Mounting Racks, Cables, Brain Boards and Relays
SNAP I/O
Mounting Racks
Quad Pak I/O Racks
Quad racks provide a high-density digital I/O solution and accept Opto 22 Quad Pak
modules. Both 50-pin header and card edge connectors are available.
Quad Pak Digital Racks
(Brain Board Compatible)
SNAP racks come in two model types Ñ D Series (digital only) and B Series (for SNAP brains). All SNAP racks use a single
5-volt power source, are configured for standard panel mounting, and offer a DIN-rail mounting option. B Series racks are
designed for integration with the SNAP Ethernet, Profibus, and Modbus brains, and allow a combination of analog and digital
SNAP I/O modules on the same rack. D Series racks use the same 50-pin connector as Opto 22 Classic racks and are
therefore compatible with Opto 22 Classic digital brain boards and interfaces. D Series racks provide an ideal direct connect
solution for OEM applications.
691-0238.
PB16HQ. Quad 4-Module Position Rack.................................EACH
69.00
691-0239.
PB32HQ*. Quad 8-Module Rack For B4 Brain........................EACH
120.00
Quad Pak Digital Racks for Direct Connect
Quad Pak I/O Rack Accessories
4
691-0240.
PB24HQ*. Quad 6-Module Position Rack .........................................................................................EACH
115.00
691-0241.
PB24Q. Quad 6-Module Position Rack..............................................................................................EACH
108.00
691-0244.
STRAP4Q. 4-Position Strap Quad Rack R0431.................................................................................EACH
1.65
*With Header Connector.
ÒDÓ Series Digital Only Racks
691-0019.
SNAP-D4M. 4-Module Rack ..............................................................................................................EACH
691-0020.
SNAP-D4MC. 4-Module Rack With Extra Terminal Block For Field Wiring.......................................EACH
691-0023.
SNAP-D6MC. 6-Module Rack With Extra Terminal Block For Field Wiring.......................................EACH
691-0025.
SNAP-D8M. 8-Module Rack ..............................................................................................................EACH
691-0028.
SNAP-D12M. 12-Module Rack ..........................................................................................................EACH
42.00
45.00
70.00
81.00
104.00
77.00
94.00
112.00
161.00
182.00
161.00
Standard Mounting Racks
Standard mounting racks include both digital and analog. Standard digital racks
are available in 4, 8, 16, and 24-channel models and feature LED status
indicators and plug-in replaceable fuses for each channel. Standard digital
input and output modules can be combined on any Standard mounting rack. A
Standard digital rack, with screw terminals for both field and logic connections,
is available for custom application development targeted at isolating non-
isolated devices such as PLCs. Standard digital racks are available for both direct connection and connection to Opto 22
Classic brain boards. Standard analog racks in 4, 8, or 16-channel models accept Opto 22 Standard analog I/O modules.
Standard analog racks are compatible with all Classic analog brain boards.
ÒBÓ Series Brain Board Racks
691-2144.
SNAP-B4M. 4-Module Rack, FM Approved.......................................................................................EACH
691-0031.
SNAP-B8M. 8-Module Rack, FM Approved.......................................................................................EACH
691-0034.
SNAP-B12M. 12-Module Rack, FM Approved...................................................................................EACH
691-0037.
SNAP-B16M. 16-Module Rack, FM Approved...................................................................................EACH
691-0038.
SNAP-B16MC. 16-Module Rack With Extra Terminal Block For Field Wiring ...................................EACH
691-5536.
SNAP-D64RS. 16-Module Rack for Use with SNAP-ENET-D64 Digital Brain ...................................EACH
SNAP I/O Mounting Rack Accessories
691-2140.
SNAP-LCM4DIN. DIN-Rail Adapter for SNAP-LCM4 Industrial Controller .......................................EACH
70.00
691-0044.
SNAP-RACKDIN. SNAP Rack Din Rail Adapter Clip ..........................................................................EACH
11.25
691-2144.
SNAP-B4M. SNAP B Series 4 Position Brain Rack............................................................................EACH
77.00
Standard Digital Racks
G4 Mounting Racks
G4 mounting racks accept G4 digital I/O modules only and are available in 4, 8, 16,
24, and 32-channel models. G4 digital input and output modules can be used in any
combination on any G4 mounting rack. A model with screw terminals for both field
and logic connections is available for custom application development, targeted at
isolating non-isolated devices such as PLCs. G4 models are available for both direct
connection and connection to Opto 22 Classic brain boards.
Standard Digital Racks with Header Connector (Brain Board Compatible)
691-0190.
PB4H. 4-Channel Rack.......................................................................................................................EACH
691-0191.
PB8H. 8-Channel Rack.......................................................................................................................EACH
691-0192.
PB16H. 16-Channel Rack...................................................................................................................EACH
691-0193.
PB16HC. 16-Channel Rack Common TB ...........................................................................................EACH
Standard Digital Racks for Direct Connect
691-0194.
PB4. 4-Channel I/O Module Rack ......................................................................................................EACH
691-0195.
PB4R. 4-Channel Output Module Rack..............................................................................................EACH
691-0196.
PB8. 8-Channel I/O Module Rack ......................................................................................................EACH
691-0197.
PB16A. 16-Channel I/O Module Rack ................................................................................................EACH
691-0198.
PB16C. 16-Channel I/O Module Rack Extra Term. Strip ......................................................................EACH
691-0199.
PB16T. 16-Channel I/O Module Rack ................................................................................................EACH
691-0200.
PB24. 24-Channel I/O Module Rack ..................................................................................................EACH
42.00
56.00
69.00
98.00
21.00
35.00
38.00
62.00
95.00
80.00
97.00
G4 Racks (Brain Board Compatible)
G4 Racks for Direct Connect
G4 Digital Racks with Header Connector (Brain Board Compatible)
691-0212.
G4PB8H. 8-Channel Rack ..................................................................................................................EACH
42.00
691-0213.
G4PB16H. 16-Channel Rack ..............................................................................................................EACH
69.00
691-0216.
G4PB4. 4-Channel I/O Module Rack..................................................................................................EACH
691-0217.
G4PB4R. 4-Channel Output Module Rack .........................................................................................EACH
691-0218.
G4PB8. 8-Channel I/O Module Rack..................................................................................................EACH
691-0219.
G4PB16. 16-Channel I/O Module Rack..............................................................................................EACH
691-0220.
G4PB16I. 16-Channel I/O Module Rack Isolated Control ..................................................................EACH
691-0221.
G4PB16T. 16-Channel I/O Module Rack Extra Term.Strip ................................................................EACH
691-0222.
G4PB24. 24-Channel I/O Module Rack..............................................................................................EACH
691-0223.
G4PB32DEC. 32-Channel I/O Module Rack.......................................................................................EACH
21.00
25.00
38.00
62.00
80.00
80.00
97.00
125.00
8.95
Standard Analog Racks
691-0203.
PB16AH. 16-Channel Analog Mounting Rack....................................................................................EACH
170.00
Standard I/O Rack Accessories
691-0207.
PBSA. Power Supply 120 VAC...........................................................................................................EACH
70.00
691-0210.
STRAP2. 2 Position Strap Single Rack R0433 ..................................................................................EACH
1.00
691-0211.
STRAP8. 8 Position Strap Single Rack R0430 ..................................................................................EACH
1.65
Cables
691-0356.
HH1.5. 1.5-Ft Header to Header Cable...............................................................................................EACH
691-0358.
HH4. 4-Ft Header to Header Cable .....................................................................................................EACH
691-0359.
HH6. 6-Ft Header to Header Cable .....................................................................................................EACH
691-0360.
HH8. 8-Ft Header to Header Cable .....................................................................................................EACH
40.00
47.00
54.00
60.00
G4 Rack Accessories
691-0224.
G4STRAP. G4 16-Position Strap Single Rack, R5187.......................................................................EACH
Brain Boards
Power Series Relays
Opto 22 provides a full range of Power Series
relays with a wide variety of voltage and current
options. All Power Series SSRs provide
4000 VRMS of optical isolation and provide a
wide operating temperature range of Ð40¡C to
+100¡C. Part numbers with a D are TTL compatible, with a 3-32 VDC control
voltage. Part numbers with an A use an 85-280 VAC control voltage.
Printed Circuit Series
Opto 22Õs Printed Circuit Series allows OEMs to easily
deploy solid-state relays on printed circuit boards with
switch loads up to 4 amps.
The MP Series packaging is designed with a minimum
footprint to allow maximum relay density on the circuit
board. Z Series SSRs switch nominal voltages of either 120 or 240 VAC with
nominal current ratings of 2 and 4 amps. All MP Series SSRs provide
4000 VRMS of optical isolation and provide a wide operating temperature
range of Ð40¡C to +100¡C. MP Series SSRs are TTL compatible, with a
3-32 VDC control voltage. All MP Series SSRs feature a built-in snubber and a
maximum zero voltage turn-on time of
1
/
2
cycle. All models are UL recognized
and CSA certified. Relays with a -17 extension on the part number are VDE
approved.
MP Series DC Switching
691-0531.
DC200MP. 200 VDC, 1 A, DC Control...........................EACH
11.25
691-0532.
DC60MP. 60 VDC, 3 A, DC Control ...............................EACH
8.00
MP Series AC Switching
691-0533.
MP120D2. 120 VAC, 2 A, DC Control ...........................EACH
8.50
691-0534.
MP120D4. 120 VAC, 4 A, DC Control ...........................EACH
8.75
691-0535.
MP240D2. 240 VAC, 2 A, DC Control ...........................EACH
9.15
691-0536.
MP240D4. 240 VAC, 4 A, DC Control ...........................EACH
9.75
691-0537.
MP240D4-17. 240 VAC, 4 A, DC Control, VDE Approved..EACH
10.50
MP Series
DC Switching Series
The DC Series delivers isolated DC control to large OEM customers worldwide.
DC Power Series SSRs switch DC voltages between 5-60 volts. They have
nominal current ratings of 3 and 5 amps.
691-0501.
DC60S3. 60 VDC, 3 Amp, DC Control...........................EACH
9.60
691-0502.
DC60S5. 60 VDC, 5 Amp, DC Control...........................EACH
15.00
The AC Series offers the ultimate in solid-state reliability. AC Power Series
SSRs switch voltages between 120 and 575 VAC with nominal current ratings
from 3 to 45 amps. All AC Power Series SSRs feature a built-in snubber and a
maximum zero voltage turn-on time of
1
/
2
cycle. All models are UL recognized
and CSA certified. Relays with a -17 extension on the part number are VDE
approved, while a -12 indicates a transient proof model.
691-0503.
120A10. 120 VAC, 10 A, AC Control .............................EACH
19.00
691-0504.
120A25. 120 VAC, 25 A, AC Control .............................EACH
21.00
691-0505.
120D10. 120 VAC, 10 A, DC Control.............................EACH
16.00
691-0506.
120D25. 120 VAC, 25 A, DC Control.............................EACH
20.00
691-0507.
120D3. 120 VAC, 3 A, DC Control .................................EACH
12.50
691-0508.
120D45. 120 VAC, 45 A, DC Control.............................EACH
30.00
691-0509.
240A10. 240 VAC, 10 A, AC Control .............................EACH
18.50
691-0510.
240A25. 240 VAC, 25 A, AC Control .............................EACH
26.00
691-0511.
240A45. 240 VAC, 45 A, AC Control .............................EACH
34.00
691-0512.
240D10. 240 VAC, 10 A, DC Control.............................EACH
19.00
691-0514.
240D25. 240 VAC, 25 A, DC Control.............................EACH
22.00
691-0515.
240D25-17. 240 VAC, 25 A, DC Control, VDE Approved...EACH
24.00
691-0516.
240D3. 240 VAC, 3 A, DC Control .................................EACH
13.00
691-0517.
240D45. 240 VAC, 45 A, DC Control.............................EACH
31.00
691-0518.
240D45-17. 240 VAC, 45 A, DC Control, VDE Approved...EACH
33.00
691-0520.
380D45. 380 VAC, 45 A, DC Control.............................EACH
52.00
691-0521.
480D10-12. 480 VAC, 10 A, DC Control, Trans. Proof ...EACH
28.00
691-0526.
575D45-12. 575 VAC, 45 A, DC Control, Trans. Proof ...EACH
33.00
AC Switching Series
Opto 22Õs brain board technology creates a truly distributed and scalable,
intelligent I/O system. Opto 22 brain boards have two distinguishing factors:
the form factor of the racks that they support and the protocol(s) that they
utilize.
Classic Brain Boards
Classic brain boards are distinguished by the protocol that they support. Mistic
protocol brain boards include the B100 (digital) and B200 (analog). The
Optomux protocol is supported by the B1 and B100 (digital) and B2 and
B200 (analog) brain boards. Pamux brain boards include B4 (32-channel
digital), B5 (16-channel digital), and B6 (16-channel analog). The Mistic
protocol provides seamless integration with Opto 22Õs FactoryFloor software.
Mistic Brain Boards
691-0276.
B100. 16-Ch. Digital Brain Mistic/Optomux Protocol ...EACH
240.00
691-0277.
B200. 16-Ch. Analog Brain Mistic/Optomux Protocol ..EACH
250.00
Optomux Brain Boards
691-0278.
B1. 16-Channel Digital Brain Optomux Protocol...........EACH
221.00
691-0279.
B2. 16-Channel Analog Brain Optomux Protocol..........EACH
225.00
Pamux Brain Boards
691-0280.
B4. 32-Channel Digital Brain Pamux .............................EACH
158.00
691-0281.
B5. 16-Channel Digital Brain Pamux .............................EACH
151.00
691-0282.
B6. 16-Channel Analog Brain Pamux ............................EACH
310.00
Z Series Relays
An economical 10 amp SSR in an all plastic
package is made possible through a unique
heat transfer system. All Z Series SSRs
provide 4000 VRMS of optical isolation and
provide a wide operating temperature range
of Ð40¡C to +100¡C. Z Series SSRs are TTL
compatible, with a 3-32 VDC control
voltage. All Z Series SSRs feature a built-in snubber and a maximum zero
1
/
2
cycle. All models are UL recognized and CSA
voltage turn-on time of
certified. Relays with a -17 extension on the part number are VDE approved.
691-0528.
Z120D10. 120 VAC, 10 A, DC Control...........................EACH
9.80
691-0529.
Z240D10. 240 VAC, 10 A, DC Control...........................EACH
10.00
Power Series Accessories
691-0527.
SAFETY COVER. Standard Model SSR Cover ...............EACH
1.46
184
b
ALLIED
See Our Manufacturer Index Located In Section 1
Buy&Sell
京公网安备 11010802033920号
EEWORLD
