PCB relays
20 A class
Micro power relay K SMD
Powertrain
Systems
Chassis
Systems
Safety
Security
Body
Driver
Information
Convenience
Features
- Smallest power relay with
surface mounted technology
- Minimal weight
(0.14 oz. / 4 g)
- Maximum continuous
current 30 A
- SMD-terminals designed for
convection and infrared
reflow
Typical applications
- Rear window and seat
heating
- Wiper and indicator control
- Lamp load
- Motor management
Car Industry
Truck
Industry
Other
Industry
86_3d06
Design
Sealed;
sealed version:
sealing in accordance with
IEC 68;
immersion cleanable:
protection class IP67 to
IEC 529 (EN 60 529)
Conditions
All parametric, environmental and
endurance tests are performed
according to EIA Standard RS-407-A
at standard test conditions unless
otherwise noted:
23 °C ambient temperature,
20-50% RH, 29.5 ± 1.0" Hg
(998.9 ±33.9 hPa).
Weight
Approx. 0.14 oz. (4 g)
Nominal voltage
10, 12 V
other nominal voltages on request
Terminals
PCB/SMD terminals, for assembling
in printed circuit boards
474
All specifications subject to change. Consult Tyco Electronics AMP GmbH for latest specifications.
PCB relays
20 A class
Micro power relay K SMD
Dimensional drawing
12
±
0.1
5,8
2,5
0,6
±
0.2
±
0.2
±
0.1
±
0.1 3x*)
0,7
12,9
0,95
±
0.2
±
0.2
7,65
A
±
0.2
±
0.1
±
0.1 2x*)
0.1
0,4
At terminal tip
*) Dimension without soldering
86esw_se
View of the terminals
(Bottom view)
3x 1,3
3,06
C
1,5
+0,05
0
11,3
8,5
1,56
0,65
3,06
B
4
3,36
4x
0,4
0,2
M A B
M A
1
4x
0,4
0,2
M A C
M A
5
1,5
4,06
+0,05
0
6,01
16
1,5
0,4
0,2
M A C
M A
4,09
0,4
0,3
M A B
M A
2
2x0,8
1,8
3
±
0.2
7,5
86esw_an
Remark: Positional tolerances according to DIN EN ISO 5458
475
All specifications subject to change. Consult Tyco Electronics AMP GmbH for latest specifications.
PCB relays
20 A class
Micro power relay K SMD
Contact data
Contact configuration
Contact material
Circuit symbol
(see also Pin assignment)
Changeover contact/
Form C
AgNi0.15 (AgSnO
2
available on request)
3
5
Make contact/
Form A
AgSnO
2
Make contact/
Form A
AgSnO
2
4
+
40 A
2)
/70 A
3)
30 A
30 A
20 A
40 A
2)
/100 A
3)
30 A
30 A
20 A
Max. switching current
1)
On
Off
Limiting continuous current
at 23 °C
at 85 °C
Voltage drop at 10 A
Mechanical endurance (without load)
Electrical endurance
at cyclic temperature -40 /+23 /+85 °C
and 13,5 VDC
40 A
2)
30 A
NC/NO
25 A/30 A
15 A/20 A
Resistive load:
> 3 x 10
5
operations
20 A on NO-contact
Typ. 30 mV
> 5 x 10
6
operations
Wiper reserve:
Motor reserve blocked:
Flasher load:
> 3 x 10
5
operations
> 1 x 10
5
operations
> 2 x 10
6
operations
25 A make /5 A break;
20 A
up to 3 x 21 W , 4)
generator peak - 10 A
Turn and hazard signal
L= 1.0 mH
L= 0.77 mH
in sequence
Lamp load:
> 1 x 10
5
operations
100 A inrush
/10 A steady state
The values apply to a resistive or inductive load with suitable spark suppression.
This current may flow for a maximum of 3 sec for a make/break ratio of 1 : 10.
3)
Corresponds to the peak inrush current on initial actuation (cold filament).
1)
2)
4) With polarization + at terminal 4.
Operating voltage range
86u_me
Does not take into account the
temperature rise due to the
contact current
E = pre-energization
Pin assignment
1 make contact/
1 form A
4
1 changeover contact/
1 form C
3
5
4
5
2
1
86ess_ab
2
1
86esw_ab
476
All specifications subject to change. Consult Tyco Electronics AMP GmbH for latest specifications.
PCB relays
20 A class
Micro power relay K SMD
Coil data
Available for nominal voltages
Nominal power consumption of the unsuppressed coil at nominal voltage
Test voltage winding/contact
Upper limit temperature for the coil
Maximum ambient temperature range
1)
Max. switching rate without contact loading
Operate time
2)
Release time
2)
See also operating voltage range diagram
Measured at nominal voltage without coil suppression unit
N.B.
A low resistive device in parallel to the relay coil slows down the armature movement
and reduces the lifetime caused by increased erosion and/or higher risk of contact tack welding.
1)
2)
10, 12 VDC (other coils on request)
0.64 W
500 VAC
rms
155 °C
– 40 to + 105 °C
50 Hz
Typ. 3 msec
Typ. 1.5 msec
Recommended reflow soldering profile
max. 60 s
240
Recommended soldering range
205
180
170
Preheating range
140
120
≤
4 K/s
min. 120 s
max. 5 min 30 s
Peak temperature range:
205 to 240
°C
Time for temperature
> 183
°C:
30 to 60 s
86sprof
≥
2 K/s
min. 30 s
≤
4 K/s
RT
Mechanical data
Enclosure
Sealed
Sealed relay is suitable for immersion cleaning of PCB assembly or conformal coating.
477
All specifications subject to change. Consult Tyco Electronics AMP GmbH for latest specifications.
PCB relays
20 A class
Micro power relay K SMD
Operating conditions
Temperature range, storage
Test
Cold storage
Dry heat
Climatic cycling with condensation
Thermal change
Thermal shock
Damp heat
cyclic
constant
Corrosive gas
Vibration resistance
Shock resistance
Solderability
Resistance to soldering heat
Sealing
Relevant standard
IEC 68-2-1
IEC 68-2-2
EN ISO 6988
IEC 68-2-14
IEC 68-2-14
Testing as per
Ba
Nb
Na
-40 °C to 155 °C
Dimension
72 h
1000 h
20 cycles
35 cycles
100 cycles
Comments
-40 °C
85 °C
Storage 8/16 h
– 40/+ 105 °C
– 40/+ 105 °C
Dwell time 1 h
40 °C / 55 °C / 93%
40 °C / 93%
IEC 68-2-30
Db, Variant 2
IEC 68-2-3
Ca
IEC 68-2-42
–
IEC 68-2-43
IEC 68-2-6 (sine pulse form)
IEC 68-2-27 (half-sine pulse form)
IEC 68-2-58
IEC 68-2-58
IEC 68-2-17
Qc, Method 2
6 cycles
56 days
10 days
10 days
10 … 500 Hz
6 msec
No change in the
switching state > 10
µsec,
6 g
No change in the
switching state > 10
µsec
up to 30 g
215 °C; 3 sec
wetting
260 °C
10 sec (see soldering profile)
1 min / 70 °C
Ordering information
Part number
(Replace * with
“Coil designator”)
Micro power relay K SMD
V23086-M1*-A303
V23086-M1*-A403
V23086-M1031-A502
V23086-M1*-A602
Contact
arrangement
Form C
Form C
Form A; lamp load
Form A; flasher load
Contact
material
AgNi0.15
AgSnO2
AgSnO2
AgSnO2
Enclosure
Sealed
Sealed
Sealed
Sealed
Terminals
Printed circuit/SMD
Printed circuit/SMD
Printed circuit/SMD
Printed circuit/SMD
Coil versions
Coil
designator
Micro power relay K SMD
011
012
031
1)
Rated coil
voltage
(V)
12
10
12
Coil resistance
+/- 10%
(Ω)
225
156
156
Must
operate voltage
(VDC)
6.9
5.7
6.9
Must
release voltage
(VDC)
1.5
1.25
1.5
Allowable overdrive
(VDC)
1)
at 23 °C
at 105 °C
1)
24
20
20
15
13
13
Allowable overdrive is stated with no load current flowing through the relay contacts and minimum coil resistance.
Standard delivery packs
(orders in multiples of delivery pack)
Micro power relay K SMD:
1000 pieces
478
All specifications subject to change. Consult Tyco Electronics AMP GmbH for latest specifications.
