X1G003901008901: DescriptionCMOS Output Clock Oscillator,; CategoryPassive components oscillator; File Size504KB，8 Pages; ManufacturerSeiko Epson Corporation

Download Datasheet Parametric Compare View All

X1G003901008901 Overview

CMOS Output Clock Oscillator,

Parameter Name	Attribute value
Reach Compliance Code	unknown
Other features	TAPE
Ageing	0.5 PPM/FIRST YEAR
maximum descent time	8 ns
Frequency Adjustment - Mechanical	NO
frequency stability	0.28%
Installation features	SURFACE MOUNT
Nominal operating frequency	16.384 MHz
Maximum operating temperature	85 °C
Minimum operating temperature	-40 °C
Oscillator type	CMOS
Output load	13.5 pF
physical size	7.0mm x 5.0mm x 1.5mm
longest rise time	8 ns
Maximum supply voltage	3.465 V
Minimum supply voltage	3.135 V
Nominal supply voltage	3.3 V
surface mount	YES
maximum symmetry	55/45 %
Base Number Matches	1

Temperature Compensated Crystal Oscillator (TCXO)

Data sheet

MODEL

：

TG-5501CA-89N 16.384000MHz

Product. No.

：

X1G0039010089xx

Please refer to the 10.Packing information about xx (last 2 digits)

SEIKO EPSON CORPORATION

Pb free.

Complies with EU RoHS directive.

*About the products without the Pb-free mark.

Contains Pb in products exempted by EU RoHS directive.

(Contains Pb in sealing glass, high melting temperature type solder or other.)

INTRODUCTION

1. Any part of this material may not be reproduced or duplicated in any form or any means without the

written permission of Seiko Epson.

2. This sheet is not intended to guarantee or provide an approval of implementation of industrial patents.

	X1G003901008901	X1G003901008900	X1G003901008911	X1G003901008913	X1G003901008912
Description	CMOS Output Clock Oscillator,	CMOS Output Clock Oscillator,	CMOS Output Clock Oscillator,	CMOS Output Clock Oscillator,	CMOS Output Clock Oscillator,
Reach Compliance Code	unknown	unknown	unknown	unknown	unknown
Other features	TAPE	TR, 10 INCH	TR, 10 INCH	TR, 10 INCH	TR, 10 INCH
Ageing	0.5 PPM/FIRST YEAR	0.5 PPM/FIRST YEAR	0.5 PPM/FIRST YEAR	0.5 PPM/FIRST YEAR	0.5 PPM/FIRST YEAR
maximum descent time	8 ns	8 ns	8 ns	8 ns	8 ns
Frequency Adjustment - Mechanical	NO	NO	NO	NO	NO
frequency stability	0.28%	0.28%	0.28%	0.28%	0.28%
Installation features	SURFACE MOUNT	SURFACE MOUNT	SURFACE MOUNT	SURFACE MOUNT	SURFACE MOUNT
Nominal operating frequency	16.384 MHz	16.384 MHz	16.384 MHz	16.384 MHz	16.384 MHz
Maximum operating temperature	85 °C	85 °C	85 °C	85 °C	85 °C
Minimum operating temperature	-40 °C	-40 °C	-40 °C	-40 °C	-40 °C
Oscillator type	CMOS	CMOS	CMOS	CMOS	CMOS
Output load	13.5 pF	13.5 pF	13.5 pF	13.5 pF	13.5 pF
physical size	7.0mm x 5.0mm x 1.5mm	7.0mm x 5.0mm x 1.5mm	7.0mm x 5.0mm x 1.5mm	7.0mm x 5.0mm x 1.5mm	7.0mm x 5.0mm x 1.5mm
longest rise time	8 ns	8 ns	8 ns	8 ns	8 ns
Maximum supply voltage	3.465 V	3.465 V	3.465 V	3.465 V	3.465 V
Minimum supply voltage	3.135 V	3.135 V	3.135 V	3.135 V	3.135 V
Nominal supply voltage	3.3 V	3.3 V	3.3 V	3.3 V	3.3 V
surface mount	YES	YES	YES	YES	YES
maximum symmetry	55/45 %	55/45 %	55/45 %	55/45 %	55/45 %
Base Number Matches	1	1	1	1	1
