ZLTMM-120-63-L-D-285 datasheet, PDF

Datasheet> All Categories > The connector> The connector> ZLTMM-120-63-L-D-285

ZLTMM-120-63-L-D-285: DescriptionBoard Stacking Connector, 40 Contact(s), 2 Row(s), Male, Straight, Solder Terminal, ROHS COMPLIANT; CategoryThe connector The connector; File Size770KB，1 Pages; ManufacturerSAMTEC; Websitehttp://www.samtec.com/; Environmental Compliance

Download Datasheet Parametric View All

ZLTMM-120-63-L-D-285 Overview

Board Stacking Connector, 40 Contact(s), 2 Row(s), Male, Straight, Solder Terminal, ROHS COMPLIANT

ZLTMM-120-63-L-D-285 Parametric

Parameter Name	Attribute value
Is it lead-free?	Lead free
Is it Rohs certified?	conform to
Objectid	1666986059
package instruction	ROHS COMPLIANT
Reach Compliance Code	compliant
ECCN code	EAR99
Factory Lead Time	2 weeks
YTEOL	8.57
Connector type	BOARD STACKING CONNECTOR
Contact to complete cooperation	GOLD (10) OVER NICKEL (50)
Contact completed and terminated	TIN OVER NICKEL
Contact point gender	MALE
Contact material	PHOSPHOR BRONZE
DIN compliance	NO
Filter function	NO
IEC compliance	NO
JESD-609 code	e3
MIL compliance	NO
Manufacturer's serial number	ZLTMM
Plug information	MULTIPLE MATING PARTS AVAILABLE
Mixed contacts	NO
Installation method	STRAIGHT
Installation type	BOARD
Number of rows loaded	2
Options	GENERAL PURPOSE
Terminal pitch	2 mm
Termination type	SOLDER
Total number of contacts	40

Preview

Download Datasheet

View All

F-213-1

ZLTMM–112–75–L–D–285

LTMM–110–02–F–D–RA

LTMM–113–02–T–D

(2,00 mm) .0787"

LTMM, ZLTMM SERIES

SHROUDED HEADER & STACKER

Mates with:

SQT, SQW, ESQT, SMM

LTMM

NO. PINS

PER ROW

PLATING

OPTION

TAIL

OPTION

OTHER

OPTION

SPECIFICATIONS

For complete speciﬁcations and

recommended PCB layouts

see www.samtec.com?LTMM

or www.samtec.com?ZLTMM

Insulator Material:

High Temperature

Nylon

Terminal Material:

Phosphor Bronze

Plating:

Sn or Au over

50µ" (1,27 µm) Ni

Current Rating:

3A per contact @ 80°C ambient

Operating Temp Range:

-55°C to +105°C with Tin;

-55°C to +125°C with Gold

RoHS Compliant:

Yes

–“XX”

05, 08, 10, 12, 13,

15, 17, 20, 22, 25

(Call Samtec for other sizes)

(2,00) .0787 x

No. of positions + (2,39) .094

(2,00) .0787 x

No. of positions + (0,61) .024

02 04

–F

= Gold ﬂash on post,

Matte Tin on tail

Leave blank for

Through-hole

= Polarized

Position

–RA

= Right

Angle

–LC

= Locking

Clip

(-SM only)

(Manual

placement

required)

–L

= 10µ" (0,25 µm) Gold on post,

Matte Tin on tail

(0,51)

.020

–SM

= Surface Mount

–T

= Matte Tin

(6,00)

.237

–K

(0,89)

.035

(0,38)

.015

(1,27)

.050

(7,79)

.307

(2,00)

.0787

(2,29)

.090

(1,52)

.060

Processing:

Lead–Free Solderable:

Yes

SMT Lead Coplanarity:

(0,10 mm) .004" max

(2,00)

.0787

(2,97)

.117

01 03

(3,55)

.140

(2,00) .0787

= (7,50 mm)

.295" DIA

Film Pick &

Place Pad

(-SM only)

(4,80)

.190

(0,38)

.015

–TR

= Tape & Reel

(–SM only)

–RA

ALSO

AVAILABLE

Shrouded IDC headers

and stackers to mate

with TCSD Series.

See STMM and

ZSTMM Series.

(0,51) .020 SQ

T/H

–SM

–RA

–SM

ZLTMM

NO. PINS

PER ROW

LEAD

STYLE

Specify

LEAD

STYLE

from

chart.

PLATING

OPTION

BODY

HEIGHT

OTHER

OPTION

–“XXX”

–F

= Gold ﬂash on post,

Matte Tin on tail

= Body

Height

LEAD

STYLE

–75

–62

–65

–73

–63

–66

–69

–74

–70

–71

–72

(OAL)

(9,58) 0.377

–“XX”

= Polarized

Position

MAX BODY

HEIGHT

(7,42) 0.292

05, 08, 10, 12, 13,

15, 17, 20, 22, 25

(Call Samtec for other sizes)

(0,51)

.020

(2,00) .0787 x

No. of positions + (2,39) .094

(2,00) .0787 x

No. of positions + (0,61) .024

02 04

–L

= 10µ" (0,25 µm)

Gold on post,

Matte Tin on tail

(6,00)

.237

(10,08) 0.397 (7,92) 0.312

(10,49) 0.413 (8,33) 0.328

(12,09) 0.476 (9,93) 0.391

(14,10) 0.555 (11,94) 0.470

(15,09) 0.594 (12,93) 0.509

(15,60) 0.614 (13,44) 0.529

(17,09) 0.673 (14,94) 0.588

(17,60) 0.693 (15,44) 0.608

(21,08) 0.830 (18,92) 0.745

(21,62) 0.851 (19,46) 0.766

–T

= Matte Tin

(3,18)

.125

(3,05)

.120

(2,00)

.0787

01 03

(3,55)

.140

(2,00)

.0787

(4,80)

.190

BODY

HEIGHT

(6,35)

.250

(OAL) MIN

Note:

Other Gold plating

options available.

Contact Samtec.

Note:

This Series is

non-standard, non-returnable.

(0,38)

.015

(0,51)

.020

(2,29)

.090

MIN

Note:

For added mechanical stability,

Samtec recommends mechanical

board spacers be used in applications

with gold or selective gold plated

connectors. Contact ipg@samtec.com

for more information.

WWW.SAMTEC.COM
