PIN RECEPTACLES
for .015” - .022” diameter pins
M
ON
S
I
CHI
A
PINS
NE
D
0512
0703
0574
0468
0512-0-15-XX-12-XX-04-0
Press-fit in .057 mounting hole
0703-0-15-XX-12-XX-04-0
Press-fit in .057 mounting hole
0574-0-15-XX-12-XX-04-0
Press-fit in .057 mounting hole
0468-0-15-XX-12-XX-04-0
Press-fit in .057 mounting hole
8894
0550
0671
0707
0550-0-15-XX-22-XX-10-0
8894-0-15-XX-12-XX-10-0
Hex press-fit in .059 plated
thru hole
Solder mount in .052 min. mounting hole
Also available on 16mm wide carrier
tape: 1,700 parts per 13” reel.
Order as: 0550-0-57-XX-22-XX-10-0
0671-0-15-XX-12-XX-10-0
Solder mount in .063 min.
mounting hole
0707-0-15-XX-12-XX-10-0
Solder mount in .051 min.
mounting hole
5739
.108 DIA.
.084 DIA.
.030
.110
.157
1534
.072 DIA.
.059 DIA.
.053 DIA.
.060
.020
.028 .071
.095
.155
Basic Part
Number
Length
A
.043 DIA.
.117
P.C.B. PAD
P.C.B. Layout
.059
.022 DIA.
HOLE
.030 DIA.
A
1534-0
1534-1
.095
.125
5739-0-18-XX-12-XX-10-0
Surface mount
Also available on 16mm wide carrier
tape: 3,000 parts per 13” reel.
Order as: 5739-0-58-XX-12-XX-10-0
.117
.069
1534-X-15-XX-12-XX-04-0
Press-fit in .056 mounting hole
SPECIFICATIONS
SHELL MATERIAL:
Brass Alloy 360, 1/2 Hard
CONTACT MATERIAL:
Beryllium Copper Alloy 172, HT
DIMENSION IN INCHES
TOLERANCES ON:
LENGTHS:
±.005
DIAMETERS: ±.002
ANGLES:
± 2°
ORDER CODE: XXXX - X - 1X - XX - XX - XX - XX - 0
BASIC PART #
SPECIFY SHELL FINISH:
01
200μ” TIN/LEAD OVER NICKEL
80
200μ” TIN OVER NICKEL (RoHS)
15
10μ” GOLD OVER NICKEL (RoHS)
2002/95/EC
SPECIFY CONTACT FINISH:
02
100μ” TIN/LEAD OVER NICKEL
84
100μ” TIN OVER NICKEL (RoHS)
27
30μ” GOLD OVER NICKEL (RoHS)
RoHS
SELECT CONTACT
#12 or #22
CONTACT (DATA ON PAGE 218)
