CAUTION: Stresses above those listed in “Absolute Maximum Ratings” may cause permanent damage to the device. This is a stress only rating and operation of the
device at these or any other conditions above those indicated in the operational sections of this specification is not implied.
IMPORTANT NOTE: All parameters having Min/Max specifications are guaranteed. Typical values are for information purposes only. Unless otherwise noted, all tests
are at the specified temperature and are pulsed tests, therefore: T
J
= T
C
= T
A
Electrical Specifications
PARAMETER
AC PERFORMANCE
BW
HD
dG
d
SR
V
S
= ±7.5V, R
F
= 1.5k, R
L
= 100 to mid supply, T
A
= +25°C unless otherwise specified.
DESCRIPTION
CONDITIONS
MIN
TYP
MAX
UNIT
-3dB Bandwidth
Total Harmonic Distortion
Differential Gain
Differential Phase
Slewrate
A
V
= +4
f = 150kHz, V
O
= 16V
P-P
, R
L
= 25
A
V
= +2, R
L
= 37.5
A
V
= +2, R
L
= 37.5
V
OUT
from -3V to +3V
70
-85
0.15
0.1
500
MHz
dBc
%
°
V/µs
DC PERFORMANCE
V
OS
V
OS
R
OL
Offset Voltage
V
OS
Mismatch
Transimpedance
V
OUT
from -4.5V to +4.5V
-20
-10
0.7
1.4
20
10
2.5
mV
mV
M
INPUT CHARACTERISTICS
I
B
+
I
B
-
I
B
-
e
N
i
N
V
IH
V
IL
I
IH1
I
IH0
I
IL
Non-Inverting Input Bias Current
Inverting Input Bias Current
I
B
- Mismatch
Input Noise Voltage
-Input Noise Current
Input High Voltage
Input Low Voltage
Input High Current for C
1
Input High Current for C
0
Input Low Current for C
1
or C
0
C
0
and C
1
inputs
C
0
and C
1
inputs
C
1
= 5V
C
0
= 5V
C
1
= 0V, C
0
= 0V
0.2
0.1
-1
2.3
1.5
8
4
1
-5
-30
-30
2.8
19
5
30
30
µA
µA
µA
nV/
Hz
pA/
Hz
V
V
µA
µA
µA
OUTPUT CHARACTERISTICS
V
OUT
Loaded Output Swing (single ended)
V
S
= ±7.5, R
L
= 100to GND
V
S
= ±7.5, R
L
= 25to GND
I
OUT
SUPPLY
V
S
I
S
+ (Full Power)
I
S
- (Full Power)
I
S
+ (3/4 Power)
Supply Voltage
Positive Supply Current per Amplifier
Negative Supply Current per Amplifier
Positive Supply Current per Amplifier
Single supply
All outputs at 0V, C
0
= C
1
= 0V
All outputs at 0V, C
0
= C
1
= 0V
All outputs at 0V, C
0
= 5V, C
1
= 0V
5
7
-6.4
5.3
15
9.25
-8.75
7.25
V
mA
mA
mA
Output Current
R
L
= 0
±6.3
±5.7
±6.5
±6.0
450
V
V
mA
FN7016 Rev 2.00
April 10, 2007
Page 3 of 18
EL1511
Electrical Specifications
PARAMETER
I
S
- (3/4 Power)
I
S
+ (1/2 Power)
I
S
- (1/2 Power)
V
S
= ±7.5V, R
F
= 1.5k, R
L
= 100 to mid supply, T
A
= +25°C unless otherwise specified.
(Continued)
DESCRIPTION
Negative Supply Current per Amplifier
Positive Supply Current per Amplifier
Negative Supply Current per Amplifier
CONDITIONS
All outputs at 0V, C
0
= 5V, C
1
= 0V
All outputs at 0V, C
0
= 0V, C
1
= 5V
All outputs at 0V, C
0
= 0V, C
1
= 5V
All outputs at 0V, C
0
= C
1
= 5V
All outputs at 0V, C
0
= C
1
= 5V
All outputs at 0V
MIN
TYP
-4.7
3.3
-2.7
0.6
0
0.6
MAX
-6.75
5.75
-5.2
1.025
-0.525
1
UNIT
mA
mA
mA
mA
mA
mA
I
S
+ (Power Down) Positive Supply Current per Amplifier
