REVISION AH
DO NOT
SCALE FROM
THIS PRINT
NOTES:
1.
C
REPRESENTS A CRITICAL DIMENSION.
MMSSX-XX-XXX-X-XX.XX-X-X-XXX
2. BURR ALLOWANCE: .003[0.08] MAX.
3. PARTS TO BE MOLDED TO POSITION.
OPTION
FEP CABLE OPTION
4. MINIMUM PULLOUT FORCE: 5 lbs [22.24 N].
-T: FEP INSULATION
SINGLE
5. CONTACT MUST BE INSERTED UNTIL RETENTION FEATURE LOCKS
(LEAVE BLANK FOR
INTO PLACE.
-M: METAL LATCH (USE IPD1-XX-S-X-M)
C
6. ALL FINISHED GOODS ARE TO BE ELECTRICAL TESTED INCLUDING
STANDARD PVC INSULATION)
(LEAVE BLANK FOR PLASTIC)
(SEE NOTE 13)
HI-POT TEST @ 1000 VOLTS DC. AFTER FINAL ELECTRICAL TEST,
LABEL EACH ASSEMBLY WITH 1 ET STAMP ON THE BODY.
DOUBLE
7. TINNED COPPER WIRE IS ROHS COMPLIANT.
[MUST BE USED ON -D END OPTION ONLY
No OF POSITIONS
8. FOLLOW CO-RF-WI-3001-M AND SAMTEC PACKAGING STANDARDS.
& APPLIES TO END 2 HOUSING]
-02 THRU -25
9. CONTACTS OFFSET FOR POLARIZATION.
-LUS: PLASTIC LATCH UP, STRAIGHT
10. REFER TO CRIMP SPECIFICATIONS PRINT FOR CRIMP AND STRIP
-LDS: PLASTIC LATCH DOWN, STRAIGHT
DIMENSIONS, TOLERANCES, TOOLING AND ITS REQUIREMENTS.
WIRE GAUGE (AWG)
-MUS: METAL LATCH UP, STRAIGHT
11. FOR LENGTHS LESS THAN 12 IN, TOLERANCE SHALL BE ±.125[3.18].
-MDS: METAL LATCH DOWN, STRAIGHT
PVC:-20, -22, -24, -26, -28, -30
FOR OTHER LENGTHS, TOLERANCES SHALL BE ± 2%.
FEP:-20, -24, -28, 30
12. GOLD PLATING IS NOT REQUIRED ON THE OUTSIDE OF THE CONTACT
OPTION
BOX OR ON THE SIDE WITH THE RETENTION LANCE.
-K: KEYED POLARIZATION
13. ASSEMBLIES USING THE FEP OPTION ARE
(USE IPD1-XX-S-K)
COLOR CODE
FOR CRIMP APPLICATIONS ONLY.
(SEE FIG 3, SHEET 2)
C (SEE TABLE 2)
14. CUT LENGTH IS ASSEMBLY LENGTH MINUS OVERALL LENGTH SUBTRACTOR.
(LEAVE BLANK FOR NO POLARIZATION;
(LEAVE BLANK FOR
AVAILABLE TO EXISTING CUSTOMERS ONLY)
STANDARD BLACK CABLE)
(No OF POS x .100[2.54])
(NOT AVAILABLE WITH FEP OPTION)
END OPTION
+ .055[1.40] REF
PLATING SPECIFICATION
02 01
-S: SINGLE END
-F: FLASH SELECTIVE (USE C-179-XX-F)
-D: DOUBLE END(MUST CHOOSE XUS OR XDS OPTIONS.)
-L: LIGHT SELECTIVE (USE C-179-XX-L)
.300 7.62
.200 5.08
ASSEMBLED LENGTH
-S: SELECTIVE (USE C-179-XX-S)
C
L
REF
REF
SPECIFY IN INCHES [USE DWCX-XX-XX]
(SINGLE END: 03.00[76.2] INCH MINIMUM,
DOUBLE END: 03.25[82.6] INCH MINIMUM)
.010 0.25 REF
(SEE NOTE 9)
"A"
IPD1-XX-S
.505 12.83
REF
C-179-XX-X
.285 7.24
REF
C
XX.XX
(SEE NOTE 11)
C
DWC-XX-10-300
XX.XX
(SEE NOTE 11)
"A"
FIG 1
MMSS-05-22-X-XX.XX-S SHOWN
SECTION "A"-"A"
UNLESS OTHERWISE SPECIFIED,
DIMENSIONS ARE IN INCHES.
TOLERANCES ARE:
DECIMALS
*
PROPRIETARY NOTE
*
THIS DOCUMENT CONTAINS CONFIDENTIAL AND
PROPRIETARY INFORMATION AND ALL DESIGN,
MANUFACTURING, REPRODUCTION, USE, PATENT RIGHTS
AND SALES RIGHTS ARE EXPRESSLY RESERVED BY SAMTEC,
INC. THIS DOCUMENT SHALL NOT BE DISCLOSED, IN WHOLE
OR PART, TO ANY UNAUTHORIZED PERSON OR ENTITY NOR
REPRODUCED, TRANSFERRED OR INCORPORATED IN ANY
OTHER PROJECT IN ANY MANNER WITHOUT THE EXPRESS
WRITTEN CONSENT OF SAMTEC, INC.
FIG 2
MMSS-05-22-X-XX.XX-D-LUS SHOWN
.XX: .01 [0.3]
2
.XXX: .005 [0.13]
.XXXX: .0020 [0.051]
ANGLES
520 PARK EAST BLVD, NEW ALBANY, IN 47150
PHONE: 812-944-6733
FAX: 812-948-5047
e-Mail info@SAMTEC.com
code 55322
DESCRIPTION:
MATERIAL:
DO NOT SCALE DRAWING
SHEET SCALE: 1.5:1
HOUSING: NYLON 6/6, COLOR: WHITE
CONTACT: PHOS BRONZE
CABLE; INSULATION: SEE CALLOUT
WIRE: TINNED COPPER
F:\DWG\MISC\MKTG\MMSSX-XX-XXX-X-XX.XX-X-X-XXX-MKT.SLDDRW
.100[2.54] SOCKET DISCREET CABLE ASSEMBLY
DWG. NO.
MMSSX-XX-XXX-X-XX.XX-X-X-XXX
BY:
DEAN P
05/03/2005
SHEET
1
OF
3
REVISION AH
01
N
N
N
N
LATCH-
END 2
01
LATCH-
END 1
01
01
LATCH-
END 1
[LATCH UP- CABLE STRAIGHT]
-LUS
LATCH-
END 2
-LDS
[LATCH DOWN- CABLE STRAIGHT]
FIG 3
-K: KEYED POLARIZATION
(MMSSX-06-XX-X-XX.XX-X-K-XXX SHOWN)
(SAME AS FIG 1, UNLESS OTHERWISE STATED)
.023 0.59 REF
.027 0.68 REF
*
PROPRIETARY NOTE
*
THIS DOCUMENT CONTAINS CONFIDENTIAL AND
PROPRIETARY INFORMATION AND ALL DESIGN,
MANUFACTURING, REPRODUCTION, USE, PATENT RIGHTS
AND SALES RIGHTS ARE EXPRESSLY RESERVED BY SAMTEC,
INC. THIS DOCUMENT SHALL NOT BE DISCLOSED, IN WHOLE
OR PART, TO ANY UNAUTHORIZED PERSON OR ENTITY NOR
REPRODUCED, TRANSFERRED OR INCORPORATED IN ANY
OTHER PROJECT IN ANY MANNER WITHOUT THE EXPRESS
WRITTEN CONSENT OF SAMTEC, INC.
520 PARK EAST BLVD, NEW ALBANY, IN 47150
PHONE: 812-944-6733
FAX: 812-948-5047
e-Mail info@SAMTEC.com
code 55322
DESCRIPTION:
IPD1-XX-S-K
DO NOT SCALE DRAWING
.100[2.54] SOCKET DISCREET CABLE ASSEMBLY
DWG. NO.
SHEET SCALE: 1.5:1
MMSSX-XX-XXX-X-XX.XX-X-X-XXX
BY:
F:\DWG\MISC\MKTG\MMSSX-XX-XXX-X-XX.XX-X-X-XXX-MKT.SLDDRW
DEAN P
05/03/2005
SHEET
2
OF
3
REVISION AH
FIG 4
(MMSSX-06-XX-X-XX.XX-S-M SHOWN)
(SAME AS FIG 1, UNLESS OTHERWISE STATED)
C
CABLE CUT IN-PROCESS
.210
- .005
5.33
- 0.13
"A"
(SEE TABLE 1, SHT 1)
IPD1-XX-S-X-R
.618 15.70
REF
C
+.010
+0.25
"A"
(SEE TABLE 1, SHT 1)
.109
- .002
2.77
- 0.05
+.003
+0.08
OVERALL LENGTH
(SEE TABLE 3)
LTC-14-01-N
OVERALL LENGTH
(SEE TABLE 3)
"A"
(SEE TABLE 1, SHT 1)
-S: SINGLE END
-D: DOUBLE END
*
PROPRIETARY NOTE
*
THIS DOCUMENT CONTAINS CONFIDENTIAL AND
PROPRIETARY INFORMATION AND ALL DESIGN,
MANUFACTURING, REPRODUCTION, USE, PATENT RIGHTS
AND SALES RIGHTS ARE EXPRESSLY RESERVED BY SAMTEC,
INC. THIS DOCUMENT SHALL NOT BE DISCLOSED, IN WHOLE
OR PART, TO ANY UNAUTHORIZED PERSON OR ENTITY NOR
REPRODUCED, TRANSFERRED OR INCORPORATED IN ANY
OTHER PROJECT IN ANY MANNER WITHOUT THE EXPRESS
WRITTEN CONSENT OF SAMTEC, INC.
520 PARK EAST BLVD, NEW ALBANY, IN 47150
PHONE: 812-944-6733
FAX: 812-948-5047
e-Mail info@SAMTEC.com
code 55322
DESCRIPTION:
DWG. NO.
DO NOT SCALE DRAWING
.100[2.54] SOCKET DISCREET CABLE ASSEMBLY
SHEET SCALE: 1:1
MMSSX-XX-XXX-X-XX.XX-X-X-XXX
DEAN P
05/03/2005
SHEET
3
OF
3
F:\DWG\MISC\MKTG\MMSSX-XX-XXX-X-XX.XX-X-X-XXX-MKT.SLDDRW
BY:
