Relays - RIDERSERIES
Digital signalling
RCL relay
1 CO contact AC/DC coil
• 3000 or 4000 VA switching capacity
• Low height of 15.7 mm
• For boiler controls, timing relays, garage door controls,
Interface modules
15.7
29.0
12.7
• Hard gold-plated contacts available
C
PCB layout / terminal assignment
View on
solder
pins,
dimensions in mm
1 C/O changeover contacts
12 A, Pinning 3.5 mm
1.3
+0.1
2.52*
2.3
3.5
3.5
1 C/O changeover contacts
16 A, Pinning 5 mm
1.3
+0.1
2.52
*
2.3
5.0
5.0
2.52
*
Output
max. switching voltage AC1
Continuous current
Contact base material
Mechanical endurance
Response time / Drop-out time
Rated data
Status indicator/Free wheel diode
Operating temperature
UL 94 flammability rating
Approvals
Insulation coordination (IEC 60664)
Rated voltage
Creepage and clearance path input - output
Surge category
Pollution severity
Protective separation to VDE 0106 part 101
250 V
12 A for 3.5 mm / 16 A for 5 mm pinning
AgNi 90/10 or AgNi 5µm Au
AC coil 10*10
6
/ DC coil 30*10
6
switching operations
7 ms / 3 ms
no/no
-40 °C…+70 °C
V-0
cURus; VDE;
250 V
10 mm
III
3
yes
2.52
*
Dimensions
Length x width x height
Note
mm
29 / 12.7 / 15.7
Applications
DC load breaking capacity
Switching
voltage [V DC]
Resistive load
Coil voltage [U/Un]
Operating voltage range DC
0A
16 A
12 A
Un Rated coil voltage
Switching
current [A]
Ambient temperature [C]
Electrical endurance
Switching
Operations
250 V AC
Resistive load
12/16 A
Operating voltage range AC
Coil voltage [U/Un]
DC coil
AC coil
0A
16 A
Un Rated coil voltage
Switching
current [A]
Ambient temperature [C]
C.32
3.8
Relays - RIDERSERIES
RCL
DC coil
006
6 V DC
012
12 V DC
024
24 V DC
048
48 V DC
060
60 V DC
110 110 V DC
AC coil
512
12 V AC
524
24 V AC
548
48 V AC
615 115 V AC
730 230 V AC
Type
RIDER Control Low
Type of construction
1 12 A, Pitch 3.5 mm, flux proof
3 16 A, Pitch 5 mm, flux proof
Type of contact
1 1 CO contacts
3 1 NO contacts
Contact material
4 AgNi 90/10
5 AgNi 90/10 hgp
Ordering data
Input
Rated voltage
DC Response/dropout Volt
Power rating
Rated current DC
Coil resistance
6 V DC 1CO
6 V DC
4.2 V / 0.6 V
500 mW
66.7 mA
90
Ω
±10%
12 V DC 1CO
12 V DC
8.4 V / 1.2 V
500 mW
33.3 mA
360
Ω
±10%
24 V DC 1CO
24 V DC
16.8 V / 2.4 V
500 mW
16.7 mA
1440
Ω
±10%
48 V DC 1CO
48 V DC
33.6 V / 4.8 V
500 mW
8.7 mA
5520
Ω
±10%
C
Ordering data
Relay
12 A / 3.5 mm
AgNi 90/10
16 A / 5 mm
AgNi 90/10
16 A / 5 mm
AgNi 5µm Au
Type
Order No.
Type
Order No.
Type
Order No.
RCL114006
8693400000
RCL314006
8693800000
RCL114012
8693190000
RCL314012
8693240000
RCL315012
on request
RCL114024
8693180000
RCL314024
8693260000
RCL315024
8824830000
RCL114048
8693480000
RCL314048
8693380000
RCL315048
on request
Note
Ordering data
Input
Rated voltage
AC Response/dropout Volt
Power rating
Rated current AC
Coil resistance
24 V AC 1CO
24 V AC
18.0 V / 3.6 V
0.75 VA
31.6 mA
1440
Ω
±10%
48 V AC 1CO
48 V AC
64 V / 7,2 V
0.75 VA
15,6 mA
1420
Ω
±10%
115 V AC 1CO
115 V AC
86.3 V / 17.3 V
0.75 VA
6.6 mA
8100
Ω
±15%
230 V AC 1CO
230 V AC
172.5 V / 34.5 V
0.75 VA
3.2 mA
32500
Ω
±15%
Ordering data
Relay
12 A / 3.5 mm
AgNi 90/10
16 A / 5 mm
AgNi 90/10
16 A / 5 mm
AgNi 5µm Au
Type
Order No.
Type
Order No.
Type
Order No.
RCL114524
8693220000
RCL314524
8693500000
RCL315524
8824870000
RCL114548
8693510000
RCL314548
8693880000
RCL315548
on request
RCL114615
8693390000
RCL314615
8693890000
RCL315615
8824880000
RCL114730
8693230000
RCL314730
8693320000
RCL315730
8824890000
Note
C.33
Digital signalling
RCL relay
1 CO contact AC/DC coil
Type code
