ÖLFLEX
®
Harmonized European Hook-up Wire & Cordage
Harmonized Hook-up Wire
Multi-Standard <HAR> Hook-up Wire
H05V-K: UL AWM Style 1007 & 1569, UL/CSA; H07V-K: UL AWM Style 1015, UL MTW 1063, CSA
Construction
Conductors: Finely stranded tinned copper
Insulation: PVC
This internationally approved hook-up wire was designed to meet North
American and European market requirements. It passes <HAR> H05V-K,
<HAR> H07V-K, UL AWM, UL MTW (16 AWG & larger), CSA TEW & CE.
Application Advantage
• Only one inventory vs. two for domestic and export
consumption
• 13 standard color options
• UL MTW (16 AWG & larger)
• Available in large cardboard barrels for easy pull
(16 AWG & larger)
•Embossed cable marking available upon request
Recommended Applications
Panel and machine wiring for domestic and export usage; internal wiring of
devices, electrical, and medical equipment
Approvals
Cable Attributes, see page 659
OR-02
OIL
FR-02
FLAME
FL-02
MOTION
MP-01
MECHANICAL
For wiring material that
conforms to H07V2-K,
please call your Lapp sales
representative.
Similar Cables
• <HAR> Hook-up Wire
• Halogen-free <HAR>
Hook-up Wire
Technical Data
Temperature Range:
- HAR/IEC:
- UL/CSA:
Nominal Voltage:
- H05V-K:
- HAR/IEC:
- UL/CSA:
- H07V-K:
- HAR/IEC:
- UL/CSA:
Test Voltage:
- H05V-K:
- H07V-K:
Conductor Stranding:
Part
Number
Color Code:
-40°C to +70°C
-40°C to +105°C
300/500V
300V
450/750V
600V
00:
01:
02:
03:
04:
05:
06:
Green/Yellow
Black
Blue
Brown
Red
White
Gray
07: Violet
08: Pink
09: Orange
10: Yellow**
11: Green**
14: Dark Blue
Approvals:
- H05V-K
UL: AWM 1007 & 1569
Canada: CSA AWM I A/B
Additional: <HAR> H05V-K
MTW per UL 1063
AWM 1015
Canada: TEW
Additional: <HAR> H07V-K
CE & RoHS
Nominal Outer
Diameter
(inches)
(mm)
Copper
Weight
(lbs/mft)
Approx.
Weight
(lbs/mft)
- H07V-K:
2000V
2500V
Class 5 fine wire
Copper
Weight
(lbs/mft)
Approx.
Weight
(lbs/mft)
Part
Number
UL:
Nominal Outer
Diameter
(inches)
(mm)
H05V-K
22 AWG (0.50 mm
2
)
41804..
20 AWG (0.75 mm
2
)
41805..
18 AWG (1.00 mm
2
)
41806..
H07V-K
16 AWG (1.50 mm
2
)
41604..
14 AWG (2.50 mm
2
)
41605..
12 AWG (4 mm
2
)
41606..
10 AWG (6 mm
2
)
41607..
0.098
0.102
0.110
0.134
0.157
0.181
0.201
2.5
2.6
2.8
3.4
4.0
4.6
5.1
3
5
6
10
16
26
39
6
8
10
15
25
30
48
8 AWG (10 mm
2
)
41608..
6 AWG (16 mm
2
)
41609..*
4 AWG (25 mm
2
)
41610..
2 AWG (35 mm
2
)
41611..
1 AWG (50 mm
2
)
41612..
2/0 AWG (70 mm
2
)
41613..
3/0 AWG (95 mm
2
)
41614..
4/0 AWG (120 mm
2
)
41615..
0.268
0.354
0.402
0.461
0.547
0.630
0.717
0.780
6.8
9.0
10.2
11.7
13.9
16.0
18.2
19.8
65
103
161
226
323
452
613
774
81
126
195
268
376
521
693
864
For Lapp part number, add the double digit color code (see above) to the part number prefix in the table; e.g.: 16 AWG H07V-K green/yellow = 4160400
* No <HAR> approval available for this size (X07V-K). ** For these colors no <HAR> approval for 1.5 mm
2
or larger.
Photographs are not to scale and are not true representations of the products in question. For current information go to our website. If not otherwise specified, all values relating to the product
are nominal values.
