PD2000
VOLTAGE CONTROLLED CRYSTAL OSCILLATOR (VCXO)
The PD2000 series offers a wide frequency adjustment range with an
ACMOS/TTL compatible output. The PD2000 14 pin resistance welded
package provides a hermetically sealed unit and operates over an extended
temperature range.
ADVANTAGES
• Hermetic Seal
• Cost Effective
• Extended Temperature Range
• Wide Frequency Adjustment Range
APPLICATIONS
• Telecommunications
• Portable Instrumentation
• Synthesizers
• Phase Locked Loops
Electrical Performance (Ta = 25°C, C
L
= 10kΩ//10pF and Vcc = +5.0V)
PARAMETER
Nominal Frequency (Fo)
Calibration Tolerance (Vc = +2.5V)
Frequency Stability
Over Temperature Range
(See Note 2)
Ageing (per year at +25°C)
Over Supply Voltage Variation (Vcc = ±5 % )
Operating Temperature Range
(See Note 2)
Storage Temperature Range
Supply Voltage
(See Note 2)
Supply Current (Dependent upon nominal frequency)
Output Waveform HCMOS/TTL
Logic Levels
Duty Cycle (@ Vcc/2)
Fall and rise times
Voltage Control Range +2.5V ± 2.0V (Positive polarity)
Linearity Error
Input Impedance
Modulation Bandwidth (3dB)
MINIMUM MAXIMUM UNITS
4.0
160
MHz
-10
+10
ppm
ppm
-25
+25
-2.0
+2.0
-3.0
+3.0
-40
+85
°C
-55
+125
°C
+4.75
+5.25
V
2.0
20.0
mA
0.1Vcc
45
3
±100
50,000
10
0.9Vcc
55
10
±200
±10
V
%
ns
ppm
%
Ω
kHz
Notes
1. To order state part number,
options and nominal frequency
(e.g. PD2000 19.600MHz).
2. Other temperature ranges,
stabilities and supply voltages
are available upon request.
11.0
18.6
8.6
0.8
0.5
1
14
15.24
20.6
7
13.0
8
Pin Connections:
1 = Voltage Control
7 = Ground/case
8 = Output
14 = Vcc
*Measurement in millimeters
PRECISION DEVICES INC.
(US) Tel (800) 274-XTAL/(608) 831-4445 • (UK) Tel +44 (0) 1223 834444 • (HK) Tel (852) 2637-3626
www.pdixtal.com
