54F113FM

Description
J-K Flip-Flop, 2-Func, Negative Edge Triggered, TTL, CDFP14,
Categorylogic    logic
File Size222KB,6 Pages
ManufacturerFairchild
Websitehttp://www.fairchildsemi.com/
Download Datasheet Parametric Compare View All

54F113FM Overview

J-K Flip-Flop, 2-Func, Negative Edge Triggered, TTL, CDFP14,

54F113FM Parametric

Parameter NameAttribute value
Is it Rohs certified?incompatible
package instructionDFP, FL14,.3
Reach Compliance Codecompliant
JESD-30 codeR-XDFP-F14
JESD-609 codee0
Logic integrated circuit typeJ-K FLIP-FLOP
Number of functions2
Number of terminals14
Maximum operating temperature125 °C
Minimum operating temperature-55 °C
Package body materialCERAMIC
encapsulated codeDFP
Encapsulate equivalent codeFL14,.3
Package shapeRECTANGULAR
Package formFLATPACK
power supply5 V
Certification statusNot Qualified
Nominal supply voltage (Vsup)5 V
surface mountYES
technologyTTL
Temperature levelMILITARY
Terminal surfaceTin/Lead (Sn/Pb)
Terminal formFLAT
Terminal pitch1.27 mm
Terminal locationDUAL
Trigger typeNEGATIVE EDGE
Base Number Matches1

54F113FM Related Products

54F113FM 74F113DCQM 74F113PCQM
Description J-K Flip-Flop, 2-Func, Negative Edge Triggered, TTL, CDFP14, J-K Flip-Flop, 2-Func, Negative Edge Triggered, TTL, CDIP14, J-K Flip-Flop, 2-Func, Negative Edge Triggered, TTL, PDIP14,
Is it Rohs certified? incompatible incompatible incompatible
package instruction DFP, FL14,.3 DIP, DIP14,.3 DIP, DIP14,.3
Reach Compliance Code compliant compliant compliant
JESD-30 code R-XDFP-F14 R-XDIP-T14 R-PDIP-T14
JESD-609 code e0 e0 e0
Logic integrated circuit type J-K FLIP-FLOP J-K FLIP-FLOP J-K FLIP-FLOP
Number of functions 2 2 2
Number of terminals 14 14 14
Maximum operating temperature 125 °C 70 °C 70 °C
Package body material CERAMIC CERAMIC PLASTIC/EPOXY
encapsulated code DFP DIP DIP
Encapsulate equivalent code FL14,.3 DIP14,.3 DIP14,.3
Package shape RECTANGULAR RECTANGULAR RECTANGULAR
Package form FLATPACK IN-LINE IN-LINE
power supply 5 V 5 V 5 V
Certification status Not Qualified Not Qualified Not Qualified
Nominal supply voltage (Vsup) 5 V 5 V 5 V
surface mount YES NO NO
technology TTL TTL TTL
Temperature level MILITARY COMMERCIAL COMMERCIAL
Terminal surface Tin/Lead (Sn/Pb) Tin/Lead (Sn/Pb) Tin/Lead (Sn/Pb)
Terminal form FLAT THROUGH-HOLE THROUGH-HOLE
Terminal pitch 1.27 mm 2.54 mm 2.54 mm
Terminal location DUAL DUAL DUAL
Trigger type NEGATIVE EDGE NEGATIVE EDGE NEGATIVE EDGE
Base Number Matches 1 1 1
Is it lead-free? - Contains lead Contains lead
Maker - Fairchild Fairchild
Peak Reflow Temperature (Celsius) - NOT SPECIFIED NOT SPECIFIED
Maximum time at peak reflow temperature - NOT SPECIFIED NOT SPECIFIED
