UNISONIC TECHNOLOGIES CO., LTD
U74AHC4066
QUADRUPLE BILATERAL
ANALOG SWITCH
DESCRIPTION
CMOS IC
The
U74AHC4066
is a quadruple bilateral analog switch which
has 4 channels.
FEATURES
* Operate From 2V to 5.5V
* Max t
PD
of 7ns at 5 V
* Low Power Dissipation: I
CC
=20μA(Max)
* Low Input Current: I
I(L)
=1μA(Max)
ORDERING INFORMATION
Ordering Number
Lead Free
Halogen Free
U74AHC4066L-S14-R
U74AHC4066G-S14-R
U74AHC4066L-P14-R
U74AHC4066G-P14-R
Package
SOP-14
TSSOP-14
Packing
Tape Reel
Tape Reel
MARKING
14 13
12
11
10
9
8
UTC
AHC4066
1
2
3
4
5
6
7
Date Code
L: Lead Free
G: Halogen Free
Lot Code
www.unisonic.com.tw
Copyright © 2017 Unisonic Technologies Co., Ltd
1 of 8
QW-R502-419.C
U74AHC4066
PIN CONFIGURATION
1A
1B
2B
2A
2C
3C
GND
1
2
3
4
5
6
7
14
13
12
11
10
9
8
V
CC
1C
4C
4A
4B
3B
3A
CMOS IC
FUNCTION TABLE
SWITCH
ON
OFF
INPUTS CONTROL (C)
H
L
Note: H: HIGH voltage level;
L: LOW voltage level.
LOGIC DIAGRAM
One Of Four Switches
UNISONIC TECHNOLOGIES CO., LTD
www.unisonic.com.tw
2 of 8
QW-R502-419.C
U74AHC4066
ABSOLUTE MAXIMUM RATING
(T
A
=25°С,unless otherwise specified)
PARAMETER
CMOS IC
SYMBOL
RATINGS
UNIT
Supply Voltage
V
CC
-0.5 ~ +7
V
Input Voltage
V
IN
-0.5 ~ +7
V
Switch I/O Voltage
V
IO
-0.5 ~ V
CC
+0.5
V
V
CC
or GND Current
I
CC
±50
mA
Output Clamp Current
I
OK
±50
mA
Input Clamp Current
I
IK
-20
mA
On-State Switch Current
I
T
±25
mA
Operating Temperature
T
OPR
-40 ~ + 85
°С
Storage Temperature
T
STG
-65 ~ + 150
°С
Note: Absolute maximum ratings are those values beyond which the device could be permanently damaged.
Absolute maximum ratings are stress ratings only and functional device operation is not implied.
THERMAL DATA
PARAMETER
SYMBOL
UNIT
°С/W
°С/W
RATINGS
SOP-14
86
Junction to Ambient
θ
JA
TSSOP-14
113
Note: The package thermal impedance is calculated in accordance with JESD 51-7.
RECOMMENDED OPERATING CONDITIONS
SYMBOL
V
CC
V
IH
TEST CONDITIONS
V
CC
=2V
V
CC
=2.3V to 2.7V
V
CC
=3V to 3.6V
V
CC
=4.5V to 5.5V
V
CC
=2V
V
CC
=2.3V to 2.7V
V
CC
=3V to 3.6V
V
CC
=4.5V to 5.5V
MIN
2
1.5
V
CC
x 0.7
V
CC
x 0.7
V
CC
x 0.7
PARAMETER
Supply Voltage
High-Level Input Voltage
TYP
MAX
5.5
UNIT
V
V
0.5
V
CC
x 0.3
V
CC
x 0.3
V
CC
x 0.3
Low-Level Input Voltage
Input Voltage
Output Voltage
Input Transition Rise or Fall Rate
V
IL
V
IN
V
OUT
t
R
/ t
F
V
V
V
ns/V
0
0
V
CC
=2.3V to 2.7V
V
CC
=3V to 3.6V
V
CC
=4.5V to 5.5V
5.5
V
CC
200
100
20
UNISONIC TECHNOLOGIES CO., LTD
www.unisonic.com.tw
3 of 8
QW-R502-419.C
U74AHC4066
ELECTRICAL CHARACTERISTICS
(T
A
=25°С,unless otherwise specified)
PARAMETER
On-state Switch Resistance
SYMBOL
R
ON
TEST CONDITIONS
V
CC
=2.3V
I
T
=-1mA, V
IN
=GND or
V
CC
=3V
V
CC,
V
C
= V
IH
V
CC
=4.5V
V
CC
=2.3V
I
T
=-1mA, V
IN
=GND to
V
CC
=3V
V
CC,
V
C
= V
IH
V
CC
=4.5V
V
CC
=2.3V
I
T
=-1mA, V
IN
=GND to
V
CC
=3V
V
CC,
V
C
= V
IH
V
CC
=4.5V
V
CC
=0 to 5.5V, V
C
= 5.5V or GND
V
CC
=5.5V, V
IN
= V
CC
or GND, V
C
= V
IH
V
CC
=5.5V, V
IN
= V
CC
and V
O
=GND, or
V
IN
=GND and V
O
= V
CC
, V
C
= V
IL
V
CC
=5.5V, V
C
=V
CC
or GND
MIN
TYP
38
29
21
143
57
31
6
3
2
CMOS IC
Peak On-state Resistance
Difference In On-state Resistance
Between Switches
Control Input Current
On-state Switch Leakage Current
Off-state Switch Leakage Current
Quiescent Supply Current
Control Input Capacitance
Feed-through Capacitance
Switch Input/Output Capacitance
R
ON(P)
∆R
ON
I
I(CTL)
I
S(ON)
I
S(OFF)
I
Q
C
IC
C
F
C
IO
MAX UNIT
180
Ω
150
75
500
Ω
180
100
30
Ω
20
15
±0.1
μA
±0.1
μA
±0.1
2
μA
μA
pF
pF
pF
1.5
0.5
5.5
SWITCHING CHARACTERISTICS
(T
A
=25°C, see test circuit and waveforms)
PARAMETER
SYMBOL
TEST CONDITIONS
V
CC
=2.5V±0.2V
C
L
=15pF V
CC
=3.3V±0.3V
V
CC
=5V±0.5V
V
CC
=2.5V±0.2V
C
L
=50pF V
CC
=3.3V±0.3V
V
CC
=5V±0.5V
V
CC
=2.5V±0.2V
C
L
=15pF V
CC
=3.3V±0.3V
V
CC
=5V±0.5V
V
CC
=2.5V±0.2V
C
L
=50pF V
CC
=3.3V±0.3V
V
CC
=5V±0.5V
V
CC
=2.5V±0.2V
C
L
=15pF V
CC
=3.3V±0.3V
V
CC
=5V±0.5V
V
CC
=2.5V±0.2V
C
L
=50pF V
CC
=3.3V±0.3V
V
CC
=5V±0.5V
MIN
TYP MAX UNIT
1.2
10
ns
0.8
6
0.3
4
2.6
12
ns
1.5
9
0.6
6
3.3
15
ns
2.3
11
1.6
7
4.2
25
ns
3
18
2.1
12
6
15
ns
4.5
11
3.2
7
9.6
25
ns
7.2
18
5.1
12
Propagation Delay Time, From A to B Or B to A t
PLH
/t
PHL
Propagation Delay Time, From A to B Or B to A t
PLH
/t
PHL
Switch Turn-on Time, From C to A or B
t
PZL
/t
PZH
Switch Turn-on Time, From C to A or B
t
PZL
/t
PZH
Switch Turn-off Time, From C to A or B
t
PLZ
/t
PHZ
Switch Turn-off Time, From C to A or B
t
PLZ
/t
PHZ
UNISONIC TECHNOLOGIES CO., LTD
www.unisonic.com.tw
4 of 8
QW-R502-419.C
U74AHC4066
ANALOG SWITCHING CHARACTERISTICS
(T
A
=25°С,unless otherwise specified)
PARAMETER
Frequency Response (Switch On),
From A to B Or B to A
Crosstalk (Between Any Switches),
From A to B Or B to A
Crosstalk (Control Input To Signal
Output), From C to A or B
Feed-through Attenuation (Switch
Off), From A to B Or B to A
Sine-wave Distortion
SYMBOL
TEST CONDITIONS
C
L
= 50pF, R
L
=600Ω, V
CC
=2.3V
f
IN
=1MH
Z
,
V
CC
=3V
20log
10
(V
O
/V
I
)=-3dB V
CC
=4.5V
V
CC
=2.3V
C
L
= 50pF, R
L
=600Ω,
V
CC
=3V
f
IN
=1MH
Z
V
CC
=4.5V
V
CC
=2.3V
C
L
= 50pF, R
L
=600Ω,
V
CC
=3V
f
IN
=1MH
Z
V
CC
=4.5V
V
CC
=2.3V
C
L
= 50pF, R
L
=600Ω,
V
CC
=3V
f
IN
=1MH
Z
V
CC
=4.5V
V
CC
=2.3V, V
I
=2 V
P-P
C
L
= 50pF, R
L
=10KΩ,
V
CC
=3V, V
I
=2.5 V
P-P
f
IN
=1KH
Z
V
CC
=4.5V, V
I
=4 V
P-P
MIN
TYP
30
35
50
-45
-45
-45
15
20
50
-40
-40
-40
0.1
0.1
0.1
CMOS IC
MAX UNIT
MHZ
dB
mV
dB
%
OPERATING CHARACTERISTICS
(T
A
=25°С,unless otherwise specified)
SYMBOL
TEST CONDITIONS
C
PD
C
L
=50pF,f=1MHz
MIN
TYP
4.5
MAX UNIT
pF
PARAMETER
Power Dissipation Capacitance
UNISONIC TECHNOLOGIES CO., LTD
www.unisonic.com.tw
5 of 8
QW-R502-419.C
