EMC Components
EMC Filters for AC Power Supply
Cased (Compact Size)
FEATURES
• EMC filters exhibit outstanding attenuation characteristics with
respect to both differential mode and common mode noise com-
ponents in the MF and HF bands.
• Leakage current is maintained at less than 1mA.
• Utilizing a plastic case and a ground terminal, these filters are
high cost-efficient.
• Small and lightweight.
• Designed to ensure superior safety and reliability, easy imple-
mentation and maintenance.
SHAPES AND DIMENSIONS
ZMB-13 Series
SAFETY STANDARDS
Part No.
ZMB2201-13
ZMB2203-13
VDE
19047-4730-1002
19047-4730-1002
APPLICATIONS
Digital applied devices (ECR, calculators, electronic scales, etc.),
control devices, measurement devices, and other electronic equip-
ment.
1
4
D
E
A
2
3
I
Ground
terminal
Screw hole H
F
B
F
L
G
K
C
J
G
G
Dimensions in mm
Part No.
A
B
C
ZMB2201-13, 2203-13
30
45
20
• Case : plastic, terminal : lead wire (UL1015 AWG#22)
D
50
E
40
F
300
G
20
H
M3
I
15
J
7.5
K
13
L
200
ELECTRICAL CHARACTERISTICS
Part No.
Rated voltage Eac(V)
Rated current(A)
Test voltage Eac(V)[Between lead wire and ground terminal]
Insulation resistance(MΩ)
[DC. 500V, 1min/between lead wire and ground terminal]
Leakage current(mA)[250V • 60Hz]
DC resistance(mΩ)
Operating temperature range(°C)[Including self-temperature rise]
With derating over(°C)
Temperature rise(°C)
Differential mode at 30dB
Attenuation frequency range
(MHz)[+5 to +35°C]
Common mode at 20dB
Weight(g)
ZMB2201-13
250
1
2000
100min.
0.4max.
200max.
–25 to +85
40
30max.
1.5 to 30
0.2 to 10
45
ZMB2203-13
250
3
2000
100min.
0.4max.
200max.
–25 to +85
40
30max.
1.5 to 30
0.5 to 10
45
• All specifications are subject to change without notice.
(2/2)
001-01 / 20030823 / e9146_zmb_13.fm
EMC Components
EMC Filters for AC Power Supply
Cased (Compact Size)
TYPICAL ELECTRICAL CHARACTERISTICS
ATTENUATION vs. FREQUENCY CHARACTERISTICS
ZMB2201-13
100
80
Attenuation(dB)
ZMB-13 Series
ZMB2203-13
100
80
Attenuation(dB)
60
Differential mode
40
Common mode
20
0
60
40
20
0
0.1
Differential mode
Common mode
0.3
1
3
10
(MHz)
Frequency
30
100
0.1
0.3
1
3
10
Frequency (MHz)
30
100
CIRCUIT DIAGRAM
Protective load
1
4
2
3
