PIN RECEPTACLES
for .040” - .060” diameter pins (#03 contact)
and .059” - .063” diameter pins (#42 contact)
PR
E
CI
M
ON
S
I
CHI
A
PINS
NE
D
0433/8433
Basic Part
Number
Length
A
0435/0436
0433-0
8433-0
.120
.330
Basic Part
Number
Dia.
C
Length
K
0435-0
0436-0
.118
.125
.050
.070
X433-0-15-XX-03-XX-04-0
Press-fit in .106 mounting hole
043X-0-15-XX-03-XX-10-0
Solder mount in .102 min.
mounting hole
0434
4064
0342
• 0342 receptacle uses
Mill-Max’s new #42 Power
Contact. This receptacle will
accept the Ø.061±.002
power pins of ¼ brick
DC/DC converters.
• #42 contact has a very low
resistance path and is rated
for currents up to 50A.
• #42 contact can be ordered
in standard receptacles that
use #03 contact; or it can be
specified as the spring
element inside custom made
receptacles for power
connector applications.
Insertion Loss per pin @ 50A
.805W
.533W
0434-0-15-XX-03-XX-10-0
Press-fit in .106 mounting hole
4064-0-18-XX-03-XX-10-0
Surface mount
0342-0-15-XX-42-XX-10-0
Hex press-fit in .090±.002
plated thru hole
Mechanical Data #42 Contact:
Insertion/Extraction Force
with a Ø.061 (nominal) pin:
First Cycle
2nd & Subsequent Cycles
Insertion Force Extraction Force Insertion Force Extraction Force
20N
6N
10N
6N
Compliancy Test
(the “spring back” characteristic of the contact to accept a
Ø.059 small pin after insertion of a Ø.063 large pin):
Initial Cycle with Ø.059 pin Second Cycle with Ø.063 pin Third Cycle with Ø.059 pin
Ins. Force Ext. Force Ins. Force Ext. Force Ins. Force Ext. Force
18N
6N
22N
7N
3N
2N
(Insertion/Extraction Forces are in Newtons and measured with polished
steel gage pins having elliptical shaped tips)
Electrical/Thermal Data #42 Contact:
The electrical conductivity (resistance) of #42 contact depends on the con-
ductivity of the mating pin. Tests were made with both Ø.060 Brass (26%
IACS) and Tellurium Copper (93% IACS) pins. Temperature rise was
measured with the receptacles mounted to simulate the heatsinking of a
multilayer circuitboard.
Contact/Pin combination
#42/ Brass
#42/TeCu
20
18
16
Temperature Rise (°C)
14
12
10
8
6
4
2
0
5
Resistance
.322mΩ
.213mΩ
Temperature Rise vs. Applied Current
#42/Brass Pin
#42/TeCu Pin
10 15 20 25 30 35 40 45 50 55 60 65 70 75 80 85 90 95 100
Applied Current (amps)
SPECIFICATIONS
SHELL MATERIAL:
Brass Alloy 360, 1/2 Hard
CONTACT MATERIAL:
Beryllium Copper Alloy 172, HT
DIMENSION IN INCHES
TOLERANCES ON:
LENGTHS:
±.005
DIAMETERS: ±.002
ANGLES:
± 2°
ORDER CODE: XXXX - X - 15 - XX - XX - XX -XX - 0
BASIC PART #
SPECIFY SHELL FINISH:
01
200µ"
TIN/LEAD OVER
NICKEL
15
10µ"
GOLD OVER
NICKEL
SELECT CONTACT
#03
(DATA ON PAGE 213)
or #42
CONTACT
SPECIFY CONTACT FINISH:
01
200µ"
TIN/LEAD OVER
NICKEL
14
10µ"
GOLD OVER
NICKEL
27
30µ"
GOLD OVER
NICKEL
w w w. m i l l - m a x . c o m
155
516-922-6000
