382983-1 Product Details
Live Product Chat
Memory Sockets
Not re vie we d for R oHS C om plia nce
No Im a ge Ava ila ble
Quick Links
C heck Pricing & Availability
Search for Tooling
Product Feature Selector
C ontact Us About This Product
382983-1
T E I nternal N umber: 3 8 2 9 8 3 - 1
Product Highlights:
l
DIMM II
l
Gold Flash over Palladium Nickel C ontact Mating Area
Plating Material
l
Number of Positions = 168
l
DRAM Type = Standard
l
DRAM Voltage = 5.0 V
View all Features
A dd to M y P art L is t
Reques t Sample
Find Similar P roduc ts
Obsolete
C ontact Product Information
C enter
Buy P roduc t
Documentation & Additional Information
Product Drawings:
l
None Available
Catalog Pages/Data Sheets:
l
I C SOC KETS
(PDF, English)
Product Specifications:
l
None Available
Application Specifications:
l
DIMM Version II Sockets
(PDF, English)
Instruction Sheets:
l
None Available
CAD Files:
l
None Available
List all Documents
Product Features
(Please use the Product Drawing for all design activity)
Product Type Features:
l
Product Type
= DIMM II
l
Number of Positions
= 168
l
DRAM Type
= Standard
l
PC B Mount Style = Through Hole
l
Module Orientation
= Vertical
Mechanical Attachment:
l
C enter Retention Hole Diameter (mm [in])
= 2.44 [0.096]
Electrical Characteristics:
l
DRAM Voltage
= 5.0 V
Termination Related Features:
l
Termination Post Length (mm [in])
= 2.79 [0.110]
Body Related Features:
l
Row-to-Row Spacing (mm [in])
= 1.90 [0.075]
l
C enterline (mm [in])
= 1.27 [0.050]
l
Number of Rows
= Dual
l
Ejector Type = Standard
l
Ejector Location
= Both Ends
l
Mount Type = Printed C ircuit Board
l
Module Key Type = Key1= C enter / Key2= Offset Left
Contact Related Features:
l
C ontact Mating Area Plating Material = Gold Flash over Palladium
Nickel
l
C ontact Base Material = Phosphor Bronze
Housing Related Features:
l
Housing Material = High Temperature Thermoplastic
l
Housing Flammability Rating = UL 94V-0
Configuration Related Features:
l
Insertion Style
= Direct Insert
l
C enter Key (mm [in])
= None
Industry Standards:
l
RoHS/ELV C ompliance
= Not reviewed for ELV/RoHS compliance
l
Lead Free Solder Processes
= Not reviewed for lead free solder
process
Packaging Related Features:
l
Packaging Method = Tray
Other:
l
Brand = AMP
Additional Information:
l
Product Line Information
Additional Product Images:
l
Module Keying Details
