342726-9 Product Details
Live Product Chat
Product View
MTA, CST-100 II, MT-6 and SL Connectors and Headers
Always EU R oHS/ELV C om plia nt
(
Sta te m e nt of C om plia nce
)
Quick Links
C heck Pricing & Availability
Search for Tooling
Product Feature Selector
C ontact Us About This Product
342726-9
T E I nternal N umber: 3 4 2 7 2 6 - 9
Product Highlights:
l
MT-7 C onnectors
l
Number of Positions = 3
l
Mating Type = Header
l
Wire-to-Board Application
l
2.54 mm C ontact C enterline Spacing
View all Features
Obsolete
C ontact Product Information C enter
A dd to M y P art L is t
Reques t Sample
Find Similar P roduc ts
Buy P roduc t
Documentation & Additional Information
Product Drawings:
l
None Available
Catalog Pages/Data Sheets:
l
Automachine and General Products
(PDF, English)
Product Specifications:
l
None Available
Application Specifications:
l
None Available
Instruction Sheets:
l
None Available
CAD Files:
l
None Available
List all Documents
Product Features
(Please use the Product Drawing for all design activity)
Product Type Features:
l
Product Type = MT-7 C onnectors
l
Number of Positions
= 3
l
Mating Type
= Header
l
PC B Mount Angle
= Vertical
l
Mating Polarization
= With
l
Mating C onnector Lock = Without
l
Four Points of C ontact
= Without
l
Shrouded
= Yes
l
Mounting Ears
= Without
Mechanical Attachment:
l
Panel Attachment
= Without
Termination Related Features:
l
Solder Tail C ontact Plating
= Tin
Contact Related Features:
l
C ontact C enterline Spacing (mm [in])
= 2.54 [0.100]
l
C ontact Mating Area Plating Material
= Tin
l
C ontact Base Material
= Brass
Housing Related Features:
l
Housing C olor = Blue
l
Housing Flammability Rating = UL 94V-2
l
Housing Material = Nylon
Configuration Related Features:
l
Backwall/Post Interruption(s)
= Without
Industry Standards:
l
RoHS/ELV C ompliance
= RoHS compliant, ELV compliant
l
Lead Free Solder Processes
= Wave solder capable to 240?C
l
RoHS/ELV C ompliance History = Always was RoHS compliant
Conditions for Usage:
l
Terminate To
= Printed C ircuit Board
Operation/Application:
l
Application
= Wire-to-Board
Other:
l
Brand = AMP
Additional Information:
l
Product Line Information
Additional Product Images:
l
PC B Layout
