BACK LIGHT
AT T E N T I O N
GLP003/1608PBC
BLUE
OBSERVE PRECAUTIONS
FOR HANDLING
ELECTROSTATIC
DISCHARGE
SENSITIVE
DEVICES
Features
l
LOW
l
LARGE
l
EASY
l
LOW
POWER REQUIREMENTS.
Description
EMITTING SURFACE.
AREA, UNIFORM, BRIGHT LIGHT
The Blue source color devices are made with
InGaN on SiC Light Emitting Diode.
Static electricity and surge damage the LEDS.
It is recommended to use a wrist band or
anti-electrostatic glove when handling the LEDs.
All devices, equipment and machinery must be
electrically grounded.
POWER CONSUMPTION.
FOR INSTALLATION.
Package Dimensions & Internal Circuit Diagram
APH1608PBC-4PCS
Notes:
1. All dimensions are in millimeters (inches).
2. Tolerance is
±0.25(0.01")
unless otherwise noted.
3. Lead spacing is measured where the lead emerge package.
4. Specifications are subject to change without notice.
SPEC NO: DSAD1405
APPROVED: J.Lu
REV NO: V.1
CHECKED: Allen Liu
DATE: MAY/24/2003
DRAWN: K.ZHANG
PAGE: 1 OF 3
Selection Guide
P ar t N o .
GLP003/1608PBC
BLUE ( InGaN )
Dic e
L en s Ty p e
WATER C LEAR
Ev (l u x )
@ 80m A
Mi n .
293
Ty p .
440
Electrical / Optical Characteristics at T
A
=25°C
°
Sy m b o l
λ
p e a k
λ
D
∆λ
1/2
C
V
F
I
R
P ar am et er
Peak Wavelength
D omi nate Wavelength
Spectral Li ne Half-wi dth
C apaci tance
Forward Voltage
Reverse C urrent
Blue
Blue
Blue
Blue
Blue
Blue
D ev i c e
Ty p .
468
470
25
65
3.65
--
Max .
--
--
--
--
4.2
10
Un its
nm
nm
nm
pF
V
uA
Tes t C o n d i t i o n s
I
F
=20mA(per chi p)
I
F
=20mA(per chi p)
I
F
=20mA(per chi p)
V
F
=0V;f=1MHz
I
F
=20mA(per chi p)
V
R
= 5V
Absolute Maximum Ratings at T
A
=25°C
°
P ar am et er
Power di ssi pati on
Forward C urrent
Reverse Voltage
Operati ng/Storage Temperature
Note:
1. The Chips are four parallel.
B lu e
410
120
5
-40
°
C To +85
°C
Un its
mW
mA
V
SPEC NO: DSAD1405
APPROVED: J.Lu
REV NO: V.1
CHECKED: Allen Liu
DATE: MAY/24/2003
DRAWN: K.ZHANG
PAGE: 2 OF 3
