Lift |
Spacing 5.0 mm
AK750/..-5.0-V-GREEN
Technical Data
Wire Sizes
Solid min
solid max
Stranded (flexible)
min
Stranded (flexible)
max
0.2 mm²
4.0 mm²
0.2 mm²
2.5 mm²
Insulating Material
Material
Flammability Class
Temperatures
Operating Temperature
Wave Soldering Process
Soldering Temperature,
recommended
Peak Soldering Time,
recommended
Reflow Process
Soldering Temperature,
recommended
Peak Soldering Time,
recommended
Leere Zeile
-
-
265 °C
3-4 s
-30 °C - 105 °C
PA 6.6
UL 94 V-0
Order Data (Spacing 5.0 mm)
Poles
2
3
4
5
6
7
8
9
10
11
12
Width (mm)
13.10
18.10
23.10
28.10
33.10
38.10
43.10
48.10
53.10
58.10
63.10
Article Designation
AK750/2-5.0-V-GREEN
AK750/3-5.0-V-GREEN
AK750/4-5.0-V-GREEN
AK750/5-5.0-V-GREEN
AK750/6-5.0-V-GREEN
AK750/7-5.0-V-GREEN
AK750/8-5.0-V-GREEN
AK750/9-5.0-V-GREEN
AK750/10-5.0-V-GREEN
AK750/11-5.0-V-GREEN
AK750/12-5.0-V-GREEN
Article Number
50750020201D
50750030201D
50750040201D
50750050201D
50750060201D
50750070201D
50750080201D
50750090201D
50750100201D
50750110201D
50750120201D
PU
50
50
50
50
50
50
50
50
50
50
50
Stranded with Ferrule 0.25 mm²
min
Stranded with Ferrule 2.5 mm²
max
Dimensions
Stripped Length
PCB Hole Diameter
Materials
Clamp
Screw
Solder Tag
Brass
Steel
Copper Alloy
8.0 mm
1.3 mm
Accessories
Figure
Designation
Bridge, 2-pole, insulated, BRI/2-5.0/5.08-
LIGHT GREY
Article Number
50000000006
Colours
RAL6018
RAL7016
similar RAL 6018
GREEN, RAL6018
GREY , RAL7016
LIGHT GREEN, similar RAL 6018
Bridge, 3-pole, insulated, BRI/3-5.0/5.08-
LIGHT GREY
50000000007
Colours according to RAL, there may be variations on colour due to production conditions.
Special colours on request.
Bridge, 2-pole, BR/2-5.0/5.08-L7.0
50000000008
Screw cover SC-AK700-YELLOW
50700000004
Ratings
Usegroup
Rated Voltage
Rated Current
Rated Wire Size
solid
stranded
Torque
Screw Size
Test Voltage
B
300 V
20 A
AWG 30-12
AWG 30-12
0.45 Nm
M3
1.6 kV
C
150 V
20 A
AWG 30-12
AWG 30-12
0.45 Nm
M3
1.6 kV
D
300 V
10 A
AWG 30-12
AWG 30-12
0.45 Nm
M3
1.6 kV
min
0.5 mm²
0.5 mm²
250 V
24 A
max
4.0 mm²
2.5 mm²
0.50 Nm
M3
2.0 kV
