IP5-01-05.0-L-S-1: DescriptionBoard Connector, 1 Contact(s), 1 Row(s), Male, Straight, Solder Terminal, Plug, ROHS COMPLIANT; CategoryThe connector The connector; File Size575KB，1 Pages; ManufacturerSAMTEC; Websitehttp://www.samtec.com/

Download Datasheet Parametric Compare View All

IP5-01-05.0-L-S-1 Overview

Board Connector, 1 Contact(s), 1 Row(s), Male, Straight, Solder Terminal, Plug, ROHS COMPLIANT

IP5-01-05.0-L-S-1 Parametric

Parameter Name	Attribute value
Maker	SAMTEC
package instruction	ROHS COMPLIANT
Reach Compliance Code	compliant
Body/casing type	PLUG
Connector type	BOARD CONNECTOR
Contact to complete cooperation	GOLD (10) OVER NICKEL
Contact completed and terminated	GOLD (10) OVER NICKEL
Contact point gender	MALE
DIN compliance	NO
Filter function	NO
IEC compliance	NO
JESD-609 code	e4
MIL compliance	NO
Manufacturer's serial number	IP5
Plug information	MULTIPLE MATING PARTS AVAILABLE
Mixed contacts	NO
Installation method	STRAIGHT
Installation type	BOARD
Number of rows loaded	1
Options	GENERAL PURPOSE
Terminal pitch	4 mm
Termination type	SOLDER
Total number of contacts	1
Base Number Matches	1

Preview

Download Datasheet

View All

F-209-1

IJ5–08–05.0–L–S–1–GP

IJ5–04–05.0–L–S–1–GP

TM

IP5–08–05.0–L–S–1

50

Ω

ISORATE JACK & PLUG

™

SPECIFICATIONS

For complete speciﬁcations and

recommended PCB layouts see

www.samtec.com?IJ5 or

www.samtec.com?IP5

Shell Material:

Copper Alloy

Insulator Material:

Black LCP

Contact Material:

Copper Alloy

Pin Material:

Brass

Dielectric Material:

Black LCP

Plating:

Au over 50µ" (1,27µm) Ni

Operating Temp Range:

-40°C to +90°C

Insulation Resistance:

Testing Now!

Contact Resistance:

Center: Testing Now!

Outer: Testing Now!

Impedance:

Testing Now!

Dielectric Withstanding

Voltage:

Testing Now!

Dielectric Working Voltage:

Testing Now!

Frequency Range:

Testing Now!

RoHS Compliant:

Yes

IJ5, IP5

SERIES

GUIDE

POST

IJ5

Mates with:

IP5

JACKS

PER ROW

05.0

PLATING

ROW

OPTION

TAIL

–L

–S

= Single

Row

–1

= (1,57mm)

.062"

board

thickness

–01, –02,

–04, –08

A

= 10µ"

(0,25µm)

Gold

–GP

= Guide

Post

–D

= Double

Row

(Not available

with –01)

(2,03)

.080

NO. OF

JACKS

–01

A

(5,55)

.219

(9,55)

.376

(17,55)

.691

(33,55)

1.321

(5,74)

.226

(4,00)

.1575

(6,50)

.256

(9,73)

.383

–02

–04

–08

(6,05)

.238

(4,00)

.158

–S (–GP)

–D

ALSO

AVAILABLE

For cable see

IJ5C Series.

Processing:

Lead-Free Solderable:

Yes

IP5

Mates with:

IJ5

ALSO

AVAILABLE

75Ω system.

See IJ7/IP7 Series

PLUGS

PER ROW

05.0

PLATING

ROW

OPTION

TAIL

OPTION

–L

–S

= Single Row

–1

= (1,57mm)

.062"

board

thickness

–L

= Cable

Latch

(Single

Row only)

APPLICATION

IJ5

–01, –02,

–04, –08

A

= 10µ"

(0,25µm)

Gold

–D

= Double Row

(Not available

with –01)

NO. OF

PLUGS

–01

A

(8,33)

.328

(12,32)

.485

(20,32)

.800

(36,32)

1.430

10mm

(8,53)

.336

(12,52)

.493

(4,00)

.1575

–02

–04

(1,52) .060

–08

IP5

Other stack heights and

PCB thicknesses available.

Call Samtec.

(1,52)

.060

(9,09)

.358

–S

–D

(4,00)

.158

WWW.SAMTEC.COM
