826383-5: DescriptionCONNECTOR, 5 CONTACT(S), MALE, RIGHT ANGLE TWO PART BOARD CONNECTOR, SOLDER, ROHS COMPLIANT; CategoryThe connector The connector; File Size115KB，1 Pages; ManufacturerTE Connectivity; Websitehttp://www.te.com; Environmental Compliance

Download Datasheet Parametric View All

826383-5 Overview

CONNECTOR, 5 CONTACT(S), MALE, RIGHT ANGLE TWO PART BOARD CONNECTOR, SOLDER, ROHS COMPLIANT

826383-5 Parametric

Parameter Name	Attribute value
Is it Rohs certified?	conform to
package instruction	ROHS COMPLIANT
Reach Compliance Code	unknown
Connector type	BOARD CONNECTOR
Contact to complete cooperation	TIN
Contact point gender	MALE
Contact material	NOT SPECIFIED
DIN compliance	NO
Filter function	NO
IEC compliance	NO
MIL compliance	NO
Manufacturer's serial number	826383
Mixed contacts	NO
Installation method	RIGHT ANGLE
Installation type	BOARD
Number of rows loaded	1
Options	GENERAL PURPOSE
Terminal pitch	2.5 mm
Termination type	SOLDER
Total number of contacts	5
Base Number Matches	1

Preview

Download Datasheet

View All

C orporate Hom e

Electronic Components

Se gm e nts

W ho W e Are

My Account

Searc h

Products

Documentation

Resources

My Account

Customer Support

Home

Products

By Type

< 5 amps/C ircuit

Product Feature Selector

> Product Details

826383-5 Product Details

Live Product Chat

3D Generated Image

MTIS (MT Interconnection System)

Always EU R oHS/ELV C om plia nt

(

Sta te m e nt of C om plia nce

)

Quick Links

C heck Pricing & Availability

Search for Tooling

Product Feature Selector

C ontact Us About This Product

826383-5

T E I nternal N umber: 8 2 6 3 8 3 - 5

Product Highlights:

Header

Number of Positions = 5

Number of Rows = Single

C olor = Black

Without Daisy C hain

View all Features

Active

View 3D PDF

A dd to M y P art L is t

Reques t Sample

Find Similar P roduc ts

Buy P roduc t

Documentation & Additional Information

Product Drawings:

MT INTERC ONNEC TION SYSTEM STIFTWANNE, LIEGEND (2,5)

(PDF, English)

Catalog Pages/Data Sheets:

Automachine and General Products

(PDF, English)

Product Specifications:

None Available

Application Specifications:

None Available

Instruction Sheets:

None Available

CAD Files:

AD Format & C ompression Information)

2D Drawing

(DXF, Version P1)

3D Model

(IGES, Version P1)

3D Model

(STEP, Version P1)

List all Documents

Product Features

(Please use the Product Drawing for all design activity)

Product Type Features:

Product Type = Header

Number of Positions = 5

C olor = Black

PC B Mount Angle = Right Angle

Keyed = No

Mounting Ears = Without

Mating C onnector Lock = With

Mating C onnector Lock Type = Locking Rib

Body Related Features:

Number of Rows = Single

Daisy C hain = Without

C enterline (mm [in]) = 2.50 [0.098]

Contact Related Features:

C ontact Mating Area Plating Material = Post Tin

C ontact Termination Type = Through Hole

C ontact Base Material = Phosphor Bronze

Housing Related Features:

Housing Material = Thermoplastic Polyester

Industry Standards:

RoHS/ELV C ompliance

= RoHS compliant, ELV compliant

Lead Free Solder Processes

= Wave solder capable to 240?C

RoHS/ELV C ompliance History = Always was RoHS compliant

Conditions for Usage:

Terminate To = Printed C ircuit Board

Packaging Related Features:

Packaging Method = Loose Piece

Other:

Brand = AMP

Additional Information:

Product Line Information
