DC/DC

MODUL

RDD08 DC Power Package

8 Watt Wide-Input DIL24 Compact-Serie

Besondere Merkmale

Weiter Eingang 2:1

Geringe Bauhöhe

Isolationspg. min. 1500V DC

Hoher Wirkungsgrad

Kurzschlußfest

TÜV/UL/cUL Zulassung

Features

Wide input range 2:1

Low profile

Isolation min. 1500V DC

High efficiency

Short circuit protection

TÜV/UL/cUL approvals

Anwendung

Telekommunikation

Rechnersysteme

MSR

Mikroprozessorsysteme

Application

Telecommunication

Computer applications

Control equipments

Microprocessor systems

Technische Daten

(bei 25°C Umgebungstemperatur)

Specification

(at 25°C ambient temperature)

Eingangsdaten

Eingangsspannung

Eingangsfilter (integriert)

Input Specifications

Input voltages

Build in filter

9…18, 18…36, 35...75 VDC

PI-Type

Ausgangsdaten

Leistung

Wirkungsgrad

Schaltfrequenz

Regelabweichung

Lastregelung

Eingangsregelung

Restwelligkeit

Output Specifications

Power

Efficiency

Switching frequency

Voltage accuracy

Load regulation

Line regulation

Ripple and noise

6.6-8.1 Watt

up to 85%

280 kHz

typ. ±2%

±1%

±0,5%

50mV max. (Vp-p)

Allgemeine Daten

Betriebstemperatur

Lagertemperatur

Temperaturkoeffizient

Kurzschlußfest

An/Ausschaltung

Zulassungen

General Specifications

Operating temp.

Storage temperature

Temp. coefficient

Short circuit protection

Remote on/off control

Safety approvals

−40°C…+71°C,derating

see curve

−40°C…+100°C

0.02% / °C

Continuous

ON: 3...10VDC or open circuit

OFF: 0...1,5VDC or short circuit pin 1 and pin 2,3

TÜV EN60950-1

UL/cUL UL60950-1

CE EN61204-3(Class A for EMI)

HN Electronic Components GmbH & Co. KG • Birkenweiherstr. 16 • D-63505 Langenselbold

Tel. (06184) 92780 • Fax (06184) 62316 • http://www.hn-electronic.de
