SN55110AW

Description
Line Driver, 2 Func, 2 Driver, BIPolar, CDFP14, CERAMIC, DFP-14
CategoryAnalog mixed-signal IC    Drivers and interfaces
File Size924KB,10 Pages
ManufacturerRochester Electronics
Websitehttps://www.rocelec.com/
Download Datasheet Parametric Compare View All

SN55110AW Overview

Line Driver, 2 Func, 2 Driver, BIPolar, CDFP14, CERAMIC, DFP-14

SN55110AW Parametric

Parameter NameAttribute value
MakerRochester Electronics
Parts packaging codeDFP
package instructionDFP,
Contacts14
Reach Compliance Codeunknown
ECCN codeEAR99
Other featuresHIGH DRIVE
Differential outputYES
Number of drives2
Input propertiesGATED
Interface integrated circuit typeLINE DRIVER
Interface standardsV.35
JESD-30 codeR-GDFP-F14
length9.21 mm
Nominal negative supply voltage-5 V
Number of functions2
Number of terminals14
Maximum operating temperature125 °C
Minimum operating temperature-55 °C
Package body materialCERAMIC, GLASS-SEALED
encapsulated codeDFP
Package shapeRECTANGULAR
Package formFLATPACK
Certification statusNot Qualified
Maximum seat height2.03 mm
Maximum supply voltage5.5 V
Minimum supply voltage4.5 V
Nominal supply voltage5 V
surface mountYES
technologyBIPOLAR
Temperature levelMILITARY
Terminal formFLAT
Terminal pitch1.27 mm
Terminal locationDUAL
maximum transmission delay25 ns
width6.285 mm
Base Number Matches1
