4-1630012-0

Description
RESISTOR, WIRE WOUND
CategoryPassive components    The resistor
File Size145KB，2 Pages
ManufacturerTE Connectivity
Websitehttp://www.te.com
Environmental Compliance
Download Datasheet Parametric View All

4-1630012-0 Online Shopping

Suppliers Part Number Price MOQ In stock
4-1630012-0 - - View Buy Now

4-1630012-0 Overview

RESISTOR, WIRE WOUND

4-1630012-0 Parametric

Parameter NameAttribute value
Is it Rohs certified?conform to
MakerTE Connectivity
package instruction,
Reach Compliance Codecompliant
Factory Lead Time5 weeks
Number of terminals2
Resistor typeFIXED RESISTOR
technologyWIRE WOUND
Base Number Matches1

Preview

Download Datasheet
This browser does not have Java enabled.
TE Connectivity
 My Cart |
 My Part Lists | Sign In/Register
English
(Change)
Have a Question?
Chat with a Product
Information Specialist
What can we help you find?
Products
Industries
Resources
About TE
My Account
Innovation
Support Center
Home > Products > Resistors > Product Feature Selector > Product Details
HSC150200RJ Product Details
Fixed Resistors

Always EU RoHS/ELV Compliant
 (
Statement of Compliance
)
Product Highlights:
Fixed Resistor
Resistor Type = Power Resistor
Resistance Selection = <1K Ω
Resistance = 22 Ω
Power Rating = 150.00 W
View all Features
 Share
 Print
 Email
Quick Links
Pricing & Availability
Search for Tooling
Product Feature Selector
Contact Us About This Product
HSC150200RJ
(4­1630012­0)
TE Internal Number: 4­1630012­0
 Active
Add to My Part List
Request Sample
Find Similar Products
Buy Product
Documentation & Additional Information
Product Drawings:
HSC150 (PDF, English)
Catalog Pages/Data Sheets:
4­1773460­6_RESISTIVE_SOLUTIONS_RAIL (PDF, English)
8­1773459­4_POWER_FILTERING_AND_RESISTIVE_SOLUTIONS_... (PDF, English)
Product Specifications:
None Available
Application Specifications:
None Available
Instruction Sheets:
None Available
CAD Files:
None Available
Additional Information:
Product Line Information
Related Products:
Tooling
List all Documents
Product Features
(Please use the Product Drawing for all design activity)
Product Type Features:
Product Type = Fixed Resistor
Resistor Type = Power Resistor
Element = Wirewound
Electrical Characteristics:
Resistance Selection (Ω) = <1K
Resistance (Ω) = 22
Power Rating (W) = 150.00
Tolerance (%) = 5
Termination Features:
Termination Type = Solder Lug
Body Features:
Mount Style = Chassis Mount
Package, Component Size = 122 x 47.5
Configuration Features:
Number of Terminations = 2
Number of Resistors = 1
Industry Standards:
RoHS/ELV Compliance = RoHS compliant, ELV compliant
Lead Free Solder Processes = Not reviewed for lead free solder
process
RoHS/ELV Compliance History = Always was RoHS compliant
Conditions for Usage:
Temperature Coefficient (ppm/°C) = ±30
Operation/Application:
Application = High Power
Packaging Features:
Package Type = Loose Piece ­ Tray
Other:
Series = HS
Brand = CGS
