~ -25 C
2.67
% /
o
C
o
o
55 C ~ 70 C
2.67
85 ~ 100 VAC
1
% / VAC
277 ~ 305 VAC
0.54
Wave-soldering
260 ± 5
o
C ; 5 ~ 10 sec
Manual-welding
360 ± 10
o
C ; 3 ~ 5 sec
±0.02
% /
o
C
Class II
Free air convection
95
% RH
Heat resistant black Plastic (flammability to UL 94V-0)
PCB mountable models
31
With optional -ST mounting plate
52
g
With optional -STD mounting plate
70
PCB mountable models
2.00 x 1.00 x 0.60 inches (50.80 x 25.40 x 15.36mm)
With optional -ST mounting plate
2.99 x 1.24 x 0.95 inches (76.00 x 31.50 x 24.16mm)
With optional -STD mounting plate
2.99 x 1.24 x 1.13 inches (76.00 x 31.50 x 28.76mm)
> 300 000 hrs (MIL-HDBK -217F, t=+25
o
C)/Full Load
NOTE: All specifications in this datasheet are measured at an ambient temperature of 25°C, humidity<75%, nominal input voltage and at rated
output load unless otherwise specified.
Safety Specifications
Parameters
Designed to meet IEC/EN/UL 62368
EMC - Conducted and radiated emission
Electrostatic Discharge Immunity
RF, Electromagnetic Field Immunity
Electrical Fast Transient/Burst Immunity
Standards
CISPR32 / EN55032, class B
IEC 61000-4-2 Contact ±6KV, Air ±8KV, Criteria B
IEC 61000-4-3 10V/m, Criteria A
IEC 61000-4-4 ±2KV, with typical application circuit,
Criteria B
IEC 61000-4-4 ±4KV, with EMC recommended circuit,
Criteria B
IEC 61000-4-5 L-L ±1KV, with typical application circuit
Criteria B
IEC 61000-4-5 L-L ±2KV/ L-G ±4KV, with EMC
recommended circuit, Criteria B
IEC 61000-4-6 10Vr.m.s, Criteria A
IEC 61000-4-11 0%, 70%, Criteria B
Surge Immunity
CS, Conducted Disturbance Immunity
Voltage dips, Short Interruptions Immunity
F 052e R4
www.Aimtec.com
3
