E-Series Plug-In Mixer
5 - 1000 MHz
Features
q
q
EMA-2CM
V3.00
R-1
LO Power: +7 dBm
Up to +1 dBm RF
Specifications
@ 25°C
Frequency Range
RF
LO
IF
Conversion Loss (dB)
10 - 500 MHz
5 - 1000 MHz
Isolation (dB)
LO to RF
5 - 50 MHz
50 - 500 MHz
500 - 1000 MHz
LO to IF
5 - 50 MHz
50 - 500 MHz
500 - 1000 MHz
Typical
6.0
6.5
Typical
60
35
30
50
30
25
5 - 1000 MHz
5 - 1000 MHz
DC - 1000 MHz
Maximum
7.0
8.5
Minimum
50
30
25
45
25
20
Operating Characteristics
Impedance
RF input for 1dB Compression
50 Ohms Nominal
+ 1 dBm
Dimensions in ( ) are in mm.
Unless Otherwise Noted: .x = ±0.04 (1.00)
.xx = ±0.02 (0.50)
.xxx = ±0.010 (0.250)
WEIGHT (APPROX.): 0.16 OUNCES 4.4 GRAMS
Ordering Information
Part No.
EMA-2CM
EMA-2CMTR
Packaging
Tube
Forward Tape & Reel
Pin Configuration
Function
LO
RF
Pin No.
8
1
3,4
2,5,6,7
2,5,6,7
Absolute Maximum Ratings
Parameter
RF Power
Peak IF Current
Storage Temperature
Operating Temperature
Pin Temperature (10 Seconds)
Absolute Maximum
50 mW
40 mA
-55°C to 100°C
-55°C to 100°C
260°C
IF*
Ground
Case Ground
*IF pins must be connected together externally.
