IRFU120_R4941 Overview

Power Field-Effect Transistor, N-Channel, Metal-oxide Semiconductor FET

IRFU120_R4941 Parametric

Parameter Name	Attribute value
Is it Rohs certified?	incompatible
package instruction	,
Reach Compliance Code	unknown
Configuration	Single
Maximum drain current (Abs) (ID)	8.4 A
FET technology	METAL-OXIDE SEMICONDUCTOR
JESD-609 code	e0
Operating mode	ENHANCEMENT MODE
Maximum operating temperature	175 °C
Polarity/channel type	N-CHANNEL
Maximum power dissipation(Abs)	50 W
surface mount	NO
Terminal surface	Tin/Lead (Sn/Pb)
Base Number Matches	1

Preview

Download Datasheet

View All

IRFR120, IRFU120

Data Sheet

January 2002

8.4A, 100V, 0.270 Ohm, N-Channel

Power MOSFETs

These are N-Channel enhancement mode silicon gate

power field effect transistors. They are advanced power

MOSFETs designed, tested, and guaranteed to withstand a

specified level of energy in the breakdown avalanche mode

of operation. All of these power MOSFETs are designed for

applications such as switching regulators, switching

convertors, motor drivers, relay drivers, and drivers for high

power bipolar switching transistors requiring high speed and

low gate drive power. These types can be operated directly

from integrated circuits.

Formerly developmental type TA09594.

Features

• 8.4A, 100V

• r

DS(ON)

= 0.270Ω

• Single Pulse Avalanche Energy Rated

• SOA is Power Dissipation Limited

• Nanosecond Switching Speeds

• Linear Transfer Characteristics

• High Input Impedance

• Related Literature

- TB334 “Guidelines for Soldering Surface Mount

Components to PC Boards”

Ordering Information

PART NUMBER

IRFR120

IRFU120

PACKAGE

TO-252AA

TO-251AA

BRAND

IFR120

IFU120

Symbol

NOTE: When ordering, use the entire part number. Add the suffix T to

obtain the TO-252AA variant in the tape and reel, i.e., IRFR120T.

Packaging

JEDEC TO-251AA

SOURCE

DRAIN

GATE

JEDEC TO-252AA

DRAIN

(FLANGE)

DRAIN

DRAIN (FLANGE)

SOURCE

IRFR120, IRFU120 Rev. B
