SIS6230N-4R0RT

Description
General Purpose Inductor
CategoryPassive components    inductor
File Size100KB,2 Pages
ManufacturerElec & Eltek
Websitehttp://www.eleceltek.com
Download Datasheet Parametric View All

SIS6230N-4R0RT Overview

General Purpose Inductor

SIS6230N-4R0RT Parametric

Parameter NameAttribute value
Reach Compliance Codeunknown
ECCN codeEAR99
Inductor typeGENERAL PURPOSE INDUCTOR
Base Number Matches1
E & E Magnetic Products Limited
SHIELDED SURFACE MOUNT
POWER INDUCTOR
Drum Type, SIS6230 Series
Miniature in size and high energy storage
Ideal for high current requirements of notebook,
video recorders and other DC-DC conversion
applications
Custom inductance value or tolerance is available
RoHS compliant
E
LECTRICAL
S
PECIFICATION
@ 25
o
C
Part
Number
Inductance
(uH)
2
Inductance
Tolerance(%)
M
N
DCR
(
W
)
(Max)
Rated
Current
(A)
3
Marking
(XYYY)
SIS6230N-2R9R
SIS6230N-4R0R
SIS6230N-5R5R
SIS6230N-6R3R
SIS6230N-7R1R
SIS6230N-8R0R
SIS6230M-100R
SIS6230M-120R
SIS6230M-150R
SIS6230M-180R
SIS6230M-220R
SIS6230M-270R
SIS6230M-330R
SIS6230M-390R
SIS6230M-470R
SIS6230M-560R
SIS6230M-680R
SIS6230M-820R
SIS6230M-101R
SIS6230M-121R
SIS6230M-151R
SIS6230M-181R
SIS6230M-221R
SIS6230M-271R
SIS6230M-331R
2.9
4.0
5.5
6.3
7.1
8.0
10
12
15
18
22
27
33
39
47
56
68
82
100
120
150
180
220
270
330
N/A
N/A
N/A
N/A
N/A
N/A
±20
±20
±20
±20
±20
±20
±20
±20
±20
±20
±20
±20
±20
±20
±20
±20
±20
±20
±20
+40/-20
+40/-20
+40/-20
+40/-20
+40/-20
+40/-20
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
68m
80m
96m
0.10
0.11
0.12
0.15
0.20
0.23
0.27
0.34
0.38
0.45
0.49
0.69
0.78
1.07
1.21
1.39
1.90
2.18
2.77
3.12
4.38
4.94
1.94
1.63
1.40
1.30
1.22
1.15
1.10
1.00
0.90
0.80
0.74
0.66
0.59
0.54
0.50
0.46
0.42
0.38
0.34
0.31
0.28
0.26
0.23
0.22
0.19
N2R9
N4R0
N5R5
N6R3
N7R1
N8R0
M100
M120
M150
M180
M220
M270
M330
M390
M470
M560
M680
M820
M101
M121
M151
M181
M221
M271
M331
Notes:
1. Ordering Information: SIS6230a - bbbRc.
SIS6230
a
bbb
R
c
= Product Type.
= Tolerance of Inductance (M=
±20%;
N=
+40/-20%).
= Inductance value in uH (i.e. 2R9 = 2.9uH; 120 = 12uH; 121 = 120uH).
= Internal Control Code.
= Packaging Code (T = Tape & Reel Packaging in 13 inch Reel).
2
.
Inductance, 2.9uH~8.0uH, is tested at 1MHz; 10uH~330uH, is tested at 1kHz.
3
.
Rated current indicates the value of DC current when the inductance is maintained at 75% more than
its initial value, or the value of current when the temperature rising
Dt
= 40°C, whichever is lower.
1/F., Harbour View 1, No.12 Science Park East Avenue, Phase II, Hong Kong Science Park, Shatin, N.T. Hong Kong
Tel: (852) 2954 3333
Fax: (852) 2954 3304
1
PI212(01)
Revised in 09/12
