SMQ-Series(Snap-in)
ALUMINUM ELECTROLYTIC CAPACITORS
LARGE CAPACITANCE ALUMINUM ELECTROLYTIC CAPACITORS
KLM
@15mm
height snap-ins
@Endurance
with ripple current : 105C 2000 hours
@Non
solvent-proof type
15mm height snap-ins, 105C
low profile
KMH
?SPECIFICATIONS
Items
Category
Temperature Range
Rated Voltage Range
Capacitance Tolerance
Leakage Current
Dissipation Factor
(tane)
Low Temperature
Characteristics
(Max. Impedance Ratio)
Endurance
-25 to +105C
160 to 400V
dc
P20%
(M)
I[3 CV
Where, I : Max. leakage current (MA), C : Nominal capacitance (MF), V : Rated voltage (V)
Rated voltage (V
dc
)
160 to 400V
tanE (Max.)
0.20
Rated voltage (V
dc
)
160 to 400V
Z (-25C) /Z (+20C)
4
Characteristics
(at 20C, 120Hz)
(at 20C after 5 minutes)
(at 20C, 120Hz)
Shelf Life
(at 120Hz)
The following specifications shall be satisfied when the capacitors are restored to 20C after subjected to DC voltage with the rated
ripple current is applied for 2000 hours at 105C.
Capacitance change
[P20%
of the initial value
D.F. (tanE)
[200%
of the initial specified value
Leakage current
[The
initial specified value
The following specifications shall be satisfied when the capacitors are restored to 20C after exposing them for 1000 hours at 105C without
voltage applied.
Capacitance change
[P15%
of the initial value
D.F. (tanE)
[150%
of the initial specified value
Leakage current
[The
initial specified value
?DIMENSIONS
[mm]
@Terminal
Type : VSSN
Sleeve
FD+1max.
?PART
NUMBERING SYSTEM
KLM 200
Negative mark
PC board pin-out
VSSN 150
M
Cap tolerance (P20%)
Nominal cap in
MF
Terminal type
Rated voltage in volts
Series name
Vent
LP2
4.0P0.5
2-F2
10
*No plastic disk is the standard design.
?STANDARD
RATINGS
V
dc
Items
fDbL
(mm)
22b15
25.4b15
30b15
35b15
160
180
200
250
400
Capacitance Rated ripple Capacitance Rated ripple Capacitance Rated ripple Capacitance Rated ripple Capacitance Rated ripple
(Arms/105c
(Arms/105c
(Arms/105c
(Arms/105c
(Arms/105c
120Hz)
120Hz)
120Hz)
120Hz)
120Hz)
(mF)
(mF)
(mF)
(mF)
(mF)
150
180
220
270
330
390
0.68
0.79
0.88
0.96
1.06
1.20
120
150
180
220
270
330
390
0.61
0.73
0.79
0.86
0.96
1.10
1.17
120
150
180
220
270
330
0.61
0.73
0.79
0.90
1.00
1.07
82
100
120
150
180
220
0.50
0.59
0.65
0.71
0.79
0.90
39
47
56
68
82
100
120
0.35
0.40
0.44
0.46
0.51
0.56
0.62
?RATED
RIPPLE CURRENT MULTIPLIERS
@Frequency
Multipliers
Frequency (Hz)
160 to 250V
dc
400V
dc
50
0.81
0.77
120
1.00
1.00
300
1.17
1.16
1k
1.32
1.30
10k
1.45
1.41
50k
1.50
1.43
(1/1)
CAT. No. E1001D
