KBL402GT0

Description
Bridge Rectifier Diode, 4A, 100V V(RRM),
CategoryDiscrete semiconductor    diode
File Size190KB,4 Pages
ManufacturerTaiwan Semiconductor
Websitehttp://www.taiwansemi.com/
Environmental Compliance
Download Datasheet Parametric View All

KBL402GT0 Overview

Bridge Rectifier Diode, 4A, 100V V(RRM),

KBL402GT0 Parametric

Parameter NameAttribute value
Is it Rohs certified?conform to
MakerTaiwan Semiconductor
package instructionR-PSIP-W4
Reach Compliance Codecompliant
ECCN codeEAR99
Other featuresUL RECOGNIZED
Minimum breakdown voltage100 V
ConfigurationBRIDGE, 4 ELEMENTS
Diode component materialsSILICON
Diode typeBRIDGE RECTIFIER DIODE
Maximum forward voltage (VF)1 V
JESD-30 codeR-PSIP-W4
JESD-609 codee3
Maximum non-repetitive peak forward current150 A
Number of components4
Phase1
Number of terminals4
Maximum operating temperature150 °C
Minimum operating temperature-55 °C
Maximum output current4 A
Package body materialPLASTIC/EPOXY
Package shapeRECTANGULAR
Package formIN-LINE
Peak Reflow Temperature (Celsius)NOT SPECIFIED
Maximum repetitive peak reverse voltage100 V
surface mountNO
Terminal surfaceMatte Tin (Sn)
Terminal formWIRE
Terminal locationSINGLE
Maximum time at peak reflow temperatureNOT SPECIFIED
Base Number Matches1
KBL401G thru KBL407G
Taiwan Semiconductor
CREAT BY ART
Glass Passivated Bridge Rectifiers
FEATURES
- Glass passivated junction
- Ideal for printed circuit board
- Reliable low cost construction
- UL Recognized File # E-326243
- Compliant to RoHS Directive 2011/65/EU and
in accordance to WEEE 2002/96/EC
- Halogen-free according to IEC 61249-2-21 definition
KBL
MECHANICAL DATA
Case:
KBL
Molding compound, UL flammability classification rating 94V-0
Base P/N with suffix "G" on packing code - halogen-free
Terminal:
Matte tin plated leads, solderable per JESD22-B102
Meet JESD 201 class 1A whisker test
Polarity:
Polarity as marked on the body
Weight:
5.6 g (approximately)
MAXIMUM RATINGS AND ELECTRICAL CHARACTERISTICS
(T
A
=25℃ unless otherwise noted)
PARAMETER
Maximum repetitive peak reverse voltage
Maximum RMS voltage
Maximum DC blocking voltage
Maximum average forward rectified current
Peak forward surge current, 8.3 ms single half sine-wave
superimposed on rated load
Rating for fusing (t<8.3mS)
Maximum instantaneous forward voltage (Note 1)
I
F
= 2A
I
F
= 4A
Maximum DC reverse current
at rated DC blocking voltage
Typical thermal resistance
Operating junction temperature range
Storage temperature range
Note 1: Pulse Test with PW=300μs,1% Duty Cycle
T
J
=25
T
J
=125℃
SYMBOL
V
RRM
V
RMS
V
DC
I
F(AV)
I
FSM
I
2
t
V
F
KBL
401G
50
35
50
KBL
402G
100
70
100
KBL
403G
200
140
200
KBL
404G
400
280
400
4
150
93
1.0
1.1
10
500
2.4
19
- 55 to +150
- 55 to +150
O
KBL
405G
600
420
600
KBL
406G
800
560
800
KBL
407G
1000
700
1000
Unit
V
V
V
A
A
A
2
s
V
I
R
R
θJL
R
θJA
T
J
T
STG
μA
C/W
O
O
C
C
Document Number: DS_D1311025
Version: G13
