Miniature Optical Circulator
(patent pending)
Product Description
The OCPI Series 1310/1550 Optical Circulators are non-reciprocal devices
that redirect light at 1310/1550 nm from port-to-port in only one direction
while minimizing back reflection and back scattering in the reverse
directions for any state of polarization. Employing Agiltron’s advanced micro
optics design, it features low insertion loss, low polarization sensitivity, high
isolation, compact structure, and high stability. The excellent characteristics
of this product make it an ideal choice for application in fiber amplifier
systems, pump laser diodes, and optical fiber sensors.
Features
·
·
·
·
·
·
Low Insertion Loss
Low PDL
High Channel Isolation
Compact Package
High Reliability & Stability
Cost Effective
Performance Specifications
OC Series 1310/1550 Circulator
1310
C Band
Operating Wavelength
L Band
C+L
Typical
Insertion Loss
1
Maximum
2
Isolation (2→1, 3→2)
Directivity (1→3)
Polarization Dependent Loss
Polarization Mode Dispersion
Return Loss
1
Optical Power Handling
Operating Temperature Range
Storage Temperature
Fiber Type
Fiber Length
Package Dimension
1.
2.
Excluding connectors
@λop, Top, SOP
Applications
·
·
·
·
·
·
Optical Fiber Amplifier
Metropolitan Area Network
Fiber Optic Sensor
Dispersion Compensation
Test and Measurement
Instrumentation
Specifications
1295 ~ 1325
1530 ~ 1565
1570 ~ 1610
1530 ~ 1610
0.7
0.8
1.0
1.2
35
28
> 50
< 0.15
< 0.1
> 50
< 500
0 ~ 75
-40 ~ 85
Corning SMF-28
> 1
Φ3.8x
45(L)
Unit
nm
dB
dB
dB
dB
ps
dB
mW
o
C
o
C
m
mm
Revision: 060-12
05-13-11
1
Germany & Other Countries
Laser Components GmbH
Tel: +49 8142 2864 – 0
Fax: +49 8142 2864 – 11
info@lasercomponents.com
www.lasercomponents.com
United Kingdom
Laser Components (UK) Ltd.
Tel: +44 1245 491 499
Fax: +44 1245 491 801
info@lasercomponents.co.uk
www.lasercomponents.co.uk
Fiber
Optics
Miniature Optical Circulator
Mechanical Dimensions (mm)
3-Port Circulator
L
P1
P2
P3
Φ
05/12 / V1 / HW / agiltron/sm_circulatoren/sm_1310_1550_mini_circulator.indd
Ordering Information
OCPI-
Type
3 Port=30
Wavelength Grade
1310=3
1550=5
C band=C
L- band=L
C+L=2
Special=0
Package Type Fiber Type
SMF-28=1
Special=0
Bare fiber=1
900um loose tube=3
Special=0
Fiber Length Connector
0.25m=1
0.5 m=2
1.0 m=3
Special=0
None=1
FC/PC=2
FC/APC=3
SC/PC=4
SC/APC=5
ST/PC=6
LC=7
Special=0
Standard=1 3.8 x 45=3
Special=0
Special=0
Revision: 060-12
05-13-11
2
Germany & Other Countries
Laser Components GmbH
Tel: +49 8142 2864 – 0
Fax: +49 8142 2864 – 11
info@lasercomponents.com
www.lasercomponents.com
United Kingdom
Laser Components (UK) Ltd.
Tel: +44 1245 491 499
Fax: +44 1245 491 801
info@lasercomponents.co.uk
www.lasercomponents.co.uk
