30KPA28A-LF Overview

Trans Voltage Suppressor Diode, 30000W, 28V V(RWM), Unidirectional, 1 Element, Silicon,

30KPA28A-LF Parametric

Parameter Name	Attribute value
Is it Rohs certified?	conform to
Maker	ProTek Devices
package instruction	O-PALF-W2
Reach Compliance Code	compliant
ECCN code	EAR99
Other features	UL RECOGNIZED
Minimum breakdown voltage	31.28 V
Shell connection	ISOLATED
Configuration	SINGLE
Diode component materials	SILICON
Diode type	TRANS VOLTAGE SUPPRESSOR DIODE
JESD-30 code	O-PALF-W2
JESD-609 code	e3
Maximum non-repetitive peak reverse power dissipation	30000 W
Number of components	1
Number of terminals	2
Maximum operating temperature	150 °C
Minimum operating temperature	-55 °C
Package body material	PLASTIC/EPOXY
Package shape	ROUND
Package form	LONG FORM
Peak Reflow Temperature (Celsius)	NOT SPECIFIED
polarity	UNIDIRECTIONAL
Maximum power dissipation	8 W
Guideline	IEC-61000-4-5
Maximum repetitive peak reverse voltage	28 V
surface mount	NO
technology	AVALANCHE
Terminal surface	Tin (Sn)
Terminal form	WIRE
Terminal location	AXIAL
Maximum time at peak reflow temperature	NOT SPECIFIED
Base Number Matches	1

Preview

Download Datasheet

View All

05113

Only One Name Means ProTek’Tion™

30KPA28A - 30KPA360A

RTCA DO-160G COMPLIANT PRODUCT

30kW POWER TVS COMPONENT

DESCRIPTION

The 30KPA Series, are discrete 30,000 Watt, silicon transient voltage suppressors (TVS) designed for use in applications

where large voltage transients can permanently damage voltage sensitive components and equipment.

The 30KPA series is available in voltages ranging from 30V to 360V with 5 percent and 10 percent tolerances. Both

tolerances are referenced to the power supply output or operating voltage level. This series is compatible with IEC

61000-4-5 (Surge) requirements.

AXIAL LEAD PACKAGE

FEATURES

• RTCA DO-160G COMPLIANT PRODUCT

•

UL File Recognition #E208219

•

Compatible with IEC 61000-4-5 (Surge): 48A, 8/20µs - L3(Line-

Ground), L4(Line-Line) & L1 (Power)

•

30,000 Watts Peak Pulse Power per Line (tp = 10/1000µs)

•

Unidirectional and Bidirectional Configurations

•

Easy Mounting to Printed Circuit Board

•

tClamping (0V to V

Min.) < 1 x 10

-12

seconds theoretical

•

Available in Multiple Voltages Ranging From 28V to 360V

•

RoHS Complaint (Exemption #7)

APPLICATIONS

•

Relay Drives

Motor (Start/Stop) Back EMF Protection

Module Lightning Protection

Secondary Lightning Protection for AC/DC

MECHANICAL CHARACTERISTICS

Molded Case

Approximate Weight: 5 grams

Lead-Free Pure-Tin Plating (Annealed)

Solder Reflow Temperature:

Pure-Tin - Sn, 100: 260-270°C

•

Flammability Rating UL 94V-0

•

CIRCUIT DIAGRAMS

UNIDIRECTIONAL

BIDIRECTIONAL

05113.R38 12/16

Page 1

www.protekdevices.com
