500C274U6R3ED2BS datasheet, PDF

Datasheet> All Categories > Passive components> capacitor> 500C274U6R3ED2BS

500C274U6R3ED2BS: DescriptionAluminum Electrolytic Capacitor, Polarized, Aluminum (wet), 6.3V, 75% +Tol, 10% -Tol, 270000uF, Stud Mount, ROHS COMPLIANT; CategoryPassive components capacitor; File Size587KB，12 Pages; ManufacturerCDE [ CORNELL DUBILIER ELECTRONICS ]; Environmental Compliance

Download Datasheet Parametric View All

500C274U6R3ED2BS Overview

Aluminum Electrolytic Capacitor, Polarized, Aluminum (wet), 6.3V, 75% +Tol, 10% -Tol, 270000uF, Stud Mount, ROHS COMPLIANT

500C274U6R3ED2BS Parametric

Parameter Name	Attribute value
Is it lead-free?	Lead free
Is it Rohs certified?	conform to
Maker	CDE [ CORNELL DUBILIER ELECTRONICS ]
package instruction	,
Reach Compliance Code	compliant
ECCN code	EAR99
capacitance	270000 µF
Capacitor type	ALUMINUM ELECTROLYTIC CAPACITOR
diameter	45.06 mm
dielectric materials	ALUMINUM (WET)
ESR	7 mΩ
leakage current	3.91267 mA
length	118.242 mm
Installation features	STUD MOUNT
negative tolerance	10%
Number of terminals	2
Maximum operating temperature	95 °C
Minimum operating temperature	-40 °C
Package shape	CYLINDRICAL PACKAGE
Package form	Screw Ends
polarity	POLARIZED
positive tolerance	75%
Rated (DC) voltage (URdc)	6.3 V
ripple current	20600 mA
surface mount	NO
Terminal pitch	19.05 mm
Terminal shape	BINDING POST
Base Number Matches	1

Preview

Download Datasheet

View All

Type 500C

95 °C Long-life, Computer Grade, Aluminum

Computer Grade, –40 °C to +95 °C, Long Life

Twice the Life!

Type 500C capacitors are designed for mainframe computers and other long life

UPS and power supply ﬁlter applications. They deliver nearly as much capacitance

as the Type DCMC capacitors, but with two times the life expectancy. They are an

excellent choice for high ripple applications. The extended cathode foil of the 500C

assures cool operation with heat ﬂow from the capacitor element to the can.

Highlights

•

Long-life, High-Capacitance

Better for Power-supply and UPS systems

Thermal-Pak™ extended cathode construction

–40 °C to +95 °C

6.3 to 500 Vdc

100 µF to 2.6 F

<200 Vdc: –10 +75%; ≥200 Vdc: –10% +50%

≤3√CV µA at 5 minutes; 4 mA max.

20 °C multiple of 25 °C Z ≤20 for 6.3–10 V, 8 for 16–50 V,

4 for 63–100 V, 3 for 150 V and up.

Ambient Temperature

45 °C

2.00

55 °C

1.82

65 °C

1.59

75 °C

1.33

85 °C

1.00

10 kHz

50 Hz 60 Hz 120 Hz 360 Hz 1 kHz 5 kHz

1 3/8” & 1 3/4” Diameters

6.3 to 160 V

200 to 350 V

400 to 500 Vx

2” & 2 1/2” Diameters

6.3 to 160 V

200 to 350 V

400 to 500 V

3” & 3 1/2” Diameters

6.3 to 160 V

200 to 350 V

400 to 500 V

0.95

0.84

0.79

0.97

0.88

0.84

1.00

1.03

1.12

1.18

1.04

1.17

1.26

1.04

1.20

1.31

1.04

1.20

1.32

0.93

0.78

0.77

0.95

0.83

0.82

1.00

1.04

1.20

1.22

1.06

1.29

1.33

1.06

1.34

1.39

1.07

1.35

1.40

0.91

0.76

0.93

0.81

1.00

1.06

1.24

1.08

1.36

1.37

1.10

1.43

1.44

1.10

1.44

1.45

& up

Speciﬁcations

Operating Temperature:

Rated Voltage:

Capacitance:

Capacitance Tolerance:

Leakage Current:

Cold Impedence:

Ripple Current Multipliers:

Frequency

EIA Ripple Life:

Life Test:

Shelf Life:

Vibration:

5,000 h at full load @ +85 °C per EIA IS-749

∆Capacitance

±20%

ESR 200% of limit

DCL 100% of limit

5,000 h at 95 °C and rated voltage

∆Capacitance

±20%

ESR 200% of limit

DCL 100% of limit

500 h @ +95 °C, Capacitance, ESR and DCL, initial

requirements.

10 to 55 Hz, 0.06” and 10 g max, 1.5 h ea. of 2 axis

Cornell Dubilier

•

140 Technology Place

•

Liberty, SC 29657

•

Phone: (864)843-2277

•

Fax: (864)843-3800

•

www.cde.com
