BZX84B12-E8 datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > Discrete semiconductor> diode> BZX84B12-E8

BZX84B12-E8: DescriptionDIODE 12 V, 0.3 W, SILICON, UNIDIRECTIONAL VOLTAGE REGULATOR DIODE, PLASTIC PACKAGE-3, Voltage Regulator Diode; CategoryDiscrete semiconductor diode; File Size460KB，10 Pages; ManufacturerVishay; Websitehttp://www.vishay.com; Environmental Compliance

Download Datasheet Parametric View All

BZX84B12-E8 Overview

DIODE 12 V, 0.3 W, SILICON, UNIDIRECTIONAL VOLTAGE REGULATOR DIODE, PLASTIC PACKAGE-3, Voltage Regulator Diode

BZX84B12-E8 Parametric

Parameter Name	Attribute value
Is it lead-free?	Lead free
Is it Rohs certified?	conform to
Maker	Vishay
package instruction	R-PDSO-G3
Contacts	3
Reach Compliance Code	unknown
ECCN code	EAR99
Configuration	SINGLE
Diode component materials	SILICON
Diode type	ZENER DIODE
Maximum dynamic impedance	25 Ω
JESD-30 code	R-PDSO-G3
JESD-609 code	e3
Humidity sensitivity level	1
Number of components	1
Number of terminals	3
Maximum operating temperature	150 °C
Package body material	PLASTIC/EPOXY
Package shape	RECTANGULAR
Package form	SMALL OUTLINE
Peak Reflow Temperature (Celsius)	260
polarity	UNIDIRECTIONAL
Maximum power dissipation	0.3 W
Certification status	Not Qualified
Nominal reference voltage	12 V
surface mount	YES
technology	ZENER
Terminal surface	Matte Tin (Sn)
Terminal form	GULL WING
Terminal location	DUAL
Maximum time at peak reflow temperature	40
Maximum voltage tolerance	2%
Working test current	5 mA
Base Number Matches	1

Preview

Download Datasheet

View All

VISHAY

BZX84 Series

Vishay Semiconductors

Zener Diodes

Features

• These diodes are also available in other case

styles and other configurations including: the

SOD-123 case with type designation BZT52

series, the dual zener diode common anode con-

figuration in the SOT-23 case with type designa-

tion AZ23

series and the dual zener diode common cathode

configuration in the SOT-23 case with type desig-

nation DZ23 series.

• The Zener voltages are graded according to the

international E 24 standard. Standard Zener volt-

age tolerance is ± 5 %. Replace "C" with "B" for

± 2 % tolerance. Other voltage tolerances and

other Zener voltages are available upon request.

• Silicon Planar Power Zener Diodes

18078

Mechanical Data

Case:

SOT-23 Plastic Package

Weight:

Approx. 8 mg

Packaging Codes/Options:

E8 / 10k per 13 " reel (8 mm tape), 30k/box

E9 / 3k per 7 " reel (8 mm tape), 30k/box

Absolute Maximum Ratings

amb

= 25 °C, unless otherwise specified

Parameter

Power dissipation

Test condition

Symbol

tot

Value

300

Unit

Device on fiberglass substrate, see layout.

Thermal Characteristics

amb

= 25 °C, unless otherwise specified

Parameter

Thermal resistance junction to ambient air

Junction temperature

Storage temperature range

Test condition

Symbol

θJA

Value

420

150

- 65 to + 150

Unit

°C/W

°C

Device on fiberglass substrate, see layout.

Document Number 85763

Rev. 2, 15-Jul-03

www.vishay.com
