KA11AY6 Product Details
Industrial Relays (General Purpose)
Always EU RoHS compliant but not ELV Compliant
(
Statement of
Compliance
)
Share
Print
Email
Quick Links
Pricing & Availability
Search for Tooling
Product Feature Selector
Contact Us About This Product
KA11AY6
(413930991)
TE Internal Number: 413930991
Product Highlights:
KRPA Series
Contact Current Class = 5A to 10A Class, Less Than
16A
Contact Rated Current = 10 A
Terminal Type = Solder
Contact Arrangement = 2 Form C (CO)
View all Features
Active
Add to My Part List
Request Sample
Find Similar Products
Buy Product
Documentation & Additional Information
Product Drawings:
None Available
Catalog Pages/Data Sheets:
KRPA, KRP, KA, KR 5 to 10 Amp General Purpose Relay (PDF, English)
Product Specifications:
None Available
Application Specifications:
None Available
Instruction Sheets:
None Available
CAD Files:
None Available
Additional Information:
Product Line Information
Additional Product Images:
Schematic
Wiring Diagram
Related Products:
Tooling
List all Documents
Product Features
(Please use the Product Drawing for all design activity)
Electrical Characteristics:
Contact Current Class = 5A to 10A Class, Less Than 16A
Contact Rated Current (A) = 10
Contact Limiting Continuous Current (A) = 10
Contact Limiting Making Current (A) = 10
Contact Limiting Breaking Current (A) = 10
Insulation Initial Dielectric Between Coil/Contact Class = 500V to
1000V Class
Insulation Initial Dielectric Between Open Contacts (V rms) = 1000
Insulation Initial Dielectric Between Contacts and Coil (V rms) =
1000
Contact Rated Voltage (VAC) = 240
Contact Limiting ShortTime Current (A) = 10
Contact Switching Recommended Load, Min. = 100mA at 12V
Coil Rated Voltage (VAC) = 6
Coil Resistance (Ω) = 6
Coil Rated Power, AC (VA) = 2.00
Coil Rated Power Class = 2.0VA to 3.0VA Class
Insulation Initial Dielectric Between Adjacent Contacts (V rms) =
1000
Insulation Initial Insulation Resistance (MΩ) = 100000
Dimensions:
Mechanical Length Class = 35mm to 40mm Class
Length (mm [in]) = 35.70 [1.406]
Mechanical Width Class = 30mm to 40mm Class
Width (mm [in]) = 35.70 [1.405]
Mechanical Height Class = >50mm Class
Height (mm [in]) = 50.80 [2.000]
Contact Features:
Terminal Type = Solder
Contact Material = Ag
Contact Number of Poles = 2
Configuration Features:
Contact Arrangement = 2 Form C (CO)
Coil Magnetic System = Monostable, AC
Coil Special Features = UL Coil Insulation Class B
Industry Standards:
RoHS/ELV Compliance = RoHS/Not ELV Compliant
Lead Free Solder Processes = Not relevant for lead free process
RoHS/ELV Compliance History = Always was RoHS not ELV compliant
Approved/Registered Standards = UL, CSA
Environmental:
Environmental Category of Protection = RT0
Environmental Ambient Temperature, Max. (°C [°F]) = 70 [158]
Environmental Ambient Temperature Class = 50°C to 70°C Class
Packaging Features:
Packaging Method = Tray
Other:
Series = KRPA
Brand = Potter & Brumfield
