Zener Diodes
MAZ7000
Series
Silicon planar type
Unit : mm
For stabilization of power supply
φ
0.65 max.
•
Large power dissipation P
tot
(800 mW)
•
Allowing to supply with the radial taping
27 min.
I
Features
Cathode
Colored band indicates
Vz classification
Parameter
Repetitive peak forward current
Total power dissipation
*1
Non-repetitive reverse surge
power dissipation
*2
Junction temperature
Storage temperature
Symbol
I
FRM
P
tot
P
ZSM
T
j
T
stg
Rating
200
800
60
200
−55
to
+200
Unit
mA
W
W
°C
°C
27 min.
φ
3.0 max.
Anode
Colored bands indicates type No.
Cathode on the first band (wide)
1 : Cathode
2 : Anode
JEDEC : DO-41
Note) *1 : P
tot
= 800 mW achieved with a printed-circuit board
*2 : t = 100
µs,
T
j
= 150°C
•
Color indication of V
Z
rank classification
A rank
Blue
B rank
Red
I
Common Electrical Characteristics
T
a
= 25°C
*1
Parameter
Forward voltage
Zener voltage
*2
Operating resistance
Reverse current
Temperature coefficient of zener voltage
Terminal capacitance
*3
Symbol
V
F
V
Z
R
Z
I
R
S
Z
C
t
I
F
= 200 mA
Conditions
Min
Typ
3rd Band
2nd Band
1st Band
I
Absolute Maximum Ratings
T
a
= 25°C
5.0 max.
Max
1.0
Unit
V
V
Ω
µA
mV/°C
pF
I
Z ··················
Specified value
I
Z ··················
Specified value
V
R ···············
Specified value
I
Z ··················
Specified value
V
R ···············
Specified value
Refer to the list of the
electrical characteristics
within part numbers
Note) 1．
Rated input/output frequency: 5 MHz
2． 1 : The V
Z
value is for the temperature of 25°C. In other cases, carry out the temperature compensation.
*
*2 : Guaranteed at 20 ms after power application.
*3 : T
j
= 25°C to 150°C
1
